Summary of Contents for Chauvet Professional REMMIRA
- Page 1 Installation Guide Model ID: REMMIRA Model ID: REMMIRASQ...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Before You Begin ............... What Is Included.................. Claims....................Text Conventions................. Symbols....................Safety Notes ..................FCC Statement of Compliance ..............Expected LED Lifespan ............... 2. Introduction ................Product Overview ................REM MIRA LED Module Insertion and Removal......... Removing a Module................. -
Page 3: Before You Begin
1. Before You Begin What Is Included REM MIRA • 1 REMMIRA 1000X500 mm • IEC power linking cable • 8 REMMIRA LDM (packaged separately) • Installation Guide • Ethernet RJ45 linking cable REM MIRA SQ • 1 REMMIRA 500X500 mm •... -
Page 4: Safety Notes
Before You Begin Safety Notes Read all the following safety notes before working with this product. These notes contain important information about the installation, usage, and maintenance of this product. This product contains no user-serviceable parts. Any reference to servicing in this User Manual will only apply to properly trained, certified technicians. -
Page 5: Fcc Statement Of Compliance
Before You Begin FCC Statement of Compliance This device complies with Part 15 Part B of the FCC rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. -
Page 6: Introduction
Introduction 2. Introduction Product Overview Alignment Alignment screws Knockout conical Mounting holes screws conical screw Test button Receiver cards Power in screw Power supply Power out Knockout screw Pass-through channels Pass-through channels All screws on the REM MIRA are captive screws. REM MIRA Installation Guide Rev. -
Page 7: Rem Mira Led Module Insertion And Removal
Introduction REM MIRA LED Module Insertion and Removal Inserting a Module To insert an LED module onto the REM MIRA: 1. Identify where on the REM MIRA the module will be placed. 2. Carefully align the magnets on the back of the module with the magnets on the cabinet. Ensure that the arrows on the module match the orientation of the arrows on the cabinet. -
Page 8: Removing A Module
Introduction Removing a Module When removing a module from the REM MIRA, it is necessary to use an MT-07 tool. To remove an LED module from the REM MIRA: 1. Identify which module needs to be removed. 2. Using an MT-07 tool, hold down the trigger to activate and gently press the MT-07 against the module to firmly grip it. -
Page 9: Removing And Replacing The Led Masks
Introduction 3. With the module gripped, gently pull the module away from the cabinet. • For further information on the MT-07 tool, see Chauvetprofessional.com/mt-07/ • Use caution when removing the module so as not to cause damage. • Modules are universal and will fit anywhere on the frame. WARNING! The magnets on the modules are very powerful! Keep fingers clear when installing. - Page 10 Introduction 2. Using a fingertip, gently lift the edges of the mask off of the LEDs. • Take SPECIAL CARE to not pry off any LEDs! • DO NOT use prying tool to remove the LED mask! Doing so may damage the LEDs. •...
-
Page 11: Setup
Setup 3. Setup AC Power The REM MIRA has an auto-ranging power supply and can work with an input voltage range of 100-240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 12: Mounting
Mounting 4. Mounting Orientation Each REM MIRA is constructed of aluminum. This ensures the cabinet is stable and easy to install. The cabinet also has alignment conicals on the top and side of the product. The REM MIRA is front service only and should be installed on a flat wall. The product cannot be hanged from a truss. -
Page 13: Flat Wall Installation
Mounting Flat Wall Installation Refer to the following diagrams for flat wall installation. Mounting Points on a Flat Wall At least 1 mounting point for every junction (circled) must be secured, including outside edges and corners The mounting holes are intended for flush mount installation to a flat surface against the video panels. -
Page 14: Flat Wall Installation
Mounting Flat Wall Installation When mounting to a flat wall, follow the diagram below: Washer M10 Bolt Steel Strut Module Strut nut REM MIRA Installation Guide Rev. 1... -
Page 15: Joining Each Rem Mira
Joining Each REM MIRA 5. Joining Each REM MIRA Vertically Joining the Panels Once the REM MIRA is mounted, it can be easily joined vertically to another REM MIRA using the 2 screws located at the top of each panel. Alignment Screw conicals... -
Page 16: Vertical Panel Connection
Joining Each REM MIRA Vertical Panel Connection Use the following instructions to join panels vertically: 1. Line up the alignment conicals and screws at the top of each panel with the corresponding holes on the bottom of the other panel. 2. -
Page 17: Connecting & Cabling Each Rem Mira
Connecting & Cabling Each REM MIRA 6. Connecting & Cabling Each REM MIRA Testing Signal and Power Connections Each REM MIRA cabinet has 2 power sockets and 2 signal ports. The following table outlines each of the indicator functions. Indicator Color Status Description... -
Page 18: Rem Mira Knockouts
Connecting & Cabling Each REM MIRA REM MIRA Knockouts Knockout Dimensions 1.4 in 36 mm 1.4 in 35 mm 0.2 in 4 mm When removing knockouts, do not use a tool that exceeds the width of the knockouts on the REM MIRA. Failure to do so may damage the product. Removing Knockouts The REM MIRA has two knockouts for additional cabling options. - Page 19 Connecting & Cabling Each REM MIRA 2. Locate the knockout’s attachment points. Each knockout has attachment points -small tabs that connect the knockout to the enclosure. 3. Facing the back of the cabinet, place the tip of a flat-head screwdriver on one of the attachment points.
-
Page 20: Connecting Power And Signal Cables
Connecting & Cabling Each REM MIRA Connecting Power and Signal Cables The following sections provide information and diagrams on connecting signal and power between panels. Refer to the Introduction section in this User Manual for available cables and item numbers. Connecting the Signal Between Joined Panels Signal cable panel connections can use several different configurations. -
Page 21: Signal Chain Rectangles
Connecting & Cabling Each REM MIRA Signal Chain Rectangles When panels are assembled together to output video from a Novastar MX40 Pro, they form horizontal rows and vertical columns in rectangular arrangements. Each port of one of the Novastar MX40 Pro driver can support multiple REM MIRA panels. If the amount of panels used exceeds the maximum, more than 1 output port from the Novastar MX40 Pro will be required. -
Page 22: Connecting The Power Between Joined Panels
Connecting & Cabling Each REM MIRA Connecting the Power Between Joined Panels Power cable panel connections can also use different configurations. The basic configuration to connect the main power supply from one panel to the next is: 1. The main power is connected to the first panel’s Power Input or Output. 2. -
Page 23: Contact Us
Contact Us Contact Us General Information Technical Support Chauvet World Headquarters Address: 3360 Davie Rd., Suite 509 Voice: (844) 393-7575 Davie, FL 33314 Fax: (954) 756-8015 Voice: (954) 577-4455 Email: chauvetcs@chauvetlighting.com Fax: (954) 929-5560 Toll Free: (800) 762-1084 Website: www.chauvetprofessional.com Chauvet Europe Ltd Address: Pod 1 EVO Park Email:...
