Summary of Contents for Rugged Radios R1
- Page 1 USER MANUAL VERSION 1.0.2...
- Page 2 SAFETY Safety: This radio generates RF electromagnetic energy during transmit mode. This radio is designed for and classified as “Occupational Use Only,” meaning it must be used only during the course of employment by individuals aware of the hazards, and the ways to minimize such hazards. This radio is NOT intended for use by the “General Population”...
- Page 3 To program your radio and to access advanced features, visit rtsystemsinc.com or contact them at 800-921-4834...
- Page 4 CONTENTS User Safety Information Package Includes Charging Your Battery Pack Charging Preparation Charging Operation Accessories Connections Battery Pack Belt Clip Ext. Mic/Speaker Getting Acquainted Front Panel Operation Side Panel Operation Getting Acquainted Operation Menu Settings Expanded Messages Expanded Specifications General Transmitter Receiver Notes...
- Page 5 USER SAFETY INFORMATION • Please read the following brief instructions, non-compliance with these rules may cause danger or violate the law. • Obey the local government regulation before using this radio, improper use may violate the law and be punished. •...
- Page 6 Please check if any damage to the package when you receive it. Carefully unpack the transceiver. We recommend that you check the items listed in the following table. If any items are missing or damaged during shipment, please contact with your local dealer immediately. • R1 handheld radio • Antenna • Rechargeable Li-ion Battery •...
- Page 7 CHARGING YOUR BATTERY PACK CHARGING PREPARATION Precaution: The supplied battery pack of this radio is a high-performance Li-ion with 7.4V standard voltage 2000mAh high capacity in a very compact package. Under normal use, the battery pack may be used for approximately 500 charge cycles and more, after which operating time maybe expected to decrease.
- Page 8 CHARGING YOUR BATTERY PACK CHARGING OPERATION After installing the battery pack, if the battery icon shows [ ], it means that the battery pack is out of power. Please charge it. Charging indicator light conditions: Indicator Display Status Charging Green Completed Battery Tips •...
- Page 9 ACCESSORIES CONNECTIONS BATTERY PACK Align the two grooves of battery and the guide rail on the back of the aluminum shell, ensure full contact and in parallel, then push the battery up to the radio base along the rail on the back of the aluminum shell, until the battery latch locks up. To remove the battery, please make sure the radio is off, push the battery latch down, and make sure the radio and battery is on the releasing state, and then push the battery out from the radio.
- Page 10 GETTING ACQUAINTED FRONT PANEL OPERATION INDICATOR LIGHT VOLUME DUAL BAND ON/OFF ANTENNA FLASHLIGHT SPEAKER MICROPHONE LED DISPLAY UP/DOWN SELECT CONFRIM/SELECT BACK/EXIT CH. PRESET 2 CH. PRESET 1 FM MODE FLASHLIGHT LOCK/SPACE SETTINGS...
- Page 11 GETTING ACQUAINTED SIDE PANEL OPERATION DUAL BAND ANTENNA VOLUME ON/OFF PUSH ACCESSORY TO TALK PORT SIDE KEY 1 SIDE KEY 2 BELT CLIP RECHARGEABLE LITHIUM ION BATTERY BATTERY CHARGING PORT...
- Page 12 GETTING ACQUAINTED OPERATION CHANGING CHANNELS Use [ ] to scroll through the channels until you have reached your desired channel. To avoid accidental changes, always lock. PUSH-TO-TALK (PTT) Press it to transmit and release it to receive after your transmission is completed. 2-PIN MIC/ACCESSORY PORT The jack provides connection points for microphone input, audio output, and program cable.
- Page 13 GETTING ACQUAINTED OPERATION FM RADIO MODE Long-press [FM] to activate FM radio mode. Use [ ] to scroll through the channels until you have reached your desired channel. Quick-press [BACK] to exit FM radio mode. LOCK Long-press to lock and unlock the radio. P1 SETTING Channel 1 in active zone.
- Page 14 GETTING ACQUAINTED MENU Menu Item Function Operation Select your active Long-press [ ] to open menu. Use [ zone. to scroll to Zone and press [ OK ] to accept. Zone Selection Press [ OK ] to select On. Use [ ] to scroll to desired zone and press [ OK ] to accept.
- Page 15 GETTING ACQUAINTED MENU Menu Item Function Operation Access Radio Long-press [ ] to open menu. Use [ ] to Settings and Radio scroll to Setting and press [ OK ] to accept. Info. Use [ ] to scroll to Radio Settings, Setting for settings, or Radio Info, for firmware information.
- Page 16 GETTING ACQUAINTED SETTINGS EXPANDED Menu Item Function Operation When in the Settings menu, use Squelch system ] to scroll to Squelch and press [ allows you to mute to accept. Use the [ ] to scroll to the the background noise desired Squelch level and press [ ] to when no signal is being...
- Page 17 GETTING ACQUAINTED SETTINGS EXPANDED Menu Item Function Operation When in the Settings menu, use [ ] to Enable or disable scroll to Beeps and press [ OK ] to accept. tones. Select All Tone press [ OK ] to accept. Use Beeps ] to select On or Off and press [ OK ] to accept.
- Page 18 GETTING ACQUAINTED SETTINGS EXPANDED Menu Item Function Operation When in the Settings menu, use [ Adjust microphone to scroll to Mic Level and press [ OK ] to sensitivity. accept. Use [ ] to select the desired microphone sensitivity level and press [ OK ] to accept.
- Page 19 GETTING ACQUAINTED MESSAGES EXPANDED Menu Item Function Operation All recieved text messages When in the Messages menu, use will be stored here. ] to scroll to Inbox and press Inbox [ OK ] to accept. Write and send text When in the Messages menu, use messages.
- Page 20 GETTING ACQUAINTED MESSAGES EXPANDED Menu Item Function Operation All text messages saved When in the Messages menu, use as draft will be stored ] to scroll to Draft and press [ OK Draft here. ] to accept. When in the Messages menu, use Choose from ] to scroll to Quick Text and press pregrogammed text...
- Page 21 SPECIFICATIONS GENERAL Frequency Range 136-174 & 400-480MHz Operating voltage DC 7.4 V ±10% Operating temperature C to +40 Antenna Impedance 50Ω Duty cycle 5/5/90% TRANSMITTER RF Output Power ≤5 W /1W FM Modulation 11K0F3E@12.5KHz 7K60FXD@12.5KHz (Date only) 4FSK Digital Mode 7K60FXE@12.5KHz (Date +Voice) Spurious Emission -36dBm<1GHz , -30dBm>1GHz...
- Page 22 SPECIFICATIONS RECEIVER Receive Sensitivity 0.25μV (12dB SINAD) Channel spacing 12.5KHz Adjacent Channel Selectivity ≥55dB Inter Modulation and Rejection ≥55dB Conducted Spurious Emission ≤-57dB Rated Audio Power Output 1W @16 Ωs Rated Audio Distortion ≤5%...
- Page 23 NOTES...
- Page 24 WWW.RUGGEDRADIOS.COM...
