Acer LCD TV

AT930/AT93

AT2230/AT223

User Guide

Contents

Important safety instructions

Disposal instructions

EC-Declaration of Conformity

First things first

Packing checklist

Your LCD TV overview

Front panel view

Rear panel view

Remote control

General keys

Teletext

Basic connections

Connecting the power cord

Setting up the remote control

Enjoying your TV

Connecting an antenna/cable

Getting started watching your TV

Connecting external audio/video devices

Connecting a DVD, VCR, STB or audio/video equipment

Connecting a camera, camcorder or video game

Connecting a PC or notebook computer

Selecting the input source

OSD navigation

Navigating the OSD with the remote control

Adjusting the OSD settings

Setting scenario mode in TV

Advanced features

Advanced setting

Steady sound

Channel setting

Locking TV content

Channel/program list

Audio effects

Widescreen display mode

Troubleshooting

PC input signal reference chart

Product specifications

Need help?

Do you have a question about the AT1930 and is the answer not in the manual?

Questions and answers

Summary of Contents for Acer AT1930

Page 1 Acer LCD TV Contents AT930/AT93 Important safety instructions Disposal instructions AT2230/AT223 EC-Declaration of Conformity First things first User Guide Packing checklist Your LCD TV overview Front panel view Rear panel view Remote control General keys Teletext Basic connections Connecting the power cord...
Page 2 Purchase Date: Place of Purchase: Acer and the Acer Logo are registered trademarks of Acer Inc. Other companies' product names or trademarks are used herein for identification purposes only and belong to their respective companies. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trade-...
Page 3 Important safety instructions Read these instructions carefully. Please put them somewhere safe for future reference. . Only use attachments/accessories specified by the manufacturer. 2. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/ apparatus combination to avoid injury from tip-over.
Page 4 Do not throw this electronic device into the rubbish bin / container when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle. For more information regarding WEEE, please refer to http://global.acer.com/about/environmental.htm Соответствует сертификатам, обязательным в РФ (Compliant with Russian regulatory certification)
Page 5 Trade Name: Acer Model Number: AT1930; AT1931; AT2230; AT2231 Is compliant with the essential requirements and other relevant provisions of the following EC directives, and that all the necessary steps have been taken and are in force to assure that production units of the same product will continue comply with the requirements.
Page 6 First things first We would like to thank you for making this Acer LCD TV your choice. With proper care, your new Acer LCD TV will provide you with years of entertainment and satisfaction. This User's Guide introduces you to the various features your LCD TV can offer, and provides clear and concise information about the product, so please read it thoroughly and retain it for future reference.
Page 7 Your LCD TV overview Front panel view Earphone AV in-S-video, CVBS, Audio L/R HDMI When the OSD is on, functions the same as the Volume up Right arrow. Volume When the OSD is on, functions the same as the down Left arrow.
Page 8 Rear panel view AC-in VGA-in + PC Audio-in HDMI AV in-COMPONENT + Audio L/R SCART Analog Tuner PC IN AUDIO HDMI SCART COMPONENT PC IN AUDIO HDMI SCART COMPONENT...
Page 9 Remote control General keys e (Empowering Technology) Press to activate and select the scenario mode. See page 9. MENU Press to open or close the Menu. Back POWER Press to back to previous Menu. Directional keys/OK WIDE Press to select the audio type, displayed in the top right-hand corner MENU BACK...
Page 10 Teletext RECALL ENTER SUBPAGE REVEAL INDEX SUBTITLE SIZE HOLD TTX/MIX Colour buttons (R/G/Y/B) Operates corresponding button on the teletext page. INDEX Press to go to the index page. SUBTITLE Press to view subtitles on the screen. REVEAL Press to reveal hidden telext information.
Page 11 Basic connections Connecting the power cord Connect the AC cord into the AC input on the back of the set. Connect the plug to the wall outlet as shown. Setting up the remote control Open the cover on the back of the remote unit. Insert two AAA batteries (supplied) to match the polarity indicated inside the battery compartment.
Page 12 Getting started watching your TV Power a. Turn on the power switch beneath the screen. b. Press the power button or channel up/down button on the remote control. Setup Wizard The first time you switch on the TV, the Setup Wizard will guide you to complete the language selection and channel scanning.
Page 13 Changing channels a. Press 0 - 9 on the remote control to select a channel. The channel changes after 2 seconds. b. Pressing the channel ( CH ) up / down button on the remote control will also change the channel. Adjusting the volume Adjust the volume level using the ( VOL ) up/down button on the remote control.
Page 14 COMPONENT COMPONENT R B G PC IN AUDIO COMPONENT HDMI SCART D-Sub HDMI R B G HDMI D-Sub Yellow White Blue Green * Acer recommends the following priority for connection types: HDMI -> COMPONENT -> SCART -> S-Video -> Composite.
Page 15 TV-out PC IN AUDIO SCART PC IN AUDIO HDMI SCART SCART COMPONENT Recorder Connecting a camera, camcorder or video game Connect your camera or camcorder to the video/audio ports on the left of the TV set as shown below. PC IN AUDIO HDMI SCART...
Page 16 PC IN AUDIO D-Sub D-Sub For VGA connections, Acer recommends setting your PC's external monitor resolution to 440 x 900 (AT930/AT93) or 680 x 050 (AT2230/AT223) pixels @ 60 Hz refresh rate. Selecting the input source Once you have connected your antenna or external equipment to the TV, you need to select the correct input source.
