  • Page 1 Detector de fallas ultrasónico X5, Solid NDT SL-UFDX5...
  • Page 2 Ultrasonic Flaw Detector Operating Instructions Solid (Beijing) Technology Co.,Ltd...
  • Page 3 CONTENTS CHAPTER I. - OVERVIEW ........................1 1.1 H ..................1 OW TO USE THE INSTRUCTION MANUAL 1.1.1 Layout of pages and conventions of expressions ..............2 CHAPTER II. TECHNICAL PARAMETERS AND PERFORMANCE FEATURES OF THE INSTRUMENT ............................4 2.1 M ..................
  • Page 4 3.4.2Config ............................31 3.4.3 Display ............................ 34 3.4.4 Region ............................. 39 3.4.5 Result ............................42 3.5 PLSRSV ............................46 3.5.1 Pulser ............................. 46 3.5.2 Recive ............................. 49 3.5.3 Gain ............................53 3.5.4 Prf ............................54 3.5.5 Bea (backwall echo attenuator) ..................... 55 3.6 G ...............................
  • Page 5 3.10.2 Probe ..........................107 3.10.3 Record ..........................110 3.10.4 Repair ..........................113 3.10.5 Eval ............................ 115 3.11B BSCAN ............................ 116 3.11.1 Config ..........................116 3.11.2 Disp ............................ 118 3.12 A .................. 119 DJUSTMENT OF THE SPECIAL FUNCTIONS 3.12.1 Gain step ..........................120 3.12.2 Db gain ..........................
  • Page 6 CHAPTER VI. FACTORS INFLUENCING THE INSPECTION ACCURACY AND THE EVALUATION OF DEFECTS ......................134 6.1 E ........134 SSENTIAL ONDITIONS FOR SING THE LTRASONIC ETECTOR 6.1.1 Training the Operator ......................134 6.1.2 Technical requirements for flaw detection ................134 6.1.3 Testing range ......................... 135 6.1.4 Measurement of wall thickness using the ultrasonic method ..........
  • Page 7 Chapter I. - Overview This is a portable, industrial, non-destructive ultrasonic flaw detector, which is used to rapidly, and easily inspect work pieces accurately for various defects such as cracks, inclusions and pinhole porosity etc. Further evaluation of these defects can be performed during the testing process. The instrument can be used extensively in many varying fields where materials inspection is required to maintain quality control during manufacturing and production processes, e.g.
  • Page 8 of the instrument, which will describe all keys and displays on screen, and explain the operating principle. By following the instructions carefully, you can avoid possible instrument failure due to operating errors, and have a better concept of all the functions of the instrument. 1.1.1 Layout of pages and conventions of expressions In order that you can understand the instructions easily, all operating steps and instructions of importance are arranged in a practical way.
  • Page 9 select a function.
  • Page 10 Chapter II. Technical parameters and performance features of the instrument 2.1 Measuring range and measuring error Range of scanning: 1mm ~15000 mm (Apply to UFDX5) Resolution for scanning: 0.01mm (1mm ~100mm) 1mm (100 mm ~10000mm) Range of gain: 0dB ~110 dB D-Delay: -20µs～+3400µs P-Delay:...
  • Page 11 2.5 Performance features Dynamic echo treatment technology show “analog display and analog performance”  which other digital instrument lack. 20MHz analog Bandwidth can satisfy requirements of different applications.  Color Legs ,intuitionisticly achieving the position of flaw when more than one echo ...
  • Page 12 drilled hole under consideration of reference attenuation, material attenuation and surface compensation ,evaluation of equivalent sizing and equivalent gain and percentage of defects...
  • Page 13 Chapter III. - Operation 3.1 Overview of the instrument 3.1.1 Designation of the instrument’s components...
  • Page 14 Reference List dB Step Selection Probe calibration dB Selection Lock function parameter Freeze Key Home Print Data Parameter regulate key Broadening Key Function selection Data Save Function selection LCD Screen Measurement range set Gate selection Function selection DAC curve ON/OFF 3.1.2 Functional keyboard UFDX5Functional keyboard are arranged in three areas: menu keys area, function keys area and special function keys area.
  • Page 15 2．Parameter Modify keys 5．Function keys area 6．Page Up/Down keys area 3．Special function keys area 7．Menu keys area 4．Alarm LED 8．Power on/off key Fig. 3.2 Functional keyboard The function of UFDX5 can divided into 3 classes. The first class is function group menu, including 8 menus as following BASIC/ PULSE/GATE/PROBE/FILE /DAC/DGS/B-scan .There are 5 menu keys corresponding with the 5 function groups on the display screen, and Home Key...
  • Page 16 ,Copy Key , Home Key , dB Key , Zoom Key , Freeze Key , Lock Key Save Key Please refer to Fig. 3.2 for an overview of the functional keyboard. 3.1.3 Indicator light The LED display on the plug-in power supply unit indicates the status of the charging process. Indicator light 1: gate alarming indication showing: red Indicator light 2: battery charging indication...
