- Page 1 GL860 Quick Start Guide GL860-UM-800-7L...
- Page 2 First Thank you for choosing Graphtec midi LOGGER GL860. The Quick Start Guide is to assist with the basic operations. Please refer to the USER'S MANUAL (PDF) for more in-depth information. To make measurements using the GL860, the following terminal blocks are required in addition to the GL860 main unit.
- Page 3 About the User’s Manual and Included Software The user's manual and accompanying software are stored in the internal memory of the instrument. Please copy it from the internal memory to your computer. To copy, see the next section. When you initialize the internal memory, the bundled files are also deleted. Deleting the included files will not affect the operation of the instrument, but we recommend that you copy the files to your computer beforehand.
- Page 4 Nomenclature Top Panel Analog signal input terminals • Standard 20CH screw terminal (B-563) Power jack for humidity sensor • Standard 20CH screwless terminal (B-563SL) Humidity sensor • Standard 30CH screwless terminal (B-563SL-30) (Option: when using the B-530) • Withstand high-Voltage high-precision terminal (B-565) SD memory card GND terminal Wireless LAN...
- Page 5 Connection Procedures Mounting each terminal 1. Insert tabs at the top of the terminal unit into 2. Press the terminal unit in the direction the grooves. shown until it is securely locked. Insert into grooves Press Connecting the AC Adapter Connect the DC output of the AC adapter to the Use a flathead screwdriver to push the button above connector indicated as "DC LINE"...
- Page 6 Connect the External Input/Output Terminals < Signal assignment > Orange with red dotted line Orange with black dotted line : 2 Logic/pulse Grey with red dotted line input Grey with black dotted line White with red dotted line White with black dotted line Alarm output Yellow with red dotted line Yellow with black dotted line : 4...
- Page 7 Maximum input voltage If a voltage exceeding the specified value goes into the instrument, the electrical relay in the input will be damaged. Never input a voltage exceeding the specified value at any moment. Standard 20CH screw terminal(B-563) Standard 20CH screwless terminal(B-563SL) Withstand high-Voltage high-precision Standard 30CH screwless terminal(B-563SL-30) terminal(B-565)
- Page 8 Descriptions of the Control Panel Keys [Menu] Sequence •AMP Settings Set the input, range, filter, scaling, and other channel based settings. •Record Settings DATA Set sampling interval and data record destination. ENTER •Trigger Settings Password TRIG Set the specify recording start and stop setting conditions.
- Page 9 9. START/STOP (USB DRIVE MODE) 12. CURSOR (ALARM CLEAR) Push the [START/STOP] key to initiate start DISPLAYPress the [CURSOR] key to switch and stop of a recording when GL860 is in the between the A and B cursors during a data Free Running mode.
- Page 10 Descriptions of the Menu Screens : Displays the operating status. Status message display area Time/DIV display area : Displays the current time scale. : Displays the current sampling interval. Sampling interval display : Displayed in red when accessing the Device access Status icon internal memory.
- Page 11 : Displays the following icons to indicate AC/Battery status AC/Battery Indicator the operating status of the AC power indicator When the AC power and the battery. supply is being used Battery power: 100 - 91% Note: Use this indicator as a guideline Battery power: 90 - 71% because remaining battery power is an estimate.
- Page 12 SENSORS & CONTROLS Specifications are subject to change without notice. Deutschland Althen GmbH Meß- und Sensortechnik | Dieselstrasse 2 | 65779 Kelkheim, Deutschland Tel: + 49 (0)6195 - 70060 | Fax: + 49 (0)6195 - 7006 66 | info@althen.de | althen.de...
