Features
• Control volume +/-, track FWD/PREV, PLAY/PAUSE, and auxiliary input
• Equipped with QCC3034 Bluetooth
• Easily switch between wireless input and auxiliary input
• Wireless remote with steering wheel mount: 1.85"x.78"
• Rated IPX7 for powersports & marine applications
• Drill-less mounting solution included
• Controller: 2.87"x 2.8"x.94"
• 24-bit lossless audio processor
• Amplifier remote turn-on output
Installation Tips
1 Ensure your streaming device has wireless mode enabled and that power is applied to the
IBBTR18. (The blue LED on the IBBTR18 will blink to indicate it is in pairing mode.)
2 Within your streaming device's wireless setup menu, select "IBBTR18" from the list of
pairable devices.
3 When successfully connected, the Blue LED on the IBBTR18 will stop blinking and remain lit.
A single beep will be heard through the connected audio system.
4 Connecting the blue wire (remote out) to the amplifier (remote in) to turn the amplifier on/off.
5 The IBBTR18 will remember the last device that was connected to it and reconnect with it
automatically. When a connected streaming device is out of range for more than one minute,
the IBBTR18 will automatically disconnect this device and return to pairing mode (LED will blink).
6 The IBBTR18 can be installed out of sight, as it has a wireless remote to be used with it.
Wiring Diagram
Bluetooth Adapter
TheInstallBay.com
IBBTR18
Single Zone Controller with Bluetooth
Wireless Connectivity and Remote
5.1 chips
®
• 5.2V 2-channel RCA output
• Wireless range: 35ft/11m
• 1-year warranty
Power (yellow)
Ground (black)
Remote in (red)
Remote out (blue)
Auxiliary input female
Audio RCA output male
Rev. 9/29/23 IBBTR18_Manual
© 2023 Metra Electronics Corporation
®
Advertisement
Summary of Contents for Install Bay IBBTR18
- Page 1 When a connected streaming device is out of range for more than one minute, the IBBTR18 will automatically disconnect this device and return to pairing mode (LED will blink). 6 The IBBTR18 can be installed out of sight, as it has a wireless remote to be used with it. Power (yellow)
- Page 2 IBBTR18 Single Zone Controller with Bluetooth ® Wireless Connectivity and Remote Operation Guide Toggle Aux/Wireless Pair with wireless Device 1 Double click pairing “ ” button to pair Modes Push 2X wireless remote with controller. Push Once 2 Press “+” & “-” for level up & down.
- Page 3 IBBTR18 Single Zone Controller with Bluetooth ® Wireless Connectivity and Remote Installing the Rubber Band Snap the unit into the plastic adapter. Using the included rubber band for steering wheel and bar mounting, hold the rubber against the steering wheel. Wrap it around, then hook it up.
- Page 4 IBBTR18 Single Zone Controller with Bluetooth ® Wireless Connectivity and Remote Sling for Remote Control Use the included sling to carry this waterproof remote control. Sling FCC Compliance Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
