British General SBS52 Technical Data

Technical Data
13 Amp Fused Connection Units
Brief product description:
The Brushed Stainless Steel range of screwed
flat-plate is suitable for domestic and commercial
applications.
Supplied with optional flex-outlet.
Product Images
SBS52 SBS54
Technical Specifications
Standard(s)
Rating
Switch type
Contact Gap
Terminal Capacity
RoHS Directive
WEEE Directive
Mounting Box Depth(Min)
Fixing Centres
Size
Weights & Dimensions
Cat No. Description
Each
SBS52 13A SW FCU + LED
SBS54 13A USW FCU
Packaging Information
Cat No. Description
Individual
SBS52 13A SW FCU + LED 5050765005869
BS 1363 Part 4
13 Amp 250V~
Double pole
3.0mm minimum
3 x 2.5mm² 2 x 4.0mm² 1 x 6.0mm²
No
No
35mm
60.3mm
87.4mm x 87.4mm x 28.8mm
Pack Quantity
Dimension (W x L x H) cm
Inner Outer
Product
Box Box
3.3 x 9 x 9.2
1 10 100
3.3 x 9 x 9.2
1 10 100
Barcode
Inner Box Outer Box
/ /
Features:
• Manufactured to BS 1363 part 4
• Angled colour coded terminals with captive screws
• Minimum mounting box depth 35mm
• Terminal capacity 3 x 2.5mm², 2 x 4.0mm²
& 1 x 6.0mm²
Weight (g)
Inner Box Outer Box Each
20 x 18 x 9.8 41.5 x 52.5 x 19 188
20 x 18 x 9.8 41.5 x 52.5 x 19 187.4
Cat No. Description
Individual
SBS54 13A USW FCU 5050765005883
CMB (m 3 )
Inner Outer Outer Box
Box Box
1980 20586 0.060024
1974 20526 0.060024
Barcode
Inner Box Outer Box
/ /
