Ledvance Dual Selectable Slim Wall Pack Installation Manual

LEDVANCE
Luminaire Installation Guide
Dual Selectable Slim Wall Pack
The Dual Selectable Slim Wall Pack luminaires are environmentally
preferable LED alternatives to traditional HID or Incandescent
luminaires. Ideal in place of traditional luminaires, or as new
installations, it's offered in two selectable wattages and three
selectable CCT's for illuminating building exteriors, outdoor corridors,
walkways, and stairwells. Its adjustable angle also makes it versatile
for all lighting needs from cutoff to non cutoff. Its an all-in-one
luminaire to cover a variety of applications.
For warranty coverage, please register at www.ledvanceUS.com
Please Read All Instructions Before Attempting Installation
− RISK OF FIRE, EXPLOSION AND ELECTRIC SHOCK This product should be installed, inspected, and
maintained by a qualified electrician only, in accordance with the NEC and all local codes.
− Turn off electrical power before inspection, installation, or removal.
− Use only UL (or other NTRL) approved wire for input/output connections.
− Minimum size 18 AWG or 14 AWG for continuous runs.
− Make sure LEDs and drivers are cool to touch when performing maintenance.
− Make sure the supply voltage is the same as the rated voltage of the luminaire and connected to an individual,
properly grounded branch circuit protected by a 20 Ampere circuit breaker. Use Min. 90°C supply.
− Do not install in a hazardous atmosphere, except where the ambient temperature does not exceed the rated
operating temperature of the fixture.
− Grounding and bonding of the overall system shall be done in accordance with NEC article 600 and local codes.
− This Luminaire is to be wall mounted only and keep tightly closed when in operation. Installation height must be
more than 4' off ground.
4132337
WARNING
