- Page 1 302080002 Operation,maintenance and installation manual More information https://www.caravansplus.com.au...
- Page 2 More information https://www.caravansplus.com.au...
- Page 3 Table of Contents 302080002 302080002 More information https://www.caravansplus.com.au...
- Page 4 This machine has been designed and built to be installed on vehicles (motor homes, caravans, special vehicles,etc.) in order to improve the internal temperature. When the weather is hot it supplies cool and dehumidified air; when the weather is cold it supplies hot air without however replacing the vehicle’s original hea ng system.In both cases the air temperature is adjustable.
- Page 5 A:(Compressor) B:(Condenser) C:(Fan) D:(Evaporator) E:(4 Way switchover valve) More information https://www.caravansplus.com.au Operating instructions for users...
- Page 6 1.4. User tips The machine performance can be improved by taking some precau- ons. Improve the vehicle’s heat insula on by elimina ng openings and covering the glass surface with reflec ng curtains. Avoid frequently opening doors and windows when not necessary. Select the appropriate temperature and fan speed.
- Page 7 TABLEA Automatic mode Internal tem- T≦20°C 20°C<T<25°C T≧25°C perature Heat pump Dehumidifica on Press the on/off bu on to switch on Opera ng Cold the machine. mode ven la on ven la on Set point 20°C 22°C 25°C Press the change mode bu on to Cold mode select automa c mode¹.
- Page 8 Dehumidification mode Ventilation mode Press the on/off bu on to switch on Press the on/off bu on to switch on the machine. the machine. Press the change mode bu on to Press the change mode bu on to select dehumidifica on mode. select ven la on mode.
- Page 9 Heat pump mode Press the on/off bu on to switch on the machine. Press the change mode bu on to select heat pump mode. Press the selec on bu ons to set the ambient temperature on the SLEEP LOUVER desired value between 18°C and TIMER FUNCTION SWING LONIZER 30°C.
- Page 10 Pressing the mer off bu on a third note⁵ At the time the machine will start in automatic mode. me disables this func on More information https://www.caravansplus.com.au 302080002 Operating instructions for users...
- Page 11 1.6. Installing and changing the remote 1.7. Description of the receiver control batteries SLEEP LOUVER TIMER FUNCTION SWING LONIZER CANCEL OFF More information https://www.caravansplus.com.au Operating instructions for users...
- Page 12 1.7.1 Icons and buttons More information https://www.caravansplus.com.au Operating instructions for users...
- Page 13 1.7.2 Wall pad operation Operating instructions for users More information https://www.caravansplus.com.au...
- Page 14 1.7.3 ERROR AND PROTECTION LIST---when error or protection happen, the buzzer will sound; press any button, the buzzer’ sound will be disappear. More information https://www.caravansplus.com.au Operating instructions for users...
- Page 15 302080002 More information https://www.caravansplus.com.au Operating instructions for users...
- Page 16 1.9. Routine maintenance Cleaning: do it periodically,removing the dust with a moist cloth. if nec- Checking: do it periodically, making sure that: essary, use a non-aggressive detergent.Never use petrol or solvents. - the condensa on drain holes are not obstructed. - the openings in the floor are not obstructed.
- Page 17 Installa on can be performed by persons with specific technical knowledge. In addi on to this requirement, installers must have adequate working condi ons in order to ensure their own safety and that of others. 2.1. Packing, unpacking and handling Observe the instruc ons given on the packing.
- Page 18 2.2. Choice of the place of installation To accomplish uniform climate control in a vehicle, the machine must be installed correctly. Posi on the machine, to ensure easy access for servicing and to facilitate disassembly and installa on. Place the assembly template in the compartment intended for installa- on and check the space available for the openings in the floor.
- Page 19 2.3. Preparing the opening and fixing To install the machine it is necessary to create openings in the floor. The openings in the floor of the vehicle must be accessible and,there- fore,must not be covered by parts of the chassis frame behind or the like.
- Page 20 2.3.1 Fixing systems Parts supplied for the a/c fixing Mode 1: use n °4 screws for the a/c fixing More information https://www.caravansplus.com.au Operating instructions for users...
- Page 21 Mode 2: use n° 8 screws, n° 4 brackets and n° 2 belts for the a/c fixing Mode 3: use n° 4 screws and n° 4 washers for the a/c fixing More information https://www.caravansplus.com.au Operating instructions for users...
- Page 22 2.4. Fitting the wall-pad controller Posi on the wall-pad: To fit the wall-pad controller you need to make a 20 mm hole in the wall for fixing the connec ng cable to pass through (observe the stated distances for correct posi oning). Open wall-pad,let cable pass through the bo om box hole, fix it to the wall, so as to hide the hole you have made.
- Page 23 2.5. Compartment opening and electrical hook-up Make a hole in the compartment where the machine has been installed to permit recircula on of the internal air; Close this hole with a grille that allows at least 300cm² of air to pass through. Install the condensa on drain pipes provided, connect the wall-pad controller extension to the machine and lastly power up by inser ng the plug into a socket outlet 220-240V - 50Hz.
- Page 24 More information https://www.caravansplus.com.au...
- Page 25 More information https://www.caravansplus.com.au Operating instructions for users...
- Page 26 More information https://www.caravansplus.com.au...
- Page 27 302080002 More information https://www.caravansplus.com.au...
- Page 28 DESCRIPTION DESCRIPTION DESCRIPTION BASE FOUR-WAY VALVE FIXING BRACKET MAIN PCB COPPER PIPE 2 EPP BASE CAPILLARY PIPE SCREW FOR FIXING MOTOR FIXING BRACKET ELECTRIC CABLE COPPER PIPE 3 CABLE CLAMP AIRFILTER BELT 1 ELECTRICAL HEATING BELT 2 VIBRATION-DAMPING WALL-PAD CONTROLLER PIN FOR FIXING CAPACITOR REMOTE CONTROL...
