Summary of Contents for BenQ MP722

Page 1 trusted dependable most name projector lamp sales. http://www.myprojectorlamps.com http://www.myprojectorlamps.ca http://www.myprojectorlamps.eu The following projector manual has not been modified or altered in any way.
Page 2 MP722/MP723 Digital Projector User Manual Welcome...
Page 3 Table of contents Important safety Operating in a high altitude environment .........43 instructions ......3 Creating your own startup screen ..43 Introduction......7 Adjusting the sound......44 Personalizing the projector menu Projector features ........7 display ...........44 Shipping contents........8 Shutting down the projector ....45 Projector exterior view ......
Page 4 Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before you Always open the lens shutter or...
Page 5 Safety Instructions (Continued) The lamp becomes extremely hot Do not place this product on an during operation. Allow the unstable cart, stand, or table. The projector to cool for approximately product may fall, sustaining serious 45 minutes prior to removing the damage.
Page 6 Safety Instructions (Continued) Do not place this projector in any of the Do not block the ventilation holes. following environments. - Do not place this projector on a blanket, bedding or any other soft surface. - Space that is poorly ventilated or confined. - Do not cover this projector with a cloth or Allow at least 50 cm clearance from walls any other item.
Page 7 If you intend to mount your projector on the ceiling, we strongly recommend that you use a proper fitting BenQ projector ceiling mount kit and that you ensure it is securely and safely installed.
Page 8 Introduction Projector features The projector integrates high-performance optical engine projection and a user-friendly design to deliver high reliability and ease of use. The projector offers the following features. • Wall color correction allowing projection on surfaces of several predefined colors •...
Page 9 Shipping contents The projector is shipped with the cables required for connection to a PC or video equipment. Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated.
Page 10 Projector exterior view Lamp cover Front/upper side Vent (heated air exhaust) Lens sliding door Quick-release button External control panel (See "Projector" on page 10 for details.) Focus ring and Zoom ring Vent (cool air intake) Front IR remote sensor Projection lens AC power cord inlet Kensington anti-theft lock slot...
Page 11 Controls and functions Projector Left/ Starts the FAQ function. See "Utilizing FAQ function" on page 42 for details. BLANK Used to hide the screen image. See "Hiding the image" on page 41 for details. LAMP indicator light Indicates the status of the lamp. Lights up or flashes when the lamp has developed a problem.
Page 12 Remote control Keystone/Arrow buttons ( / Up, Down) Manually corrects distorted images resulting from an angled projection. See "Correcting keystone" on page 33 details. MENU/EXIT Turns on the On-Screen Display (OSD) menu. Goes back to previous OSD menu, exits and saves menu settings. See "Using the menus"...
Page 13 Indicator light D. ZOOM (+, -) Flashes or lights red when any key on the Magnifies or reduces the projected image remote control is pressed. size. See "Magnifying and searching for MODE details on the projected picture" on page 33 for details.
Page 14 Remote control effective range Infra-Red (IR) remote control sensors are located on the front and the back of the projector. The remote control must be held at an angle within 30 degrees perpendicular to the projector's IR remote control sensors to function correctly. The distance between the remote control and the sensors should not exceed 8 meters (~ 26 feet).
Page 15 Select this location with the projector suspended upside-down from the ceiling behind the screen. Note that a special rear projection screen and the BenQ Projector Ceiling Mounting Kit are required for this installation location. Set Rear Ceiling in the SYSTEM SETUP: Basic >...
Page 16 BenQ has provided a table of 4:3-aspect-ratio screen sizes to assist you in determining the ideal location for your projector. There are two dimensions to consider, the perpendicular horizontal distance from the center of the screen (projection distance), and the vertical offset height of the projector from the horizontal edge of the screen (offset).
Page 17 How to determine the position of the projector for a given screen size Select your screen size. Refer to the table and find the closest match to your screen size in the left columns labelled "4:3 screen diagonal". Using this value, look across this row to the right to find the corresponding average distance from screen value in the column labelled "Average".
Page 18 11667 12222 There is 3% tolerance among these numbers due to optical component variations. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics.
Page 19 Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...
