DCT-WR204
Wi-Fi ROUTER
Owner's Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the DCT-WR204 and is the answer not in the manual?

Questions and answers

Neil Bomford
June 18, 2025

I can’t access my account refusing my credit card .

User image 685312c6e97da

Summary of Contents for Pioneer DCT-WR204

  • Page 1 DCT-WR204 Wi-Fi ROUTER Owner’s Manual...
  • Page 2 Contents Thank you for buying this Pioneer product. Please read through these instructions so you will know how to operate your model properly. After you have finished reading the instructions, keep this document in a safe place for future reference.
  • Page 3 Il testo completo della dichiarazione di conformità UE è disponibile al seguente indirizzo Internet: https://www.pioneer-car.eu/eur/compliance Español: Por la presente, Pioneer declara que el tipo de equipo radioeléctrico [*] es conforme con la Directiva 2014/53/UE. El texto completo de la declaración UE de conformidad está disponible en la dirección Internet siguiente: https://www.pioneer-car.eu/eur/compliance Português:...
  • Page 4 Celotno besedilo izjave EU o skladnosti je na voljo na naslednjem spletnem naslovu: https://www.pioneer-car.eu/eur/compliance Română: Prin prezenta, Pioneer declară că tipul de echipamente radio [*] este în conformitate cu Directiva 2014/53/UE. Textul integral al declarației UE de conformitate este disponibil la următoarea adresă internet: https://www.pioneer-car.eu/eur/compliance Български:...
  • Page 5 Tokyo 113-0021, JAPAN http://www.pioneer-car.eu [*] DCT-WR204 Hereby, Pioneer declares that the radio equipment type [*] is in compliance with UK SI 2017 No. 1206. The full text of the UK declaration of conformity is available at the following internet address: http://www.pioneer-car.eu/compliance...
  • Page 6 Precaution Certain country and state laws may prohibit or restrict the placement and use of this product in your vehicle. Please comply with all applicable laws and regulations regarding the use, installation and operation of this product. It is the user’s responsibility in compliance with all applicable laws and ordinance.
  • Page 7 • It is the user’s responsibility in compliance with all applicable laws and ordinance. • Pioneer is not liable for any damage, due to installation other than described, or use of the product. Pioneer does take responsibility whatsoever for any damage or losses incurred as a result.
  • Page 8 To ensure safe driving WARNING • Do not control or operate this product while driving. Park your vehicle in a secure way before using this product. Precautions before connecting the system CAUTION • Firmly install this product. If this product is not firmly installed, it may fall off while driving and cause an accident.
  • Page 9 Precautions before installation CAUTION Never install this product in places where, or in a manner that: • To ensure proper installation, be sure to use the supplied parts in the manner specified. If any parts are not supplied with this product, use compatible parts in the manner specified after you have the parts’...
  • Page 10 • This disclaimer applies both during and after terms of the Warranty. • Pioneer will not be held liable for any costs incurred as a result of using mobile data services. Data usage can be expensive. The “Statistics” information for Data use should be used as a guide only, it is not always completely accurate.
  • Page 11 How to read this Manual Notation Meaning These symbols are used to draw your attention to items you should be aware of when using this product and items you should be aware of to maintain its performance. Note /Notes Notes provide useful tips and extra information about product features. →...
  • Page 12 OFF. To prevent the product from draining the vehicle battery, pls turn the unit OFF when the vehicle battery is not being regularly charged. To protect itself from overheating, the DCT-WR204 may shut down automatically. To recover, pls Power ON>OFF>ON .
  • Page 13 Check the Accessories Main Unit × 1 Power Cable (5.0m) × 1 Warranty × 1 Quick Start Guide × 1 − 13 −...
  • Page 14 Before Installing the Product WARNING • When installing the product on vehicles installed with an air bag, never install on the cover of the air bag and at locations that might obstruct the deployment of the air bag. Doing so might prevent the air bag from being deployed normally, cause the product to fly out due to air bag deployment, and cause accident and injury.
  • Page 15 Precautions before installation Before Installing and Securing the Product Never install this product in places where, or in a manner that: • To ensure proper installation, be sure to use the supplied parts in the manner specified. If any parts are not supplied with this product, use compatible parts in the manner specified after you have the parts’...
  • Page 16 Installation Recommended Installation Position • The Product can be mounted horizontally on a flat surface or vertically up to a 90 degree angle with the antenna connectors topwards. • As SIM cards may require changing depending on destination, we recommend to mount the product to allow easy access to the SIM slots and LED for the user Not OK Mounting surface...
  • Page 17 Connecting the Power Cable Be sure to disconnect the ⊖ terminal of the vehicle’s battery before connecting the power cable. Black 0.3 m Fuse (F 3.0 A/250 V) 0.3 m 5.0 m − 17 −...
  • Page 18 Caution This product is not compatible with cigar chargers. Only use the cable supplied by Pioneer in the box. Caution When replacing the fuse, make sure to only use a fuse of the rating prescribed for this product. Do not replace the fuse with one of a higher rating, this may cause fire and/or smoke.
  • Page 19 Product Overview 1. Part Names Back Right side Left side Front Bottom 1 Main Label 6 Main Power Connector Includes Username and Password 7 LTE Antenna Connectors 8 Wi-Fi Antenna Connectors 2 SIM Card Lid Covers 2 SIM slots compatible with 9 LAN ports nano SIM With status LED.
  • Page 20 Status LED Status Translation • • Color Action Function Description Controlled by • • Reserved for future using Router • Green DC power existing MCU & Router • Power • Blue Reserved for future use Router • White RGB all Blinking SW Update Router •...
