Thank you for purchasing the Mini Circular Saw. Please read this manual thoroughly before
operating this device.
SAFETY WARNINGS
Read all safety warnings and instructions. Failure to follow them may result in electric shock, fire,
or serious injury. Keep these warnings for future reference.
1. Work Area Safety
• Keep your work area clean and well-lit. Cluttered or dark areas invite accidents.
• Do not operate Mini Circular Saw in explosive atmospheres, such as in the presence of flammable
liquids, gases, or dust. The tool can create sparks that may ignite dust or fumes.
• Keep children and bystanders away while operating Mini Circular Saw. Distractions can cause you
to lose control.
2. Electrical Safety
• The Mini Circular Saw plug must match the outlet. Do not modify the plug in any way. Avoid using
adapter plugs with earthed (grounded) tools, as unmodified plugs reduce the risk of electric
shock.
• Avoid contact with earthed or grounded surfaces such as pipes, radiators, ranges, and
refrigerators. Electric shock is more likely if your body is grounded.
• Do not expose Mini Circular Saw to rain or wet conditions. Water entering the tool increases the
risk of electric shock.
• Do not abuse the cord. Never use the cord for carrying, pulling, or unplugging the tool. Keep the
cord away from heat, oil, sharp edges, or moving parts. Damaged or tangled cords increase the
risk of electric shock.
• When operating Mini Circular Saw outdoors, use an extension cord suitable for outdoor use.
Using a cord suitable for outdoor use reduces the risk of electric shock.
• If operating Mini Circular Saw in a damp location is unavoidable, use a Ground Fault Circuit
Interrupter (GFCI) protected supply. A GFCI reduces the risk of electric shock.
Use Proper Extension Cord:
Make sure your extension cord is in good condition. When using an extension cord, ensure it is
heavy enough to carry the current required by the tool. An undersized cord will cause a drop in
voltage, resulting in loss of power and overheating.
MINI CIRCULAR SAW
Item No. 210471
User Guide
- 1 -
Advertisement
Summary of Contents for Sharper Image 210471
- Page 1 MINI CIRCULAR SAW Item No. 210471 User Guide Thank you for purchasing the Mini Circular Saw. Please read this manual thoroughly before operating this device. SAFETY WARNINGS Read all safety warnings and instructions. Failure to follow them may result in electric shock, fire, or serious injury.
- Page 2 3. Personal Safety • Stay alert and use common sense when operating the Mini Circular Saw. Do not use the tool if you are tired or under the influence of drugs, alcohol, or medication, as inattention can lead to serious injury.
- Page 3 5. Service Have your Mini Circular Saw serviced by a qualified repair person using only identical replacement parts to ensure safety. • Turn off the Mini Circular Saw immediately if: o The power plug or cord is defective. o The switch is defective. o Smoke or a burning smell occurs.
- Page 4 • Do not reach underneath the workpiece. The guard cannot protect you from the blade below. • Adjust the cutting depth so that less than a full tooth of the blade is visible below the workpiece. • Never hold the workpiece in your hands or across your leg. Secure the workpiece to a stable platform to minimize body exposure, blade binding, or loss of control.
- Page 5 SPECIFICATIONS Power Connection / Frequency: 120 VOLT / 60 Hz Power Consumption: 480 watt Rated Speed / No Load Speed: 4200 min Cutting Depth: 26 mm Saw Blade: 85 mm Protecting Class: II / Double insulated Soun Pressure Level: 93.5 dB (A) TOOL DESCRIPTION INTENDED USE This power tool is designed for ripping and cross-cutting wood and other materials, maintaining a...
- Page 6 DESCRIPTION OF TOOL 1. ON/OFF Switch 10. Laser (optional) 2. Safety switch 11. Dust extraction connection 3. Cutting depth limiter 12. Battery compartment (laser option only) 4. Clamping screw 13. Laser ON/OFF (laser option only) 5. Safety guard 14. Release button for the safety guard 6.
- Page 7 ASSEMBLY Unpacking 1. Open the shipper box and carefully remove the case. 2. Remove the packaging material. 3. Remove any packing protection and transport materials, if applicable. 4. Check the case to ensure it contains all parts. 5. Inspect the tools and accessories for any damage that may have occurred during transport. Selecting the Correct Blade for Your Material •...
- Page 8 WARNING • Unplug the machine when replacing the blade, and properly press the BLACK spindle lock button to lock the spindle before removing the clamping flange. • Do not use the machine if the spindle lock is blocked. Gently press the spindle lock button. •...
- Page 9 INSTRUCTIONS FOR USE Operation / Start-Up To use this tool, place the material to be cut between the base plate (6) and the support surface. The blade will penetrate the material, making a clean, fast, and safe cut. • Switching On o Push the safety switch (2) forward with one finger, then press the ON/OFF switch (1) while keeping it pressed.
- Page 10 Cutting along a line Use the indicators on the front and rear of the blade guard to help you cut along a straight line. Plunge Cutting (Refer to the tool description diagram) Plunge cutting may be challenging with certain hard materials. To perform a plunge cut: 1.
- Page 11 Using the Laser The laser beam guide helps you make straight cuts more easily: • Align the beam along a drawn line or a marked point. To switch the laser on, press the laser ON/OFF switch (13). To turn it off, press the same switch (13) again. CLEANING AND MAINTENANCE WARNING Unplug the tool from the wall outlet before cleaning or performing maintenance.
- Page 12 Customer Service department at 1 (877) 210- 3449. Customer Service agents are available Monday through Friday, 9:00 a.m. to 6:00 p.m. ET. The SHARPER IMAGE® name and logo are registered trademarks. ©Sharper Image. All Rights Reserved.