  • Page 17 Receiver port: used to connect “receive” probe. Note To install a single-element probe, connect the probe cable to either of the two ports on the ： front of the instrument. when two probes, or a dual-element probe is connected to the instrument, the “RECEIVE”probe connector should be installed in the reiver port and the “TRANSMIT”probe connector in the transmit port.
  • Page 18 Indicators for charging Located below the main measurement reading box of the UFDX5 display, which are the icons indicating the status of the battery charging. Power supply inspection displays estimation of extended battery life based on coulomb meter according to the condition of use, with indication of percentage or endurance time (Reference to3.4.5.4).
  • Page 19 The probe is connected to the BNC /LEMO socket on the right hand side of the instrument casing using the cable selected. When using a single crystal probe either of the two connector sockets, (which are parallel internally), can be used as they have the same function. When using a twin crystal probe (TR-probe - one crystal for sending, and one crystal for receiving) or two single probes (one for sending, and the other for receiving), take care that the sending probe is connected to the socket on the left (with “↓”...
  • Page 20 Note: Please check the power-monitoring icon at the lower right hand corner of the display screen to verify if the unit is ready for optimum power operation. If the power monitor shows that the voltage is low, it will turn off automatically 1 min after the alarm bell sounds.
  • Page 21 3.1.9.1 UFDX5 screen display modes • A-scan in the normal mode Figure3.8 A-scan in the normal mode • A-scan in the zoom mode The zoom mode is activated using .The screen display always shows the gain and adjusted dB step value.All other functions are locked in zoom mode.
  • Page 22 Fig.3.9 A-scan in the zoom mode • B-scan Fig.3.10 B-scan 3.1.9.2 Displaying Measured Readings UFDX5 is capable of displaying up to five measured readings at one time including a main display box. Parameters available for display include the following (availability depends on instrument configuration and operating mode): Note that when S, D, P readings are displayed, the Gate-Detection Mode setting for the referenced gate (A or B) is indicated by a ^ (Peak Mode) or a / (Flank Mode).
  • Page 23 RA—Projection distance from the probe’s BIP to the reflector represented by the echo in A-Gate, minus the inputted X-VALUE. (see Figure 3-11) RB—Projection distance from the probe’s BIP to the reflector represented by the echo in B-Gate, minus the inputted X-VALUE. (see Figure 3-11) LA—Leg Indicator identifies on which leg the reflector represented by the echo in A-Gate was detected (Legs 1 through 5).
  • Page 24 Fig.3.11 Measurement Values Display...
  • Page 25 3.1.9.3 Menus Status Bar UFDX5 home menu system consists of three class including function group menus, function menus and functions. In the Menu status bar, we can see present menu status. For example, the following menu status show BASE function group menu—>RANGE function menu－>RANGE function(Refer to Fig.3.12).
  • Page 26 When the instrument display the mode-States vs. Time，X position display “M/D/Y –H: M: S”， Y position display the following information: TYPE ICONS NOTE CHANNEL Channel No. FILE FILE No. DATA TYPE Echo stored Type Thickness stored Type PROBE STATUS Single incline incidence Dual incline incidence Single straight incidence Dual straight incidence...
  • Page 27 3.2 Overview of instrument description 3.2.1 Function of the keys With the key combinations on the UFDX5 of function selection and function adjustment, you can select the functions of the instrument and adjust the functional values. With the keys of the Special Functional group, you can directly start the special functions of the instrument.
  • Page 28 To increase or decrease the gain once the set gain step is activated, the range is 0dB~110dB. dB- step Key To choose the increment for the gain setting, There are 7 steps 12.0dB、6.0dB、2.0dB、 1.0dB、0.5dB、0.2dB、0dB . Zoom key To display a zoomed A-scan, to extend the display and show detail of waveform Full- screen key Enlarged echo display over the entire screen, to shift the full-screen and normal mode Freeze key...
  • Page 29 3.2.2 Home menu structure UFDX5Home menu system consists of several function group menus, function menus and functions in order to extend the application of the instrument. BASE PLSRSV GATE PROBE FILES *RANGE SELECT XTAL FRQ PLS TYPE FILE No/ FILE No *MTLVEL ENERGY/PLS VOLT EFF DIAM...
  • Page 30 3.2.3 Basic operation method Function group menus and function menus are selected by pressing below the desired item; when a function menu is selected, the functions contained in that function menu are listed in the function bar down the right-hand side of the display screen; functions are then selected by pressing the adjacent function key ;...
  • Page 31 3.2.4 Base menu 3.2.4.1 Language Sets the language displayed on the instrument’s screen. (Refer to section3.4.4.1) 3.2.4.2 Units Sets display units to inch or millimeter. (Refer to section3.4.4.2) 3.2.4.3 Brightness Adjusts the display’s brightness through BASE—>DISPLAY—>BRIGHTNESS (Refer to section3.4.3.3) The intensity of the background light of the display screen can be adjusted by selecting the functional item BRIGHTNESS, which offers six options.