Page 20 The final connection path should be like that shown in the following diagram: notebook or desktop computer i. VGA cable ii. VGA to DVI-A cable iii. Audio cable iv. USB cable Many notebooks do not turn on their external video ports when connected to a projector. Usually a key combo like FN + F3 or CRT/LCD key turns the external display on/off.
Page 21 Connecting a monitor If you want to view your presentation close-up on a monitor as well as on the screen, you can connect the D-SUB OUT signal output socket on the projector to an external monitor with a VGA or VGA to DVI-A cable by following the instructions below. To connect the projector to a monitor (either through a VGA cable or VGA to DVI-A cable): •...
Page 22 Connecting Video source devices This section describes how to connect the projector to Video source devices using video cables. Video cable connections are recommended for Video presentations. You can connect your projector to various Video source devices that provide any one of the following output sockets: •...
Page 23 Connecting a DVI source device The projector provides a DVI input socket that allows you to connect it to a DVI source device like a DVD player, or a VGA output device like a notebook or desktop computer. There are three types of DVI connectors: DVI-A, DVI-D, and DVI-I. The DVI-I socket is an integrated connector which supports both formats: DVI-A, and DVI-D.
Page 24 In the unlikely event that you connect the projector to a DVD player via the projector’s DVI-D input and the projected picture displays wrong colors, please change the color space to YUV. "Changing Color Space" on page 31 for details. Connecting a Component Video source device Examine your Video source device to determine if it has a set of unused Component Video output sockets available:...
Page 25 Connecting an S-Video source device Examine your Video source device to determine if it has an unused S-Video output socket available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to an S-Video source device: Take an S-Video cable and connect one end to the S-Video output socket of the Video source device.
Page 26 Connecting a composite Video source device Examine your Video source device to determine if it has a set of unused composite Video output sockets available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to a composite Video source device: Take a Video cable and connect one end to the composite Video output socket of the Video source device.
Page 27 Operation Starting up the projector Plug the power cord into the projector and into a wall socket. Turn on the wall socket switch (where fitted). Check that the Power indicator on the projector lights orange after power has been applied. Slide the lens cover open.
Page 28 Auto Power Off Disable Digital Zoom Disable Blank Timer Panel Key Lock Timer Controller Disable Splash Screen BenQ My Screen Analog RGB MENU Exit Analog RGB MENU Exit Press MENU/EXIT twice* on to highlight the SYSTEM the projector or remote control SETUP: Basic menu.
Page 29 Securing the projector Using a security cable lock The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as Kensington lock, to secure the projector. You can locate a Kensington lock slot on the rear side of the projector.
Page 30 Setting a password Once a password has been set and the power on lock is activated, the projector cannot be used unless the correct password is entered every time the projector is started. Once a password has been set and the splash screen lock is activated, you cannot change the splash screen that displays at projector startup unless the correct password is entered.
Page 31 Please write down the recall code, number and turn off your projector. Seek help and contact BenQ from the local BenQ service center to decode the Customer Center. number. You may be required to provide proof of 0 2 1 2...
Page 32 Though the password function is disabled, you need to keep the old password in hand should you ever need to re-activate the password function by entering the old password. Switching input signal The projector can be connected to multiple devices at the same time. However, it can only display one full screen at a time.
Page 33 Adjusting the projected image Adjusting the projection angle The projector is equipped with 1 quick-release adjuster foot and 1 rear adjuster foot. These adjusters change the image height and projection angle. To adjust the projector: Press the quick-release button and lift the front of the projector.
Page 34 Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. To correct this, besides adjusting the height of the projector, you will need to manually correct it following ONE of these steps.
Page 35 Press repeatedly to magnify the picture to a desired size. To navigate the picture, press Mode/enter to switch to the paning mode and press the directional arrows ( , ) on the projector or remote control to navigate the picture. To reduce size of the picture, press Mode/enter to switch back to the zoom in/out function, and press AUTO to restore the picture to its original size.
Page 36 Real: The image is projected as its original resolution, and resized to fit within the display area. For input signals with lower resolutions, the projected image will display smaller than if resized to full screen. You could adjust the zoom setting or move the projector towards the screen to increase the image size if necessary.
