Summary of Contents for NULEA HD315
- Page 1 WORK WITH YOUR FAVORITE Nulea is happy to provide its clients with help around the clock. Visit www.nulea.com and select 24/7 live chat, or send an email to support@nulea.com for immediate assistance. This product is covered in a 12-month warranty program.
- Page 2 Work with your favorite At Nulea, we believe you should choose the work you love and work in an environment that makes you comfortable and happy. Nulea Ergonomic Series is designed for people who demand maximum typing experience with minimum fatigue and stresses.
- Page 3 How to deal with Bluetooth disconnection, duplicate input and input lag? 1. Check the keyboard power. Low battery power can adversely affect the connectivity and overall functionality of the keyboard. For your better experience, fully charge the keyboard with the included USB-C cable before using it for the first time.
- Page 4 How to deal with Bluetooth pairing doesn't work, Bluetooth can't connect problem? 1. Check and make sure that the Bluetooth on your computer is turned on and make sure that the keyboard's connection channel is on the appropriate device. (Up to three devices can be connected, one for each channel) 2.Unpair and delete the keyboard's Bluetooth name on your computer's paired device.
- Page 5 How to charge the keyboard? 1. To charge the keyboard, plug the included USB-C to USB-A cable into the keyboard and laptop respectively. (Or use a 5V/1A charger) 2. During charging, the charging indicator light is red, and the indicator light turns green when fully charged. 3.
- Page 6 So if you don't adapt to it, please stick with it for a while. If you still don't like it, please don't hesitate to contact our service for help. Customer Service： support@nulea.com...
- Page 7 1 × Wireless Ergonomic Keyboard 1 × 2.4G USB Receiver ( For 2.4G connection only ) 1 × USB-C Charging Cable 1 × User Manual Specification HD315 Model Connected by Bluetooth & 2.4G receiver Product Dimensions 418.04 × 244.08 × 32.71mm / 16.5 × 9.6 × 1.3 in Connection 2.4G Wireless &...
- Page 8 Hardware Basics Power On/Charging Indicator Connection Indicator Num Lock Indicator Fn Key Caps Lock Indicator Leather Wrist Rest Charging Ports USB Receiver Power Switch...
- Page 9 Indicators & Definition Indicator Icon Color Definition Power On Green Green indicator is on for 3s then off. Low battery indicator flashes red. Charging Red- Green Stay in red color when charging, and it will turn green after fully charged. Press Fn+Q to 2.4G mode, green 2.4G Green...
- Page 10 Pairing Steps A.2.4G Connection Step 1. Flip the power switch to the ON position. Step 2. Plug the 2.4G USB receiver into the port of computer.
- Page 11 Step 3. Press "Fn+Q", the mode light will light up green and switch to 2.4G wireless mode. Green B. Bluetooth Connection Pair with 1 device Step 1. Flip the power switch to the ON position.
- Page 12 Step 2. Press “Fn+W” to enter channel 1 mode. Long press “Fn+W” for 5 seconds to enter pairing mode, Bluetooth channel 1 indicator will flash blue and start to search the available Bluetooth device. Blue...
- Page 13 Step 3. On your Bluetooth device, find the Bluetooth name “Nulea RT05” and click to connect it. Bluetooth Search Devices Nulea RT05 connected ”foeter” Not Connected IK6650 Not Connected Bluetooth: On Turn Bluetooth Off Now discoverable as ”forter 的 iMac”...
- Page 14 Pair with 2 device Step 1. Press “Fn+E” to enter channel 2 mode.
- Page 15 Long press “Fn+E” for 5 seconds to enter pairing mode, Bluetooth channel 2 indicator will flash red and start to search the available Bluetooth device.
- Page 16 Step 2. On your Bluetooth device, find the Bluetooth name “Nulea RT05” and click to connect it. Bluetooth Search Devices Nulea RT05 connected ”foeter” Not Connected IK6650 Not Connected Bluetooth: On Turn Bluetooth Off Now discoverable as ”forter 的 iMac”...
- Page 17 Keys & Functions Turn on Fn Lock Mac / Key Icon Windows Fn Lock is on Windows Brightness- (Win 10) Brightness- Brightness+ (Win 10) Brightness+ Switch Between Switch Between Open Apps Open Apps Task View Mission Control Show Desktop Show Desktop Search Spotlight Email...
- Page 18 How to change the backlight color? Press the light adjustment button, three levels of brightness adjustable. Press the light adjustment button and the up or down buttons to adjust the backlight color. Switch Color: Blue/Green/Red/Cyan/Purple/Yellow/White Blue Green Cyan Purple Yellow White...
- Page 19 Sleep Mode The keyboard will enter sleep mode if idle for 30min. To save keyboard power, if you don't use the keyboard, the keyboard backlight will go into sleep mode after three minutes. Press any key to exit sleep mode. Charging Low battery indicator flashes red, in order not to affect the experience and function of the keyboard, please charge in time.
- Page 20 FCC ID Statement Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 21 The Bluetooth word mark and logos are registered trademarks owned by the ® Bluetooth SIG, Inc. and any use of such marks by Nulea is under license. Other trademarks and trade names are those of their respective owners.
- Page 22 FCC ID: 2AKHJ-HD315 MADE IN CHINA UAB Qixiang Europe Pranciškonų g. 6-46, LT-01133 Vilnius, Lithuania Technical Information Center Geschwister-Scholl-Str. 73, 60488 Frankfurt, Germany Email: qixiang.europe@gmail.com Phone: +49 6976 895074 CET Product Service Ltd. Beacon House Stokenchurch Business Park, Ibstone Rd, Stokenchurch High Wycombe HP14 3FE UK Email: info.cetservice@gmail.com...
