Page 2
To Users Thank you for selecting Gree product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product and achieve...
Page 4
Zone Control Interface LE60-13/GH 1 Safety Notices (Please be sure to abide) WARNING: If not abide them strictly, it may cause severe damage to the unit or the people. NOTE: If not abide them strictly, it may cause slight or medium damage to the unit or the people.
Page 5
Zone Control Interface LE60-13/GH 2 Product Composition The product contains the following parts, please check before installation. Table 2.1 Accessories list Parts name Quantity Purpose Power Adapter Supply power for zone control interface Send and receive the signal of RF remote...
Page 6
Zone Control Interface LE60-13/GH 3 Appearance statement Figure 3-1 Appearance of zone control interface...
Page 7
Zone Control Interface LE60-13/GH Figure 3-2 Zone control interface introduce Table 3.1 Interface statement Port name Purpose Power Power input Zone Damper(1-8) Air valve port in each area (8 at most)
Page 8
Zone Control Interface LE60-13/GH Port name Purpose Antenna Antenna port Button1~ Button2 Reserved Extension Extended function port Wired Remote Wired remote controller communication port Controller1~2 WiFi Module WiFi module communication port Communication port for U-MATCH duct unit with RS485 RS485 communication type...
Page 9
Zone Control Interface LE60-13/GH (5) Whether it can be paired with a regional controller depends on the specific model. If you have any questions about model matching, you can consult technical support for assistance. 4 Function 4.1 Function Overview Zone control interface is a component of area control system. Its function is to...
Page 10
Zone Control Interface LE60-13/GH 5 Product Installation 5.1 Size Figure 5-1 Zone control interface size (unit: mm) Table 5.1 Size value Name Length...
Page 11
Zone Control Interface LE60-13/GH 5.2 Installation Requirement (1) Don’t install the product in a wet place or a place easy to splash. (2) Don’t install the product in a place near high-temperature objects or a place with direct sunshine. (3) Indoor installation is suggested. Suggested working temperature range for installation is 0~50℃.
Page 12
Zone Control Interface LE60-13/GH RS485 port of zone control interface; if it is a big duct type unit or U-MATCH duct unit with Power line communication type, lead H1 and H2 of wiring board of indoor unit to the HBS port of zone control interface.
Page 13
Zone Control Interface LE60-13/GH (3) Twist the standard antenna to the Antenna port of zone control interface and make sure it is firm. The ambient of zone control interface shall be spacious and with good transmission signal, the antenna direction can be adjusted by rotation.
Page 14
Zone Control Interface LE60-13/GH Figure 5-4 Vertical installation diagram (5) Confirm the number of air valve used based on actual usage condition, then connect the RJ11 port of each air valve to the RJ11 socket of zone control interface Zone Damper (1-8).
Page 15
Zone Control Interface LE60-13/GH Error name/ Solutions phenomenon 1. Check if the damper motor is blocked by any obstacle, to ensure there is no mechanical error in the damper; Zone temperature 2. Check the installation position of RF remote controller...
