Summary of Contents for Hall Technologies HT-OSIRIS-DSP1
- Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com HT-OSIRIS-DSP1 Digital Signal Processor USER MANUAL March 26, 2024 Hall Technologies March 26, 2024 Page 1 of 19...
-
Page 2: Table Of Contents
Audio Mode ........................14 Ducking ..........................14 System Tab ............................ 16 Device Info & Firmware Update ..................16 Login & System ........................17 API Command List ............................. 17 Specifications ............................18 Hall Technologies March 26, 2024 Page 2 of 19... -
Page 3: Introduction
Safety is of paramount importance in any learning environment. The HT-COMALERT wireless microphone, a complementary addition to the HT-OSIRIS-DSP1 system, isn't just a microphone – it's a lifeline. For educators and students alike, the S.O.S. feature takes center stage, offering a quick and reliable way to summon assistance in case of emergencies. -
Page 4: Package Contents
• Provides flexible control options using Web UI and API commands. Package Contents • 1 x HT-OSIRIS-DSP1 Digital Signal Processor • 1 x DC 12V Power Adapter (with US, UK, EU & AU pins) • 1 x 3-Pin Phoenix Male Connector •... -
Page 5: Panel Description
Connect to a RS232 device for bidirectional serial communication Ports for signals from/to a third-party control system. Input modes: contact closure or ALARM IN / OUT voltage input (3.3V ~ 5A). Output modes: contact closure or 5V voltage. Hall Technologies March 26, 2024 Page 5 of 19... -
Page 6: Installation
1. Position and install the mounting brackets (two at each side) using the mounting screws provided. 2. Repeat above step for the other side of the device. 3. Attach the brackets to the desired location. Hall Technologies March 26, 2024 Page 6 of 19... -
Page 7: Application Wiring
Application Wiring There are various different application methods with wiring examples; two are shown below. INTEGRATION WITH HT-TRK1 INTEGRATION WITH DISCOVERY Hall Technologies March 26, 2024 Page 7 of 19... -
Page 8: Soft Codec Support
The following are instructions to utilizing the HT-OSIRIS-DSP1 camera and microphones in the Google Meet, Microsoft Teams, and Zoom soft codec applications. The HT-OSIRIS-DSP1 is not limited to these three. (For soft codec applications outside of these three please refer to their user manual.) GOOGLE MEET To use the devices in Google Meet, open “More Options”... -
Page 9: Microsoft Teams
MICROSOFT TEAMS To use the devices in Microsoft Teams, open Device Settings located in the “More” menu. In the video settings, select the “HT-OSIRIS-DSP1” for the camera and in the audio settings select “HT-OSIRIS-DSP1” for both microphone and speaker. Hall Technologies... -
Page 10: Zoom
To use the devices in Zoom, click on the “up” arrow on the microphone and camera buttons located on the bottom left part of the Zoom screen. In the video settings, select the “HT-OSIRIS-DSP1” for the camera and in the audio settings select “HT-OSIRIS-DSP1” for both microphone and speaker. -
Page 11: Web Gui
Web GUI The Web UI designed for the HT-OSIRIS-DSP1 allows for basic controls and device settings. This Web UI can be accessed through a modern browser, e.g., Chrome, Safari, Firefox, IE10+, etc. To get access the Web UI: Connect the LAN port of the switcher to a local area network. The default IP address of the HT- OSIRIS-DSP1 is 192.168.10.254. -
Page 12: Ip Settings Tab
IP Settings Tab IP SETTINGS UI Element Description IP Method Select DHCP or Static (default) IP Settings Set the IP address, subnet, and gateway (in Static mode). Apply Click to apply the settings. Hall Technologies March 26, 2024 Page 12 of 19... - Page 13 Select the external alarm trigger mode between contact closure and voltage input (3.5 V ~ Alarm in Mode 5V). Apply Click to apply setting changes. S.O.S. Log Contains the log of all triggered events. Hall Technologies March 26, 2024 Page 13 of 19...
-
Page 14: Audio Tabe
Audio Tab AUDIO MODE The HT-OSIRIS-DSP1 includes three input channels and two output channels, among which there are three groups of mutually exclusive options between USB Host and AEC Ref, between WL IN and Wireless Receiver, and between USB Host or AEC out. -
Page 15: Ducking
-20dB. Sets the level at which the master microphone is used to trigger ducking. The lower the Ducking Trigger value set, the easier the ducking is triggered. Default setting is -30dB. Hall Technologies March 26, 2024 Page 15 of 19... -
Page 16: System Tab
Set the system time for accurate log readings. Note, with a power cycle this resets to System Time default factory clock setting. Upgrade Select the firmware file for the desired device to be upgraded. Hall Technologies March 26, 2024 Page 16 of 19... -
Page 17: Login & System
Perform a factory reset, reboot the device, or export the log. API Commands Additional commands not found in the Web GUI such as AEC enable/disable, AGC enable/disable, ANC enable/disable, and others can be found in the HT-OSIRIS-DSP1 API Commands document. Hall Technologies March 26, 2024... -
Page 18: Specifications
Power Supply DC 12V 2A Power Consumption (Max) 10.1W (Max) Dimension (Width x Heigh x Depth) 8.46” x 0.98” x 4.73” (215mm x 25mm x 120.2mm) Net Weight 1.52 lbs. (0.69 kgs) Hall Technologies March 26, 2024 Page 18 of 19... - Page 19 © Copyright 2023. Hall Technologies All rights reserved. 1234 Lakeshore Drive, Suite #150, Coppell, TX 75019 halltechav.com / support@halltechav.com (714)641-6607 Hall Technologies March 26, 2024 Page 19 of 19...