  • Page 32 3.2.5 Basic settings prior to detection 3.2.5.1 Basic settings of the BASE group—>RANGE function menu Before proceeding with the inspection work, the following basic settings for RANGE, MTLVEL, D-DELAY, P-DELAY in the BASE group menu—>RANGE function menu must be entered. For details please refer to section 3.4 .1Adjustment of base group. 3.2.5.2 Basic Settings of the PLSRSV function group Before proceeding with the inspection work the following basic settings for PLSRSV function group—>PULSER function menu—>...
  • Page 33 3.4 BASE Function Group In the BASE functional group, the functions that you find here are required for the basic adjustment of the screen displays. 3.4.1 Range In the RANGE functional menu, users can adjust and set the functional items relative with the display range, including RANGE, MTLVEL, D-DELAY and P-DELAY.
  • Page 34 500mm, 600mm, 700mm, 800mm, 900mm, 1000mm, 2000mm, 3000mm, 4000mm, 5000mm Fine adjustment: Range Step graduation ≤100.mm 0.1mm >100mm Operation:  By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< >...
  • Page 35 2,730m/s 0.107 in /µs Sound velocity of longitudinal wave in organic glass 3,080m/s 0.121 in /µs Sound velocity of transverse wave in aluminum 3,230m/s 0.127 in /µs Sound velocity of transverse wave in steel 4,700m/s 0.185 in /µs Sound velocity of longitudinal wave in copper 5,920m/s 0.233 in /µs Sound velocity of longitudinal wave in steel...
  • Page 36 starting point is at the surface of the work piece or slightly subsurface. If the initial pulse has to be started at the surface of the work piece the D-DELAY must be set to 0. Range: -20µs～3400µs Step: 0.1µs Operation: By pressing the home key <...
  • Page 37 And then adjusting parameters for the function by way of the fast rotary knob.  By pressing the same more than once to shift between coarse and fine adjustment. Note: If the P Delay is unknown, please refer to Chapter IV Calibration of the instrument, for the correct set up procedure to follow.
  • Page 38 By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select BASE functional group. ...
  • Page 39 Options: ALL——Freezes the currently active A-Scan. No additional A-Scans are displayed until the display is unfrozen. COMPARE——Freezes the currently active A-Scan on the display screen(which is then displayed in an alternate color),then displays subsequent live A-Scans. Forzen A-Scan is cleared selecting an alternative FREEZE MODE.
  • Page 40 By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select CONFIG function menu.  By pressing the function key < > on the right –hand of the Functional keyboard, you ...
  • Page 41 3.4.3.1 Heme/Ascancol (Header Theme/Ascan Color) This multipurpose functional menu is used to select Header theme and to select A-Scan color. And operator presses the same more than once to shift between the two functions. HEADER THEME: Set the display screen color to one of five schemes according to condition of work field and personal favorite.
  • Page 42 3.4.3.2 Coor Mod/Coorcol (Co-Ordinate Grid/Co-Ordinate Color) This multipurpose functional menu is used to select co-ordinate grid and to select co-ordinate color. And operator presses the same more than once to shift between the two functions. COOR MOD: This function is used to set the grid co-ordinates for the display. Options: 0~3 Operating procedure: By pressing the home key <...
  • Page 43 3.4.3.3 Lum/Bkcol (Brightness/Black Color) This multipurpose functional menu is used to select brightness and to select the back color. And operator presses the same more than once to shift between the two functions. LUM: This function is used to adjust the backlight intensity (BRIGHTNESS) of the display. Options: 0~5 Operating procedure: Operating procedure:...
  • Page 44 3.4.3.4 Echo mod/Textcol (Echo Mode/Text Color) This multipurpose functional menu is used to select echo mode and to select text color .And operator presses the same more than once to shift between the two functions. ECHOMOD(COLOR LEG): To make the orientation easier, the instrument is able to display the different sound path sections or legs in different ways.
  • Page 45 Set the color of the displayed text information. Options: 0~255 Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu. ...
  • Page 46 3.4.4.2 Units Set displayed unites to standard, metric. Options: inch---default setting which displays values in inches mm---displays values in millimeters 选项：mm、inch Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< >...
  • Page 47 By pressing the menu key< > , you select BASE functional group.  By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select REGION function menu. ...
  • Page 48 3.4.5 Result The display includes a total of five boxes where measured values (Referred to 3.1.6.2) can be displayed. Four “small reading boxes” can each contain one of four measured values. A “main” reading box can display, in a larger format, any one of the values shown in the small boxes. 3.4.5.1 Main Disp/Coor Disp (Main Reading Display/Coordinating Display) This multipurpose functional menu is used to select main reading box and to select coordinating box.
  • Page 49 By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select BASE functional group.  By pressing the same menu key< > again to enter this function menu. ...
  • Page 50 Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select BASE functional group. ...
  • Page 51 Options:SA/SB/DA/DB/PA/PB/A%A/A%B/dBtA/dBtB/dBrA/dBrB/SBA/DBA/PBA/LA/LB Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select BASE functional group. ...
  • Page 52 Option: Li battery Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< >...