Page 37 YPbPr/S-Video/Video/HDCP Signal Input Dynamic mode: Is suitable for playing gamebox-based video games in a normal living room lighting level environment. Standard mode (Default): Is appropriate for viewing colorful movies, video clips from digital cameras or DVs. Cinema mode: Is suitable for enjoying dark movies or DVD movies best viewed in a blackened (little light) home cinema or lounge room environment.
Page 38 Adjusting Color Highlight Color in the PICTURE menu and adjust the values by pressing on the projector or remote control. Lower setting produces less saturated colors. If the setting is too high, colors on the image will be overpowering, which makes the image unrealistic. Adjusting Tint Highlight Tint in the PICTURE menu and adjust the values by pressing on the...
Page 39 3D Color Management In most installation situations, color management will not be necessary, such as in classroom, meeting room, or lounge room situations where lights remain on, or where building external windows allow daylight into the room. Only in permanent installations with controlled lighting levels such as boardrooms, lecture theaters, or home theaters, should color management be considered.
Page 40 Press to highlight Gain and adjust its values to your preference by pressing The contrast level of the primary color you select will be affected. Every adjustment made will reflect to the image immediately. Repeat steps 3 to 6 for other color adjustments. Make sure you have made all of the desired adjustments.
Page 41 To activate the presentation timer, press NOTICE press to highlight On and press Mode/ Are you sure to turn on the enter. presentation timer? A confirmation message displays. Highlight Yes and press Mode/enter on the projector or ENTER on the remote control to confirm. You will see the message “Timer is On”...
Page 42 Hiding the image In order to draw the audience's full attention to the presenter, you can use BLANK on the projector or remote control to hide the screen image. The word 'BLANK' appears in the corner of the screen while the image is hidden.
Page 43 Utilizing FAQ function The INFORMATION menu contains possible solutions to problems encountered by users regarding image quality, installation, special feature operation and service information. To get the FAQ information: Press on the projector or remote control or press MENU/EXIT to open the OSD menu and press to highlight the INFORMATION menu.
Page 44 Creating your own startup screen In addition to selecting the projector preset startup screen from among BenQ logo, Black or Blue screen, you can make your own startup screen that is a picture projected from your computer or video source.
Page 45 Adjusting the sound The sound adjustments made as below will have an effect on the projector speaker. Be sure you have made a correct connection to the projector audio input. See "Connection" on page for how the audio input is connected. Muting the sound To temporarily turn off the sound, Press MENU/EXIT and then press...
Page 46 Shutting down the projector Press Power and a confirmation message will display prompting you. If you don't respond in a few seconds, the message will disappear. Press Power a second time. The Power indicator light flashes orange, the projection lamp shuts down, and the fans will continue to run for approximately 90 seconds to cool down the projector.
Page 47 Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. Main menu Sub-menu Options Off/Light Yellow/Pink/Light Wall Color Green/Blue/Blackboard Aspect Ratio 4:3/16:9/Auto/Real Keystone DISPLAY Position Phase H. Size Digital Zoom PC source: Dynamic/Presentation/sRGB/Cinema/ User 1/User 2 Picture Mode Video source: Dynamic/Standard/Cinema/User 1/...
Page 48 Disable/5 min/10 min/15 min/20 Blank Timer min/25 min/30 min Panel Key Lock On/Off Disable/30 min/1 hr/2 hr/3 hr/4 Timer Controller hr/8 hr/12 hr Splash Screen BenQ/Black/Blue/My Screen My Screen Quick Cooling On/Off High Altitude Mode On/Off Mute On/Off Volume Audio Settings...
Page 49 DISPLAY menu FUNCTION DESCRIPTION (default setting/ value) Correct the projected picture’s color when the projection surface is not Wall Color white. See "Using Wall Color" on page 35 for details. (Off) There are four options to set the image's aspect ratio depending on your Aspect Ratio input signal source.
Page 50 PICTURE menu Some picture adjustments are available only when certain input sources are in use. Unavailable adjustments are not shown on the screen. FUNCTION DESCRIPTION (default setting / value) Pre-defined picture modes are provided so you can optimize your Picture Mode projector image set-up to suit your program type.
Page 51 Controller (Disable) Allows you to select which logo screen will display during projector start- Splash up. Four options are available: BenQ logo, Black screen, Blue screen or My Screen Screen. (BenQ logo) Captures and stores the projected picture as My Screen. See "Creating your...
