ETT McPower Flair Manual

EN:
TECHNICAL DETAILS: • Flush-mounted toggle switch with flat rocker • 250V~/10A • without frame • WxHxD: 80x80x40mm •
SAFETY INSTRUCTIONS: Keep the operating instructions for the appliance in a safe place. Check the appliance regularly for
damage. Do not modify the product or accessories. Do not insert any objects into connection sockets. The product is not
suitable for outdoor use. Do not short-circuit the connections. Only use the product if it is in perfect condition. Never operate a
defective device! The appliance must not be modified in any way. Risk of electric shock and accident! Keep the appliance away
from moisture and humidity. Avoid extreme loads such as extreme heat or cold, moisture, microwaves, mechanical pressure and
vibrations. Avoid overloading the socket : Do not connect several high-current devices at the same time. Overloaded sockets can
lead to overheating and a fire hazard. Disconnect the mains power supply before connecting. Electrical work, installation
and repairs may only be carried out by qualified electricians. Avoid inserting metal objects or fingers into the socket
to prevent a short circuit or electric shock - DANGER TO LIFE! Only wipe the appliance with a soft, dry cloth. Never use
scouring powder or chemical cleaning agents. Electrical components must not come into contact with moisture. Do not kink,
crush, pinch or otherwise damage the cables. If you have any questions, defects, mechanical damage or other problems, please
contact the dealer or manufacturer. If you have any doubts about the safety of the socket or if it is not working properly, have
it checked by a qualified electrician and repaired if necessary. The product is not a toy and does not belong in the hands of
children! Please note that the product, packaging, plastic film / bags, polystyrene parts, etc. are not suitable for children. Small
parts and insulating material can become a dangerous toy for children and pose a hazard.
1. Switch off the fuse and check that there is no voltage. 2. Strip approx. 10 mm of insulation from the wire ends. 3. Remove the
cover. 4. The connections are labeled „L1" and „X1". 5. Screw the wires into the screw terminals as described in the sketch below.
Ensure no wires are improperly clamped and that no strands are protruding or overlapping. 6. Insert the switch into the flush-
mounted box and tighten the mounting claws. 7. Place the frame over the installed light switch and snap the switch rocker
DISPOSAL INSTRUCTIONS:
making an important
of charge in accordance
European WEEE Directive, electrical and electronic appliances may not be disposed of with household waste.
Their components must be recycled or disposed of separately, as toxic and hazardous components can cause lasting damage
to health and the environment if disposed of improperly. As a consumer, you are obliged under the German Electrical and
Electronic Equipment Act (ElektroG) to return electrical and electronic equipment free of charge at the end of its life to the
manufacturer, the point of sale or to public collection centres set up for this purpose. Details are regulated by the respective
state law. The wheeled bin symbol on the product, operating instructions and/or packaging indicates these regulations.
DOC
1534803
1535789
Item number: 1534800
Toggle switch McPower „FLAIR"
250V~/10A, flush-mounted, white
suitable for hollow wall boxes with 68mm Ø
1534800
1535786
1534755
By separating, recycling
contribution to protecting
with local regulations
Made by ETT Distribution GmbH, Schmalbachstraße 16, 38112 Braunschweig
ASSEMBLY
onto the switch.
and disposing of
our environment. Packaging
at the appropriate
DE: Eine mehrsprachige Version dieser Anleitung und die
Konformitätserklärung finden Sie unter folgendem Link:
EN: A multilingual version of this manual and the Declaration of
Conformity can be found at the following link:
FR: Vous trouverez une version multilingue de ce manuel et la
déclaration de conformité sur le lien suivant:
ES: Encontrará una versión multilingüe de estas instrucciones y de
la declaración de conformidad en el siguiente enlace:
http://ettgroup.de/product/1534800
1535812
1535813
1534802
1535788
1534757
old appliances in this
can be disposed
collection centres. According
1534801
1535787
1534756
way, you are
of free
to the