  • Page 53 By pressing the function key < > on the right –hand of the Functional keyboard , you  select PLS TYPE function. And then adjusting parameters by way of the fast rotary knob.  3.5.1.2 Energy/Pls Volt This multipurpose functional menu is used to select energy and to select purlser voltage .And operator presses the same more than once to shift between the two functions.
  • Page 54 By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select PLSRSV functional group. ...
  • Page 55 probe’s oscillating circuit and to consequently change the height, width and resolution of the echo display. The higher the damp selected, the lower the echo amplitude, and the narrower the echo waveform, with a higher echo resolution. Options: 50Ω、150Ω、250Ω、400Ω Operating procedure: By pressing the home key <...
  • Page 56 By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select PLSRSV functional group.  By pressing the same menu key< > again to enter this function menu. ...
  • Page 57 Options： 1． NEG HALFWAVE—Shows the negative component of the RF signal but displays it in a positive orientation 2． POS HALFWAVE—Shows the positive component of the RF signal 3． FULL WAVE—Shows the positive and negative halves of the RF wave, but both are oriented in the positive direction RF—shows the echo with no rectification Operating procedure:...
  • Page 58  By Pressing the menu key < > , you select RECIVE function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you select RECTIFY function.  And then adjusting parameters by way of the fast rotary knob. 3.5.2.4 Reject This function is used to reject spurious echoes from the base line of the display, for example, to remove the structural noise propagating from the test piece.
  • Page 59 the defect echo is not inadvertently suppressed. Certain specifications prohibit the use of this function. 2. The function of suppression will not influence the waveform display when “radio frequency” (RF) is selected as an option. 3.5.3 Gain GAIN function menu includes dB STEP and USER STEP. 3.5.3.1 dB step The function sets the increment for the gain setting from the options below.
  • Page 60 Step: 0.1dB Operating procedure:  By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< >...
  • Page 61 Operating procedure:  By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select PLSRSV functional group. ...
  • Page 62 3.5.5.1 Bea sta The function is used for turning on or off the BEA mode. And then the value of BW GAIN is now the level of gain applied to A-scan echoes falling within B-Gate’s region. When BEA is activated, the gain applied to the backwall echo is set lower than the system gain applied to all other echoes.
  • Page 63 By Pressing the menu key < > , you select BEA function menu.  By pressing the function key < > on the right –hand of the Functional keyboard ,  you select B START function. And then adjusting parameters by way of the fast rotary knob. ...
  • Page 64 you select BEA dB function. And then adjusting parameters by way of the fast rotary knob.  3.6 Gate This function group is used for the adjustment of the gate settings, including POS、CONFIG、 ALARM function menu. Functions of the gate during operation of the instrument: To monitor the presence of defects in the test piece within the set logic and range.
  • Page 65 By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select POS function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you ...
  • Page 66 And then adjusting parameters by way of the fast rotary knob.  3.6.1.4 Gatethrsh The function is used to set the threshold value of the selected gate. The parameter is expressed in a percentage, i.e. the percentage relative to the full screen height of 100% Parameter range: 2%～90% Steps: 1% Operating procedure:...
  • Page 67 By pressing the menu key< > , you select GATE functional group.  By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select CONFIG function menu. ...
  • Page 68 Options: ON/OFF Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select GATE functional group. ...
  • Page 69 3.6.3 Alarm Alarm function menu is setting of the gate alarm, including Gate logic, LED, BEEP. 3.6.3.1 Select The function identifies gate for positioning. Options: Gate A /Gate B/ IF Gate Operating procedure: By pressing the home key < > immediately returns to the home Menu list. ...
  • Page 70 By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select GATE functional group.  By pressing the same menu key< > again to enter this function menu. ...
  • Page 71 LED： Set the gate alarm. Options: ON - LED is on OFF - LED is off Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu. ...
  • Page 72 By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select ALARM function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you ...
  • Page 73 IMMERSION---sound energy is transmitted from the probe, through the immersion fluid (usually water), and to the material being tested. Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< >...
  • Page 74 well as probe calibration, including CONFIG、PIECE、CALIB and AWS. 3.7.1 Config Configuration function menu include XTAL FRQ, EFF DIAM, ANGLE/K VALUE, X VALUE。 3.7.1.1 Xtal frq Set the central frequency of the crystal of the probe. Parameter range：0～10MHz Step：0.1 Operating procedure: By pressing the home key <...
  • Page 75 By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select CONFIG function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you ...
  • Page 76 By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< >, you select PROBE functional group. ...
  • Page 77 3.7.2.1 Mtlvel* Displays the velocity for the selected material and allows the user to input or velocity. Range: 1,000m/s～9,999m/s or 0.0394in/µs～0.3937in/µs The sound velocity can be adjusted by selecting the functional item MTLVEL on the right-hand of the functional keyboard, it will enable you to shift between coarse and fine adjustment.
  • Page 78 3.7.2.2 Thickness* The user can input the thickness value of the test piece. Parameter range: 5~50mm The thickness value can be adjusted by selecting the functional item THICKNESS on the right-hand of the functional keyboard, it will enable you to shift between coarse and fine adjustment.
  • Page 79 By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select PIECE function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you ...
