LTN1-300RUPS
LTN2-300RUPS
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE USE.
•
Fixtures must be wired in accordance with the National Electric Code and all applicable local codes.
•
This product must be installed in accordance with the applicable installation code by a person(s)
familiar with the construction and operation of the product and the hazards involved.
WARNING and ATTENTION:
•
Please read instructions prior to installation to ensure you have necessary tools and hardware
•
Battery is Lithium Ion. Transportation to/from other locations may have limitations by law
•
The battery will stop charging when ambient temperature falls below -4⁰F or above 140⁰F. Once
temperature returns to this range, battery will function as normal
•
Care must be taken during installation as items are odd sizing and heavy weight
•
The solar bracket is designed for universal installation. It can be wall-mounted, roof-mounted or
pole mounted. Please ensure that the correct hardware is available for the desired installation.
Installer is responsible for ensuring that the installation surface or pole, hardware and mounting
method is appropriate for any conditions that may be encountered in that location. Lite the Nite
assumes no responsibility or liability for improper installation procedure
•
If mounting panel on a pole, please ensure pole foundation is solid enough to withstand solar
panel(s) and battery box
•
For pole mounting installation, pole should be 3 or 4 inches in diameter round or square and made
of thick wall steel or Aluminum
•
Solar panel bracket should be mounted facing direction that provides most sunlight over longest
period
•
Adjust solar panel bracket so panel has a minimal 10⁰ incline for self-cleaning
•
If using pole mount and under high wind conditions, it is recommended to mount low on pole for
greater stability
•
Will require two or more people to install
CHARGE CONTROLER ELECTRICAL SPECIFICATION
•
Max Solar Input voltage: 50 Vdc or (2x12volt panels in series)
•
Max charging Output current 25 amps or 300 watts
•
Charging cut-off when battery = 14.2 Vdc
•
Floating Charge rate 13.8 Vdc
•
Min 9 volts for operation / LED status indication
BATTERY ELECTRICAL SPECIFICATION
•
Operating voltage Min 11.3 Vdc Max 14.2 Vdc Nominal 12.7 Vdc
•
Max discharging current 9.5 amps (unless larger fuse installed)
•
Max discharge current 30 amps continuous (with larger fuse)
•
Max discharge current intermittent 1 min On 1 min Off 40 amps
650 East Algonquin Road, Suite 206, Schaumburg, IL 60173
"RUPS" INSTRUCTIONS
Renewable Universal Power Supply
For use on 3"- 4" round or square pole, rooftop, or wall
For use on 2" round pole
www.litethenite.com
1
Advertisement
Summary of Contents for Lite the Nite RUPS
- Page 1 Please ensure that the correct hardware is available for the desired installation. Installer is responsible for ensuring that the installation surface or pole, hardware and mounting method is appropriate for any conditions that may be encountered in that location. Lite the Nite assumes no responsibility or liability for improper installation procedure •...
- Page 2 TOOLS/MATERIALS NEEDED: • Socket wrench with 4” extension and 16mm deep well socket (thin wall) • Utility Knife or side cutters • Allen wrench (included in carton) • Adjustable wrench • Appropriate mounting screw bolts for rooftop or side structure mounting LTN1-300RUPS - ITEMS INCLUDED WITH THIS BRACKET: A.
- Page 3 LTN1-300RUPS The bracket is pre-assembled to facilitate installation. NOTE: It is not necessary to use or match any of the numbers or markings on the bracket. a. Remove zip ties and cardboard fillers (shown above, left image) Note that bracket is in collapsed position (see pin location in red circle) b.
- Page 4 • Mounting brackets will slide together in center location for “U” bolt assembly around pole. • BE SURE “U” CLAMP (E) IS MOUNTED AWAY FROM POLE • Take bracket out of box and unfold as shown in picture below • Adjust lower arms and slightly tighten bolts so cross bracket can still move •...
- Page 5 • Confirm that the T-Bolts (H) are loose so that it will be easy to install the solar panels later (should have 1/8” to 1/4” clearance at this stage) • Attach top mount to pole using appropriate “U” bolts (sold separately), 1 pc of the large mounting bracket and 1 pc of the small mounting bracket.
- Page 6 • Slightly raise the bottom crossbar and install lower bracket • NOTE: upper and lower brackets should NOT be closer than 24 inches • Final Solar Panel angle adjustment should be made at this time and all bolts tightened • The top support arms of the bracket should be at approximately 45 degrees for the solar panels to have a good orientation to the sun.
- Page 7 • Align the T-bolts (H) so that the slots on the back of the solar panel will slide on appropriately. • Install the solar panel by aligning glide holes on back and slide into place. Once T bolt (H) heads are inside solar panel hole, tighten all 4 T-bolts (H).
-
Page 8: Surface Mount
• Attach plastic tabs (D) at top ends of each bracket. Leave bottom tabs open for water to escape • Attached warning sticker to pole for easy read SURFACE MOUNT: • Use same process as pole mount but spread mounting brackets (B & C) to corners of bracket •... - Page 9 LTN2-300RUPS - 2-inch pole top mount Determine angle of solar panel (figure 4) prior to putting together panel bracket (figure 2) to pole top mount (figure 1). Panel can be adjusted +/- 45 degrees for optimal sunlight exposure. 1. Install pole top mount (figure 1) to panel bracket (figure 2) and secure with two long screws provided.
- Page 10 3. The assembled unit should be as shown below (figure 4). Figure 4 4. Align solar panel in direction for greatest sun exposure throughout the daytime. Utilize 3 screws for tightening the sleeve once placed over pole. NOTE: Be sure to tighten each screw evenly for even and most secured mounting. Figure 5 650 East Algonquin Road, Suite 206, Schaumburg, IL 60173 www.litethenite.com...
- Page 11 CONNECTING YOUR SOLAR PANEL(S): • NOTE: for the connectors (I), there is only 1 correct orientation for installation. The alignment features need to be properly aligned for proper operation. • WARNING: DO NOT force the connectors together with the pins improperly aligned. This will cause connection problems.
- Page 12 BATTERY BOX MOUNT: • Mount battery box no lower than two feet from the ground • Connect upper “U” bolt and tighten as shown in picture below. Remember to use teeth bracket for scorning into pole • Once secure, attach bottom of battery box in same manner CONNECT SOLAR PANELS TO BATTERY BOX: •...
- Page 13 • Your battery is not operational until the fuse is properly installed so there is no discharge while in transit and storage • Locate fuse located under timer (note this is only connected to one plug outlet) • Pull out fuse and reconnect into both plugs (make sure connection is secure) •...
- Page 14 Press center button to desired setting ON/AUTO (dusk to dawn)/2/4/6/8 hour operation • Close door and lock for secure fit Congratulations… your RUPS is now fully operational so Let’s Get ON with it! 650 East Algonquin Road, Suite 206, Schaumburg, IL 60173 www.litethenite.com...
