Viper II - V2Frame
User Manual
Specifications
Mechanical
Dimensions (WxLxD)
5.25" x 17.25" x 11"
Weights -Frame
PS5000
PS5010
16 card slots, Max. of 14 modules plus PS5000
© 2001 Telecast Fiber Systems, Inc
Specifications subject to change without notice. Made in USA
Electrical
Input Voltage Range
9 lbs.
Output Voltage Range
5 lbs.
Power Consumption (per module)
3 lbs.
Power Consumption (Max)
102 Grove Street; Worcester, MA 01605 USA Phone: (508)754-4858 FAX: (508)752-1520
Quick Start Guide
The Viper II frame is designed for "plug and
play" use. The Power Bus System allows for
the convenient placement of modules in any
orientation that suits the user.
The frame ships ready-to-use. Simply insert
your PS5000 Power Supply Unit and the
optional PS5010 Battery back-up unit, if
provided. The rear of the PS5000 features a
Power Entry Module that must be set for your
local AC power. A convenient window on the
module shows the voltage input setting, either
115 or 230 VAC. If adjustment is necessary,
see the Power Supply section on page 3.
Note that the frame can accommodate
additional PS5000's or PS5010's to ensure
uninterrupted power to your system. The
PS5000 ships with a North American type
power cord. You may need to replace this with
the appropriate IEC cord to accommodate
your local power outlets.
Once the power supplies have been properly
configured and inserted into the rack frame,
AC mains power can be supplied and
additional modules can then be inserted.
Modules can be hot-swapped at any time
without fear of damage. Care should be taken
when inserting modules to ensure that they go
in straight since improper insertion can result
in damage to the internal backplane power
connectors, explained further on page 2.
Environmental
Temperature Range
100 to 240 VAC
Humidity Range
10 to 18 VDC
3 watts
50 watts
e-mail: sales@telecast-fiber.com
-25° to +55°C
0 to 95% RH, Noncond.
http://www.telecast-fiber.com