  • Page 80 3.7.3 Calib (calibration of the probe) For the convenience of the operator the procedure for determining the probe zero point and the sound velocity of the test material, is part of the standard calibration function built into the instrument. Any additional calibration of the probe can be carried out according to chapter 4. Straight beam probes can be calibrated according to the following method, however angle beam probes initially need to be calibrated on X-VALUE and ANGLE, and then only calibrated according to the following method.
  • Page 81 11． And then apply couplant and couple the probe to the thicker calibration standard (100mm). 12． Press the function key < > next to the selection titled CALIB begin to calibrate. The value in the function box will show “S-REF2?” The function A START/A WIDTH will automatically be highlighted and turn the function knob(this will shift the starting point of the A-Gate)until the A-Gate lies over the echo corresponding to the thicker standard’s thickness.
  • Page 82 By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select CALIB function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you ...
  • Page 83 By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select CALIB function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you ...
  • Page 84 And then adjusting parameters by way of the fast rotary knob.  3.7.3.4 Mtlvel/p_delay This multipurpose functional menu is used to display material velocity and to display probe delay .And operator presses the same more than once to shift between the two functions. Following the calibration procedure, the calculated acoustical velocity and probe delay are displayed.
  • Page 85 3.7.4.1 Auto gain Adjust the gain so that the reference echo’s peak is as possible to 50% of full screen height. And then record the reference dB. This reference value will be stored in the instrument until manually changed. Options: 50%/OFF Operation: By pressing the home key <...
  • Page 86 And then adjusting the state of A Gate by way of the fast rotary knob  A WIDTH: Set the position of A -Gate width. Operation: By pressing the home key < > immediately returns to the home Menu list. ...
  • Page 87 full screen height(FSH).Record the reference dB. The box will show “------”,without Operation: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu. ...
  • Page 88 properly adjusted for the specific measurement application Operation: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< >...
  • Page 89 3.8.1.1 File no/ file no Selects stored data set and data logger files. This multipurpose functional menu is used to select the file of A-scan and to select the file of thickness reading. And operator presses the same more than once to shift between the two kinds of file stored mode.
  • Page 90 6. If the current channel is locked, the settings will not be saved. 3.8.1.2 File open You can recall A-scan waveform ; the thickness value can’t be recalled.Your instrument will then be provided with all the test-relevant technical features that existed at the moment of the setup. A-frozen display of the stored A-scan appears.
  • Page 91 By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select MEMS function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you ...
  • Page 92 to the current group No., otherwise it will not work. 2. Ensure that the current saving mode is set correctly. 3. If you need to download the DAC curve to PC, please adjust the settings and DAC parameters first, then save the data. 4.
  • Page 93 REF1 OPEN: The function is used for recalling the reference wave-1. Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu. ...
  • Page 94 REF2 OPEN: The function is used for recalling the reference wave-2. Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu. ...
  • Page 95 REF3 OPEN: The function is used for recalling the reference wave-3. Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu. ...
  • Page 96 REF4OPEN: The function is used for recalling the reference wave-4. Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu. ...
  • Page 97 By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select FILES functional group. ...
  • Page 98 3.8.3.3 Chan save The function can store the detecting parameters to detecting channel No. Options: ON/OFF Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu. ...
  • Page 99 By pressing the function key < > on the right –hand of the Functional keyboard , you  select RECSPEED function. And then adjusting parameters by way of the fast rotary knob.  3.8.4.2 Video rec The function is used for recording the A-scan video. Options: ON/OFF Operating procedure: By pressing the home key <...
  • Page 100 And then turning round the fast rotary knob to carry out the process.  3.8.4.4 Vedio del The function is used for deleting the A-scan video recorded. Options: ON/OFF Operating procedure: By pressing the home key < > immediately returns to the home Menu list. ...
  • Page 101 Note DAC curve and DCS curve can’t be started at the same time. ： 3.9.1 Config Configuration function menu includes DACMOD，DACSTA，STARTMOD functions. 3.9.1.1 Dacmod The function is used for select DAC or TCG curve; the TCG function displays reflectors of equal size at equal A-scan amplitudes, regardless of the reflector’s depth in the test material.
  • Page 102 By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select DAC functional group.  By pressing the same menu key< > again to enter this function menu. ...
  • Page 103 3.9.2.1 A start/a width This multipurpose functional menu is used to set A-Gate start and to set A-Gate width. And operator presses the same more than once to shift between the two functions. A START: Operating procedure: By pressing the home key < >...
  • Page 104 When the value of the RECORD function changes from 0 to1, you have record the first DAC reference point. Note that the largest echo to cross the A-Gate will treated as the reference echo. The gain value at which this point is recorded becomes the “baseline” gain value. Options: ON/OFF Operating procedure: By pressing the home key <...
  • Page 105 3.9.3 Revise After reference points are recorded, their values may be manually adjusted, or new points may be manually input. Edit points or input additional points, the system offer two kinds of revise mode: revise mode and reference index. 3.9.3.1 Revmode/refindex This multipurpose functional menu is used to select revise mode and to elect the desired point number.