Page 17 OSD navigation Many of the advanced settings and adjustments are available through using the OSD (onscreen display) menus, as shown in the example screenshot below. Basic operations required to navigate these menus (Picture, Sound, Setting and Install) are described in this section. Navigating the OSD with the remote control MENU You can also interact with these menus using the right panel controls.
Page 18 Adjusting the OSD settings The OSD can be used for adjusting the settings of your LCD TV. Press the MENU key to open the OSD. You can use the OSD to adjust the picture quality, audio settings, channel settings and general settings. For advanced settings, please refer to following page: Adjusting the picture quality Press the MENU key to bring up the OSD.
Page 19 The options available on the OSD may vary depending on the TV signal source and model. Setting scenario mode in TV Scenario mode has six preset viewing modes designed to give you the best picture quality when watching a particular kind of programme. There are six pre-defined audio and video settings for optimal enjoyment of the following scenarios: Standard, Movie, Sport, Concert, Game, User.
Page 20 Advanced features Advanced setting MENU Advanced setting MENU Press the Menu key from the remote control hand set, to invoke the OSD (On Screen Display). Using the directional keys to navigate, select Setting from the OSD. Using the directional keys, to navigate through ‘NR’...
Page 21 NR (Noise Reduction): This function filters noise from a signal. You can set to ‘on’ or ‘off’ depending on your preference. ACM (Adaptive Contrast Management): This function automatically adjusts picture contrast, depending on the brightness of the video content. You can turn this feature either to ‘on’...
Page 22 Steady sound MENU Steady sound MENU Press the Menu key from the remote control hand set, to invoke the OSD (On Screen Display). Using the directional keys, navigate to and select Sound from the OSD. Navigate to ‘Steady sound’ to adjust settings. This function prevents sudden changes in the audio output level.
Page 23 Channel setting MENU Channel setting MENU Press the Menu key from the remote control hand set, to invoke the OSD (On Screen Display). Using the directional keys, navigate to and select Install. From this submenu, select Channel Setting to adjust Channel settings. Using the directional keys, to navigate through options ‘Channel edit’,...
Page 24 Channel edit: You can set the Channel Index or Skip this channel here. Use the directional keys to edit the channel index column. Channel swap: You can set the channel index in ‘From’ and ‘To’ submenu, then select ‘Exchange’, these two channels will change order in the channel list.
Page 25 Re-scan for channels The first time you completed the setup wizard, all available channels were listed. If you need to re-scan for new channels, please follow the steps below: MENU Scanning for channels MENU Press the MENU key on the remote control to bring up the OSD. Use the directional keys to navigate and select Install.
Page 26 MENU Press MENU to exit. Locking TV content Auto lock is a handy feature that can block all TV sources. Auto lock allows you to enter a password and effectively stop anyone without the password from watching TV. MENU Setting a password MENU Press the MENU key on the remote control to bring up the OSD.
Page 27 MENU Press MENU to exit. Locking your TV programs MENU Press the MENU key on the remote control to bring up the OSD. Using the directional keys, navigate to and select Setting from the OSD. Navigate to the Auto lock menu. Enter your Password.
Page 28 MUTE DISPLAY LIST Channel/program list Channel/program list allows you to quickly find the TV channel/program you are searching for. LIST RECALL ENTER SUBPAGE REVEAL INDEX SUBTITLE To open the channel list feature: SIZE HOLD TTX/MIX Press the CH LIST key on the remote control. This LIST will bring up the channel/program list menu.
Page 29 Widescreen display mode Your Acer LCD TV has a special widescreen mode that allows you to toggle between Super zoom, 4:3, 4:9, 6:0, 6:0 subtitle, Full screen and Wide detect type views. Press the WIDE key on the remote control to toggle the display between the seven wide modes.
Page 30 Wide detect Automatically detects the picture source and selects the appropriate aspect ratio. 4:3 (Not for HD) For 4:3 standard pictures. A side bar appears on each side. 4:9 (Not for HD) Standard 4:3 images will be scaled to 4:9. 6:0 (Not for HD) The 4:3 images will be scaled to 6:0 full-screen resolution.
Page 31 Troubleshooting Before you call the Acer service center, please check the following items: Here is a list of possible situations that may arise during the use of your LCD TV. Easy answers and solutions are provided for each. There is no picture or sound.
Page 32 PC input signal reference chart AT2230/A223: Resolution Horizontal Frequency Vertical Frequency Standard (kHz) (Hz) 720 x 400 3.5 70. 640 x 480 3.5 60.0 640 x 480 35.0 67.0 640 x 480 37.9 72.8 VESA 640 x 480 37.5 75.0 VESA 800 x 600 35.2...
Page 33 AT930/AT93: Resolution Horizontal Frequency Vertical Frequency Standard (kHz) (Hz) 720 x 400 3.5 70. 640 x 480 3.5 60.0 640 x 480 35.0 67.0 640 x 480 37.9 72.8 VESA 640 x 480 37.5 75.0 VESA 800 x 600 35.2 56.3 VESA 800 x 600...
Page 34 Product specifications Model AT930/AT93 AT2230/AT223 Panel spec Resolution (pixels) 440 x 900 680 x 050 Brightness (tpe.) 300 nit Contrast Ratio (tpe.) 000 : Dynamic Contrast Ratio 0000 : 5000 : (max.) Display 6.7 M colour Viewing angle (tpe.) H: 70 ;...
Page 35 Terminal Analog Tuner In SCART CVBS(In/Out), RGB(In), Audio R/L Component in YPbPr, Audio (R/L) AV-in CVBS, Audio (R/L) S Video S Video, Audio (R/L) HDMI Yes (HDMI .2) HDMI 2 Yes (HDMI .2) PC D-sub in PC audio-in Headphone out Resolution HDMI...
