LCD Monitor
Q27P3QW
WARNING
This disassembly information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or
repair the product or products dealt with in this disassembly information by anyone else could result in serious injury or death.
Advertisement
Related Manuals for AOC Q27P3QW
Summary of Contents for AOC Q27P3QW
- Page 1 LCD Monitor Q27P3QW WARNING This disassembly information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
- Page 2 Content Index General Safety Instructions ............................1 1. General Guidelines ..............................1 2. Important Notice ..............................1 3. How to Read this Instruction ..........................3 Exploded view diagram with list of items ........................5 Disassembly SOP ..............................6...
- Page 3 General Safety Instructions 1. General Guidelines When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
- Page 4 2-6 Safety Check after Repairment Confirm that the screws, parts and wiring which were removed in order to service are put in the original positions, or whether there are the positions which are deteriorated around the serviced places serviced or not.
- Page 5 2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly. 3. Use only a grounded-tip soldering iron to solder or unsolder ES devices. 4.
- Page 6 Warning: A “warning” is used when there is danger of personal injury. Reference: A “reference” guides the reader to other places in this binder or in this manual, where he/ she will find additional information on a specific topic.
- Page 7 Exploded view diagram with list of items...
- Page 8 Disassembly SOP 1. Suggest Tools Here are some tools that can be used for the LCD monitor’s service and repair. Philips-head Screwdriver Use a Philips-head screwdriver to fasten/remove the K- or B-typed screws P/N：N/A Gloves To protect LCD Panel and your hand P/N: (L) N/A (M) N/A C/D Disassembly Tool Use C/D Disassembly Tool to open cosmetic cover and avoid scratch.
- Page 9 2. Disassembly Procedures 1. Place the monitor face down on a smooth surface, while keeping the release button pressed, tilt the base and slide it out. 2. Remove screws.
- Page 10 3. Use disassembly tool to open all the latches along the edge of rear cover. 4. Throw the rear cover from one side, then take off the tape and disconnect the connector.
- Page 11 5. Remove the rear cover, then take off all of the tapes and disconnect the connectors. 6. Remove screws to get USB board.
- Page 12 7. Remove the screws. 8. Throw the main frame from one side, take off the tape and disconnect the connectors. Then remove the main frame.
- Page 13 9. Remove screws. 10. Get panel and middle frame.
- Page 14 11. Remove screws.
- Page 15 12. Get webcam module. 13. Remove Mylar.
- Page 16 14. Remove screws to get boards.
