High Speed Counter

CM3-SP02HSC

•

CM3-SP02HSD

•

- 1 -

Need help?

Do you have a question about the PLC CM3-SP02HSC and is the answer not in the manual?

Questions and answers

Summary of Contents for Cimon PLC CM3-SP02HSC

Page 1 High Speed Counter CM3-SP02HSC • CM3-SP02HSD • - 1 -...
Page 2 Contents General Specifications …………………………… 29 Performance Specifications …………………… 30 Features …………………………………………… 31 Operation Concept ……………………………… 32 Names of Parts …………………………………… 33 Dimensions ………………………………………… 34 Pin Arrangement ………………………………… 35 Wiring ……………………………………………… 37 Wiring Sample …………………………………… 39 Input Signal Circuit ……………………………… 43 Product Warranty …………………………………44 - 2 -...
Page 3 Reproduction of contents, in whole or part of this manual, without written permission from CIMON Inc. is prohibited. Safety symbols are classified into two categories, “WARNING” and “CAUTION”. Warning: This symbol describes situations that could cause major or fatal injury to the user.
Page 4 Design Precautions ( Warning) Please install a safety circuit to protect the entire control system in case of an unexpected power shutdown or PLC module malfunction. Such anomalies may severely compromise the integrity of the overall system. External to the PLC, please install circuits and switches to safeguard the system from mechanical damages (ex.
Page 5 Precautions for mounting ( Caution) Use the PLC in an environment that meets the general specifications given in this manual. Using this PLC in any environment outside the range of the general specifications could result in electric shock, fire, malfunction, or damage to or deterioration of the product. Please ensure that each module is installed correctly in its place.
Page 6 Precautions for wiring of HSC Module ( Caution) Cables for the output signals of the HSC module should be separate from AC power to prevent the influence of surge or induction noise occurring from AC. Select a cable considering ambient temperature and allowable current. AWG 22 (0.3 mm ) or more is recommended.
Page 7 Max. shock Acc.: 147 m/s (15G) Shock Time: 11 ms IEC 61131-2 Pulse wave: Half sine wave pulse (3 times in X, Y, Z) Square Wave CIMON ±2 kV Impulse Noise Standard Electrostatic IEC 61131-2 ±4 kV (Contact), ±8 kV (Air)
Page 8 Performance Specification Model Item CM3-SP02HSC CM3-SP02HSD I/O Points 16 points Number of Channels 2 channels Phase 1 Phase input/2 Phase input Count Input RS-422A Line Drive (5 V) Level (фA,фB) 5/12/24 V DC 2—5 mA Signal /HTL Line Drive (24 V) Types PNP Encoder (-Common) Line Drive (Differential Input)
Page 9 Features High Speed Counter (HSC) module covers a wide range of high-speed pulses. (-2147483648— 2147483647) The counted value is stored in the buffer memory as a signed 32-bit binary value. 2. Different types of operation mode are provided. - 1 Phase input 1 Multiplication (Increasing/decreasing count operated by software setting), - 1 Phase input 2 Multiplication (Increasing/decreasing count operated by software setting), - CW/CCW : 2 Phase input 1 Multiplication...
Page 10 Operation Concept 1) Count incoming pulse. 2) Preset and enable count operation can be operated by the external signal. 3) Compare the present count value with the compared value and turn compared output ON or OFF. (2 points per channel) 4) By using scan program, it’s possible to check the I/O signal and buffer memory.
Page 11 Names of Parts LED Name Description Module is powered and initialization is completed. (PWR LED blinks when an error occurs) ØA A phase pulse input (V) ØB B phase pulse input (V) Count is decreasing External preset terminal input (V) Enable count terminal input (V) O1, O2 Compared output...
Page 12 Dimensions (Unit: mm) * CM3-SP02HSC and CM3-SP02HSD have the same dimensions. - 12 -...
Page 13 SP02HSC Pin Arrangement Channel Signal Pin No. Channel Signal Pin No. A Phase pulse input 24 V A Phase pulse input 24 V A Phase pulse input 12 V A Phase pulse input 12 V A Phase pulse input 5 V A Phase pulse input 5 V A Phase common ◈...
Page 14 SP02HSD Pin Arrangement Channel Signal Pin No. Channel Signal Pin No. A + Phase Pulse Input 5 V A + Phase Pulse Input 5 V A- Phase Pulse Input 5 V A- Phase Pulse Input 5 V A + Phase Pulse Input 24 V A + Phase Pulse Input 24 V A- Phase Pulse Input 24 V A Phase Pulse Input 24 V...
Page 15 SP02HSC Wiring 1) Connector Pin Number 2) CM0-TB32M - 15 -...
Page 16 SP02HSD Wiring 1) Connector Pin Number 2) CM0-TB32M - 16 -...
Page 17 Wiring Examples 1. When waveform generator outputs 5 V. (CM3-SP02HSC) 2. When waveform generator outputs 24 V PNP open collector output. (CM3-SP02HSC) - 17 -...
Page 18 Wiring Examples 3. When waveform generator outputs 24 V NPN open collector output. (CM3-SP02HSC) 4. When waveform generator outputs totem pole output (voltage type). (CM3-SP02HSC) - 18 -...
Page 19 Wiring Examples 5. When waveform generator outputs totem pole output (NPN open collector type). (CM3-SP02HSC) 6. When waveform generator outputs line driver output. (CM3-SP02HSD) - 19 -...
Page 20 Wiring Examples 7. Preset, enable count input wiring. (CM3-SP02HSC, CM3-SP02HSD) 8. Compared output 1, 2 wiring. (CM3-SP02HSC, CM3-SP02HSD) - 20 -...
Page 21 SP02HSC Input Signal Circuit - 21 -...
Page 22 CIMON. In no event will CIMON be liable, whether in contract, tort or under any other legal theory, for lost profits or revenues, loss of use or similar economic loss, for any indirect, special,...
Page 23 INTELLECTUAL PROPERTY RIGHTS, OR THE ACCURACY, RELIABILITY, QUALITY OR CONTENT IN OR LINKED TO THE PRODUCTS. CIMON AND ITS AFFILIATES AND SUPPLIERS DO NOT WARRANT THAT THE PRODUCTS ARE SECURE, FREE FROM BUGS, VIRUSES, INTERRUPTION, ERRORS, THEFT OR DESTRUCTION. FURTHER, CIMON DOES NOT WARRANT ACCESS TO THE INTERNET OR TO ANY OTHER SERVICE, CONTENT OR DATA TRANSMITTED THROUGH THE PRODUCTS.
Page 24 REGULATIONS. LIMITATION OF LIABILITY AND INDEMNITY: TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE ENTIRE LIABILITY OF CIMON, AND ITS AFFILIATES AND SUPPLIERS FOR ALL MATTERS OR CLAIMS RELATING TO THIS AGREEMENT SHALL BE LIMITED TO THE AMOUNT YOU PAID FOR THE PRODUCTS DURING THE TWELVE (12) MONTHS PRIOR TO SUCH CLAIM.
Page 25 MEMO - 25 -...
Page 26 Seoul Address 11F, M State, #114, Beobwon-ro, Songpa-gu, Seoul, Republic of Korea, 05854 Tel. +82-2-480-8587 USA Address CIMON Inc. 2435 W. Horizon Ridge Pkwy, #100, Henderson, NV 89052 Tel. +1-702-820-1060 Homepage : www.cimon.com Version : 1.0 Revision : January, 2022...