  • Page 21 Using This Product Initial Step This is your first experience with this router, as such we try to get you connected. To use a 4G cellular internet connection you must have a subscription with a telecommunication provider. For most subscriptions, there is a maximum data limit per month. It is important that this cellular data amount is enough to support the functions that you wish to use on the Router.
  • Page 22 Power Up Check whether power cable and antennas are connected, then power up your Router for the magic to start… LEDs will turn on and off in a self-test routine, please wait till the power LED is ON and the LED indicating the SIM is fixed ON, don’t mind the color for now.
  • Page 23 Login Login with your personalized password under the admin account. With the correct information in place, a new landing page will open. If yourinserted SIM card is immediately recognized, your Router will be connected to a mobile network with maximum available strength. Mobile network connection If your router is not immediately connected to a mobile carrier, maybe the SIM card is PIN locked, please unlock the SIM card by selecting SIM settings (see next step) The SIM settings view will open.
  • Page 24 In case that the router is not connected to the network, check with your mobile network provider for the APN. In the same menu under network and SIM settings left upper area you see the APN settings. If you click that area you will see a new view opening for APN settings. By default the APN settings are set to automatically detect and follow the cellular network provider.
  • Page 25 WWAN On the landing page there is also soft key for WWAN hotspot (indicating an antenna). This feature will look for Wi-Fi networks close to you and will give the following view: Enable the Wi-Fi WAN Setting status, apply your changes and wait for a reboot of the system. Once done, tap the scan key to scan for Wi-Fi networks close to you, select the network to which you would like to connect and use the Password to finalise the conneciton The Router will remember the last selected network and password when you switch the router OFF.
  • Page 26 Router Management Within this view it is possible to reboot the system on the bottom with the “Reboot” soft key. This will take a few minutes and reboots the router but still keep the original devices connected and the credentials to log in. The other soft key is ”Factory Reset”.
  • Page 27 Wi-Fi 2.4GHz and Wi-Fi 5.0GHZ This is the Wi-Fi network the router emits for the classic devices that can connect over Wi-Fi technology. The ‘Wi-Fi Status’ setting offers the possibility to disable the network to broadcast. If you are connected to this network (check SSID in your Wi-Fi settings of your device) you will be disconnected from the router immediately and need to connect with the other network (name and or password) once you push the ‘apply’...
  • Page 28 Wi-Fi Guest (Guest Mode) Under the menu setting ‘Wi-Fi Guest’ you will find 2 frequencies for guest networks. These networks can be shared with their own network name and private password. These networks also generate a QR code to share them easily with people closeby. You can control when it is broadcasted or when it is stopped.
  • Page 29 Professional Settings The DCT-WR204 allows very advanced setting to be made. If you are not sure what the , pls ask an IT expert to support you. Do not attempt to change the “Professional Settings “ by yourself if you are not sure of the meaning the terms .
  • Page 30 Professional Settings Content Filtering Enable the Content filter to Black list websites. Input the URL’s of the websites you wish to Black list. Port Forwarding Port forwarding allows you to communicate with devices behind a router (or firewall) by instructing the router to forward traffic on certain ports to specific IP address on its LAN.
  • Page 31 Professional Settings The Demilitarized Zone (DMZ) is an internal network of an organization, which is made available to an untrusted network. As per security, the DMZ falls between trusted and untrusted networks. Maintenance of the DMZ helps to improve security of to an organization’s internal network. UPnP Universal Plug and Play (UPnP) is a network protocol that allows devices to discover each other on the network.
  • Page 32 Professional Settings Network Management Under this setting you can control the Network access settings. The Network Time Protocol (NTP) synchronizes the time of day among a set of distributed time servers and clients so that you can correlate events when you receive system logs and other time-specific events from multiple network devices.
  • Page 33 Professional Settings Dynamic DNS (DDNS) The Domain Name System (DNS) is a feature that maps Internet domain names to IP addresses. Dynamic DNS (DDNS) is a feature that allows devices to be located through domain names even if the IP address of the device has changed. VPN Passthrough Virtual Private Network (VPN) is a method of connecting multiple private networks across the Internet.
  • Page 34 Professional Settings Diagnostic Test your connectivity. System Log See and clear recent activities on your Router. − 34 −...
  • Page 35 Trademarks & Copyrights ® • The Wi-Fi CERTIFIED Logo is a registered trademark of Wi-Fi Alliance • • EU Conformity marking. • • • • • • UK Conformity marking. − 35 −...
  • Page 36 A9: Yes, when the Router is using 3G/4G as the connection source (rather than Wi-Fi), it will work when you are in motion. Q10. Why do I lose connection to my DCT-WR204 when I move in or out of range of the Wi-Fi source my Router is using? A10: The Router will automatically detect and connect to the Wi-Fi source (WWAN) you have set up in the Web User Interface.
  • Page 37 A13: It is possible that the IP Address of your Wi-Fi source is the same as that of the DCT-WR204 Router. This will cause this function to stop working You can try moving closer to the source. If this does not work, the Wi-Fi source may be too slow to use;...
  • Page 38 Specifications Dual Band 2.4GHz and 5GHz • On-board 802.11 b/g/n • Frequency band 2.4GHz : 2412 MHz to 2472 MHz Wi-Fi • Output power 2.4GHz : + 19 dBm Max. • Frequency band 5GHz : 5180 MHz to 5240 MHz •...
  • Page 39 Visit www.pioneer-car.eu/uk/ (or www.pioneer-car.eu/eur/) to register your product. PIONEER CORPORATION 28-8, Honkomagome 2-Chome, Bunkyo-ku, Tokyo 113-0021 Japan PIONEER EUROPE NV Haven 1087, Keetberglaan 1, B-9120 Melsele, Belgium/Belgique Tel: +32 (0)3 570 05 11 Salamanca, Wellington Street, Slough, SL1 1YP , UK Tel: +44 (0)208 836 3500 ©...