  • Page 106 By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select REVISE function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you ...
  • Page 107 3.9.3.3 Ref pos/ref amp This multipurpose functional menu is used to set reference position and to set reference amplitude. And operator presses the same more than once to shift between the two functions. REF POS: In reference position mode, user can edit the information of horizontal position of the recorded point.
  • Page 108 select REF AMP function. And then adjusting parameters by way of the fast rotary knob.  3.9.3.4 Reviseref In reference amplitude mode, after editing the information of horizontal position or amplitude of the recorded point, the function will confirm the edit; update the information of reference echo.
  • Page 109 By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select DAC functional group.  By pressing the same menu key< > again to enter this function menu. ...
  • Page 110 3.9.5.1 Offset1/2 This multipurpose functional menu is used to set offset curve1 and to set offset curve2.And operator presses the same more than once to shift between the two functions. OFFSET curve1/2 is used to evaluate the size of the defect below the OFFSET curve3/4. It is usually the negative of the DAC OFFSET value.
  • Page 111 3.9.5.3 Offset3/4 This multipurpose functional menu is used to set offset curve1 and to set offset curve2.And operator presses the same more than once to shift between the two functions. OFFSET curve1/2 is used to evaluate the size of the defect below the OFFSET curve3/4. It is usually the positive of the DAC OFFSET value.
  • Page 112 By Pressing the menu key < > , you select EVAL function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you  select SIZEREF function. And then adjusting parameters by way of the fast rotary knob. ...
  • Page 113 By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select DGS functional group.  By pressing the same menu key< > again to enter this function menu. ...
  • Page 114 attached probe must be specified. The probe function menu includes XTAL FRQ， EFF DIAM， DEALY MTL and X VALUE . 3.10.2.1 Xtal frq The function is used for inputting the probe’s frequency rating. Parameter range：0～10MHz Step：0.1 Operating procedure: By pressing the home key < >...
  • Page 115 And then adjusting parameters by way of the fast rotary knob.  3.10.2.3 Dealy mtl The function is used for inputting the delay-line velocity by user. Parameter range：2260～6300mm Step：1mm Operating procedure: By pressing the home key < > immediately returns to the home Menu list. ...
  • Page 116 By pressing the function key < > on the right –hand of the Functional keyboard , you  select X VALUE function. And then adjusting parameters by way of the fast rotary knob.  3.10.3 Record 3.10.3.1 A start/a width This multipurpose functional menu is used to set A-Gate starting point and to set A-Gate width .And operator presses the same more than once to shift between the two functions.
  • Page 117 By Pressing the menu key < > , you select RECORD function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you  select A WIDTH function. And then adjusting parameters by way of the fast rotary knob. ...
  • Page 118 Operating procedure: By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select DGS functional group. ...
  • Page 119 3.10.4 Repair 3.10.4.1 Testatten The function specifies a sound attenuation value (in dB per inch or mm of material thickness) for the material from which the test piece is made. Parameter range：0~100dB/m Step: 0.01 Operating procedure: By pressing the home key < >...
  • Page 120 By pressing the function key < > on the right –hand of the Functional keyboard , you  select TRANS CORR function. And then adjusting parameters by way of the fast rotary knob.  3.10.4.3 Ref atten The function specifies a sound attenuation value (in dB per inch or mm of material thickness) for the material from which the test piece is made.
  • Page 121 By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select REPAIR function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you ...
  • Page 122 By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select DGS functional group. ...
  • Page 123 By pressing the same menu key< > again to enter this function menu.  By Pressing the menu key < > , you select CONFIG function menu.  By pressing the function key < > on the right –hand of the Functional keyboard , you ...
  • Page 124 By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select BSCAN functional group. ...
  • Page 125 By pressing the home key < > immediately returns to the home Menu list.  By Pressing the Page Up/Down key< > switches the layer of function group menu.  By pressing the menu key< > , you select BSCAN functional group. ...
  • Page 126 3.12.1 Gain step This functional menu is used to select the required gain step from the options below. Options: 0dB, 0.2dB, 0.5dB, 1.0dB, 2.0dB, 6.0dB and 12.0dB Operating procedure: 13． By pressing the dB-step Key key, the gain’s step graduation will change according to the options available.
  • Page 127 report of the thickness readings will be printed. 2. Should you wish to print any saved waveform data, the saved waveform data has to be recalled first before printing the report. If this is not done, the current waveform and its parameters will be printed.
  • Page 128 3.12.6 Zoom This functional menu is used to extend the details of the waveform by pressing the key. Operating procedure: 19． Intersect the waveform to be observed by activating the gate, press down the key, and the extended waveform will be displayed. 3.12.7 Save This functional menu is used to recording measured values, saving data.
  • Page 129 instrument and the PC. 24． Freeze the screen by pressing the Freeze key on the operation interface. Complete the program upgrade according to《UFDX5 Ultrasonic Detector Operation Instructions for Insight Processing Software》 3.12.10 Recalling the ex-factory settings If required users can recall the ex-factory parameter settings when turning on the instrument. Operating procedure: 25．...