Page 52 SYSTEM SETUP: Advanced menu FUNCTION DESCRIPTION (default setting / value) Enables or disables the Quick Cooling function. Selecting On enables the Quick function and projector cooling time will be shortened from a normal 90- Cooling second duration to approximately 30 seconds. (On) A mode for operation in high altitude areas.
Page 53 INFORMATION menu This menu shows you the current operating status of the projector. Some picture adjustments are available only when certain input sources are in use. Unavailable adjustments are not shown on the screen. FUNCTION DESCRIPTION FAQ-Image and Installation Displays possible solutions to problems you may encounter. FAQ-Features and Service Source...
Page 54 Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.
Page 55 Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. The method of calculating the equivalent lamp hour is as follows: Total (equivalent) lamp hour = 1 (hours used in Economic mode) + 4/3 (hours used in normal mode) "Setting Lamp Mode as Economic"...
Page 56 Timing of replacing the lamp When the Lamp indicator lights up red or a message appears suggesting it is time to replace the lamp, please install a new lamp or consult your dealer. An old lamp may cause a malfunction in the projector and in some instances the lamp may explode. The Lamp indicator light and Temperature warning light will light up if the lamp becomes too hot.
Page 57 • To assure optimal performance from the projector, it is recommended that you purchase a BenQ projector lamp for lamp replacement. • If lamp replacement is performed while the projector is suspended upside-down from the ceiling, make sure that no one is underneath the lamp socket to avoid any possible injury or damage to the human eyes caused by fractured lamp.
Page 58 Lift the handle so that it stands up. Use the handle to slowly pull the lamp out of the projector. • Pulling it too quickly may cause the lamp to break and scatter broken glass in the projector. • Do not place the lamp in locations where water might splash on it, children can reach it, or near flammable materials.
Page 59 Use a coin to turn the screw clockwise until the lamp cover is secured. • Loose screw may cause a bad connection, which could result in malfunction. • Do not over tighten the screw. Restart the projector. Do not turn the power on with the lamp cover removed. Resetting the lamp timer After the startup logo, open the On-Screen Notice...
Page 60 Indicators Light Status & Description Power Temp Lamp Power events The projector has just been connected to a power outlet or the Orange Orange Orange lamp door is open. Orange Stand-by mode. Green Powering up. Flashing Green Normal operation. The projector needs 90 seconds to cool down as it was abnormally shut down without the normal cooling down Orange process.
Page 61 Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC inlet on the There is no power from the power projector, and plug the power cord into the cable. power outlet. If the power outlet has a switch, make sure that it is switched on.
Page 62 Specifications Projector specifications All specifications are subject to change without notice. Optical Input terminals Resolution Computer input 1024 x 768 XGA RGB input D-Sub 15-pin (female) x 1 Display system DVI-I input 1-CHIP DMD Video signal input Lens F/Number S-VIDEO F=2.4 to 2.48, f= 20.7 to 22.8 mm Mini DIN 4-pin port x 1 Lamp...
Page 63 Dimensions 274.87 mm (W) x 131.30 mm (H) x 304.99 mm (D) 274.87 131.30 304.99 74.30 48.57 Specifications...
Page 64 Timing chart Supported timing for PC (including DVI-D) input Horizontal Vertical Pixel Resolution Frequency Frequency Frequency Mode (kHz) (Hz) (MHz) 31.469 59.940 25.175 VGA_60 37.861 72.809 31.500 VGA_72 640 x 480 37.500 75.000 31.500 VGA_75 43.269 85.008 36.000 VGA_85 720 x 400 720 x 400_70 31.469 70.087...
Page 65 Supported timing for Video and S-Video inputs Color sub- Horizontal Vertical carrier Video mode Frequency Frequency Frequency (kHz) (Hz) (MHz) NTSC 15.73 3.58 15.63 4.43 SECAM 15.63 4.25 or 4.41 PAL-M 15.73 3.58 PAL-N 15.63 3.58 PAL-60 15.73 4.43 NTSC4.43 15.73 4.43 Specifications...
Page 66 Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.
Page 67 Regulation statements FCC statement CLASS B: This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
