Summary of Contents for Rovin S03 Pro
- Page 1 MB4100 512Wh Portable Power Station INSTRUCTION MANUAL...
- Page 2 CONTENTS Warnings & Safety Information .............3 Before First Use ...................4 Box Contents ....................4 Features......................4 Product Diagram ..................5 Charging Instructions ................6 Operating Instructions ................6 Troubleshooting ..................7 Specifications ....................7 Warranty Information ................10...
- Page 3 WARNINGS & SAFETY INFORMATION WARNING: The manufacturer is not responsible for any potential injury from misuse Improper use of this product may cause serious injury to yourself or others, or cause product damage and property loss. This document is subject to changes updates, revisions, or termination without prior notice.
- Page 4 BOX CONTENTS Power Station AC Charging Cable MB4100 512Wh Portable Power Station INSTRUCTION MANUAL Fuse Manual...
- Page 5 PRODUCT DIAGRAM Main Power Switch USB-A Outputs 240VAC Output Power Switch 240VAC Output LCD Screen 12VDC Output USB-C Output 12VDC Output Power Switch 240VAC Fuse Holder 10. Solar Input 11. 240VAC Input...
- Page 6 OPERATING INSTRUCTIONS LCD battery capacity circle indicates battery level. The capacity circle is divided into five sections, accounting for approximately 20%~40%~60%~80%~100% of the capacity. When in use, the LCD display automatically wakes up. When discharging, the capacity segment disappears from the display, indicating remaining capacity. When charging, the battery capacity circle flashes clockwise along the trajectory, which indicates that the device is currently charging.
- Page 7 RECHARGE METHODS 240VAC Charging Use the included AC charging cable to charge the device and connect it as shown in the figure. At this time, the input power reading appears on the screen, and the device starts charging. It can support up to 300W fast charging and can fully charge the device in about 1.8 hours.
- Page 8 OTHER FUNCTIONS AC Input Overload Protection When the AC input current exceeds the maximum rated current, the AC input overload protector fuse blows to protect the device. After confirming that there is no fault with the power station, replace the fuse in the 240VAC fuse holder (see accessory bag) to resume charging.
- Page 9 1. What type of battery does the product use? This product uses high-quality lithium iron phosphate batteries. 2. What equipment can be connected to the AC output port of the product? The AC output port of this product has a rated power of 600W and a peak power of 1200W.
- Page 10 TROUBLESHOOTING FAULT FAULT INFORMATION STATUS REMARKS CODE AC output short Flashing, no Press the AC output circuit protection output power on/off button for recovery Output overload The function icon Flashing, no protection indicates which path is output overloaded. Overload protection requires manual recovery.
- Page 11 FAULT FAULT INFORMATION STATUS REMARKS CODE System overload The AC icon flashes, Need to manually press the AC function the AC power button to is turned off, DC restore output is normal, AC is greater than 600VA or AC+DC is greater than 600W Hardware bias Ell code flashing, no...
- Page 12 SPECIFICATIONS Model S03 Pro AC Output Rated Voltage 220~240VAC Rated Power 600W Peak Power 1200W Frequency 60/50Hz DC 12V & Car Rated Voltage 12.8V Lighter Output Rated Current USB-A / C Output 5V/3A; 9V/2A; 12V/1.5A [18W Max] AC Charge Input...