  • Page 130 the thickness values. 3.12.12 Self-test run If required by user,the system will self-test run. , when turning on the instrument. Operating procedure: 27． Turn on the instrument. When the startup LOGO for Turning on the instrument is displayed on the screen, and sound the second ringing, please press down the freeze key .The system will then self-test run.
  • Page 131 Chapter IV. Calibrating the Instrument and Measuring Prior to carrying out any inspection task, it is necessary that the instrument be calibrated for sound velocity, pitch interval and probe delay, according to the test piece and to conform with the test specifications which might apply to the test application.
  • Page 132 4.1.2 Calibrating with unknown MTLVEL Operating procedure: 32． First enter an estimated sound velocity value. 33． Select Double Gate mode by adjusting the gate logic. 34． Couple the probe to a calibration test block of a known thickness and whose material is similar to that of the test piece.
  • Page 133 48． Adjust the gate heights, so that they are at the same positions of the front edges of two standard echoes. 49． Adjust the sound velocity, until it displays the thickness value of the standard test block. 50． Set the Gate Logic to Single-Gate mode, i.e. Positive or Negative logic. The pitch interval measured at this point is the pitch interval of the primary echo.
  • Page 134 sound velocity. 4. Calibration of the probe zero point. Repeat the procedure above, and change the gate mode to plus or minus. Adjust the probe zero point to make the value of the sound path (S) return to 100. The zero point value obtained is the actual zero point value.
  • Page 135 adjust the gain so that the echo crosses the A-Gate and the highest peak in gate A is at approximately 80% of full-screen height. The highest peak must not be higher than 100%full-screen height. And then turn around the fast rotary knob to record the second DAC curve point. When the value of the RECCORD function changes from 1 to 2, you have recorded the second DAC curve point.
  • Page 136 DAC Curve 4.5 Application of the DGS curve The DGS feature allows the user to use a particular probe to compare a reflector in a test piece with a known standard reflector. When the DGS function is in use, echoes from equally sized reflectors at varying depths appear to lie along the DGS Reference Curve.
  • Page 137 Step3. Compensation for surface roughness. Select DGS —＞REPAIR function menu. When DGS is active, adjusting the instrument gain setting will result in an equal adjustment of the DGS curve position. Using REF ATTEN,AMPL CORRECT TESTATTEN and TRANS CORR function to compensate for the surface roughness of the test piece and varying coupling conditions.
  • Page 138 Where: S - is the Pitch interval d – is the depth of the defect; t - is the thickness of the test piece x – is the distance of the probe crystal to the probe’s front edge p – is the horizontal distance of the defect from the probe’s front edge; D - is the relative value of the defect depth, obtained by applying the following formula: Important requirements before commencing the inspection task.
  • Page 139 Chapter V. Communication with the Instrument The instrument is equipped with bi-directional full duplex RS232 and USB interfaces, for communication with a PC for data compilation and to control the serial printer for producing test reports. Connect the instrument to the PC’s serial port or USB interface, and access the special operation software, Data View, installed on the instrument from the PC.
  • Page 140 Chapter VI. Factors Influencing the Inspection Accuracy and the Evaluation of Defects Before operating the UFDX5, please read the following technical information, paying particular attention to important instructions that are given regarding the operation of the instrument. This is very important in order to avoid possible errors occurring when operating the instrument, which may result in invalid test results.
  • Page 141 6.1.3 Testing range It is important to understand that the echo, which is displayed on the screen, only represents part of the actual acoustic beam spread of the probe through the test piece. Operators should therefore be careful when comparing and interpreting the displayed information received from the area of the part under test, to the untested areas.
  • Page 142 will influence the measuring accuracy. 6.1.5 Measuring the remaining Wall Thickness of test pieces When measuring the remaining wall thickness of test pieces (e.g. pipes, containers and various reaction vessels whose internal surfaces might be corroded or eroded), an ultrasonic thickness gauge should be used, paying attention to the selection of the correct probe and inspection procedure.
  • Page 143 material (e.g. non-ferrous metals or plastics), the sound velocity could vary drastically through the test piece, therefore it will influence the measuring accuracy. If the material of the test piece being inspected is not isotropic, the sound velocity will vary as the operator scans in different directions.
  • Page 144 detecting the edge of the defect and determining its range. b. If the diameter of the acoustic beam is greater than the length of the defect, a comparison must be made between the maximum echo response of the defect, and the maximum echo response of an artificial defect. 6.3.1 Defect edging method The smaller the acoustic beam diameter of the probe is, the more accurate the edge definition is, and therefore the defect length can be determined more accurately.
  • Page 145 Chapter VII - Maintenance and repairs 7.1 Requirement on handling and the working environment Avoid dropping the instrument and exposing it to severe knocks and bumps. The instrument should not be operated in areas where there is excessive dust, damp, strong magnetic fields, grease and dirt, etc. Do not attempt to clean the casing with any type of solvent cleaner.
