HÄFELE AXILO
PLINTH ADJUSTING FITTING SYSTEM
EASY. CONVENIENT. EFFICIENT.
AXILO
by Häfele is a new, revolutionary plinth adjusting fitting system. The combination of the
TM
adjusting tool and the plinth adjusting foot makes levelling a kitchen or a furniture item a simple,
comfortable operation.
THE REASON FOR USING AXILO
Easy cabinet levelling with just a few
manual operations.
Ergonomic and back-friendly
installation.
Time saving of up to 50% during
kitchen or furniture assembly.
Large area of application for plinth
heights from 50 to 220 mm.
TM
ENGINEERED BY HÄFELE
TM
DEVELOPMENT
Innovative system with patented technology.
Ergonomic solution.
PRODUCTION
High quality products, made in Germany.
LOGISTICS
Global availibilty.
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Häfele AXILO
- Page 1 Häfele is a new, revolutionary plinth adjusting fitting system. The combination of the adjusting tool and the plinth adjusting foot makes levelling a kitchen or a furniture item a simple, comfortable operation. THE REASON FOR USING AXILO ENGINEERED BY HÄFELE Easy cabinet levelling with just a few DEVELOPMENT manual operations.
- Page 2 For press fitting into mounting plate. > Height Adjustment: -10 to +20 mm. Adjustable at the side and from above via a P23 screw driver through the carcase or using AXILO adjusting tool. > Load bearing capacity: 150 kg/foot GLIDE, SCREW FIX SET...
- Page 3 For use from installation height H = 80 mm. For screw fixing For press fitting ADJUSTING TOOL > Area of application: For ergonomic and time-saving height adjustment of AXILO plinth adjusting legs. > Material: Plastic, mechanism: Steel > Adjustment facility: Adjustment angle height 0-10˚...
- Page 4 Practical, particulary in areas that are difficult to access. EFFICIENT LONG REACH Since you always work in front of the cabinet with AXILO The unique AXILO adjusting tool acts as an extended arm - you always have the spirit level in view - which saves time with the additional extension you can even reach plinth feet and energy.