  • Page 146 7.3 Replacing the battery THE BATTERY USED IN THE INSTRUMENT GENERALLY HAS A SERVICE LIFE OF ± 3 YEARS. WHEN THE BATTERY REQUIRES REPLACING, THE PROCEDURE DETAILED BELOW SHOULD BE FOLLOWED BY THE USER: 52． Remove the four battery-cover retaining screws at the back of the instrument casing, and remove the battery cover plate.
  • Page 147 Note: 1. This instrument is a non-destructive inspection instrument used for the inspection of materials in industry. Under no circumstances should this instrument be used as a medical instrument. 2. The instrument is limited to use in a laboratory or an industrial environment. System Power Supply The instrument can be supplied power either with external power adaptor or Li ion battery.
  • Page 148 UFDX5 Portable Digital Color-LCD Ultrasonic Flaw Detector Appendix Appendix I: Notice to Operators 64． I) After purchasing the product from our company, you are kindly requested to complete the Warranty Registration Card and stamp it with your official company stamp. Please send one copy (I) and a copy of the official invoice to the User Service Dep.
  • Page 149 UFDX5 Portable Digital Color-LCD Ultrasonic Flaw Detector Appendix II: Performance Specifications 1.UFDX5 2.X SERIES range 1~15000mm resolution 0.01mm(<100mm) 1mm(>100mm) velocity 1000~15000m/s 20 fixed sound velocity Display delay -20~3400us resolution: 0.1us Probe delay 0~99us resolution: 0.01us Auto calibration Measurement and setting of sound velocity and probe delay using two known calibration echoes (2-point calibration ) Linear error Horizontal linearity error≤0.1%...
  • Page 150 UFDX5 Portable Digital Color-LCD Ultrasonic Flaw Detector Gate /measurement /alarming Gate A/B separated gates Result of Measurement 5 testing display sections including one main display section used to magnifying display ,can choose measurement content SA/SB/DA/DB/PA/PB/A%A/A%B/dBtA/dBtB/dBrA/dBrB/SBA/DBA/PBA/LA/L Curve surface correction Correct the measurement value of curve surface according to angle of probe , thickness and diameter of workpiece Alarm All gates can...
  • Page 151 UFDX5 Portable Digital Color-LCD Ultrasonic Flaw Detector Screen saver Wait /character /shutdown Standard delivery Main unite Straight probe Angle probe Cable Power adaptor Battery pack Operating manual Carrying case Couplant 1 bottle Optional accessory RF output benefited for inspection toward thin-wall material and profoundly research and sizing analysis Printer directly copy display screen/waveform /thickness statistics...
  • Page 152 UFDX5 Portable Digital Color-LCD Ultrasonic Flaw Detector 3 A-scan waveform modes Normal /Character/ Strength GUI theme 5 GUI color themes: simple/classical/gray/bright light/ dark light, adjustment of themes by setting color of characters ,A-Scan wave ,background Echo coded 2 color coded modes: coordinates and echoes Screensaver Wait /character /shutdown Gate /measurement /alarming...
  • Page 153 UFDX5 Portable Digital Color-LCD Ultrasonic Flaw Detector Curve surface correction Correct the measurement value of curve surface according to angle of probe , thickness and diameter of workpiece Lock All menu can independently be locked avoiding adjustment of parameters related to system setup ; APPL data also can be locked avoiding misplay deletion of data Screen saver Wait /character /shutdown...
  • Page 154 UFDX5 Portable Digital Color-LCD Ultrasonic Flaw Detector Appendix IV: Interface The instrument is equipped with a bi-directional full duplex RS232 interface, used to achieve communication with a PC for further data management via software, and to control the serial printer for immediate printing of reports showing defects which may have been detected. Definitions of the interfaces can be found below.
  • Page 155 UFDX5 Portable Digital Color-LCD Ultrasonic Flaw Detector Appendix V: Terms This appendix lists the terminology used throughout this operating manual, to explain the principals of ultrasonic techniques used for the non-destructive inspection of components. A good understanding of the exact meaning of these terms will be helpful to ensure the correct use of this operating manual. Pulse amplitude: voltage amplitude of a pulse signal.
  • Page 156 UFDX5 Portable Digital Color-LCD Ultrasonic Flaw Detector 83． Scan speed: ratio of cross axis to corresponding pitch interval on the fluorescent screen. 84． Delayed scan: a kind of scanning way where the starting part of the time base will not show in type A or B display.
  • Page 157 UFDX5 Portable Digital Color-LCD Ultrasonic Flaw Detector 98． Blockage: a phenomenon occurred in the moment after the receiver receives the sending pulse or strong pulse signal where its sensitivity drops or it fails. 99． Gain: the log form of voltage amplification of the receiving amplifier of the ultrasonic detector. It is expressed by dB.
  • Page 158 UFDX5 Portable Digital Color-LCD Ultrasonic Flaw Detector Appendix VI: National Standard and Industrial Standard Concerning Ultrasonic Flaw Detection The following national and industrial standards applicable to ultrasonic flaw detection comply when operating the UFDX5 ultrasonic flaw detector :- 1. GB/T 12604.1–90 Terms for Non-destructive Detection Ultrasonic Detection 2.
