Summary of Contents for Protec PT-POS8PB2SM-OT
- Page 1 PT-POS8PB2SM-OT Ｑｕｉｃｋ Ｉｎｓｔａｌｌａｔｉｏｎ Ｇｕｉｄｅ www.procetpoe .com...
- Page 2 Ｄｅｃｌａｒａｔｉｏｎ This document belongs to PROCET company. It is not allowed to reproduce modify without the original author's permission. It is PROCET's policy to improve its products as new technology, components, software, and firmware at any time. PROCET, therefore, reserves the right to change specifications without prior notice.
- Page 3 Ｏｖｅｒｖｉｅｗ Ｔｈｅ ｉｎｓｔａｌｌａｔｉｏｎ Ｇｕｉｄｅ ｆｏｒ ＰＴ－ＰＯＳ８ＰＢ２ＳM-OT ａｎｄ ｍａｉｎｌｙ ｉｎｔｒｏｄｕｃｅｓ ｔｈｅ ｈａｒｄｗａｒｅ ｓｐｅｃｉｆｉｃａｔｉｏｎ， ｉｎｓｔａｌｌａｔｉｏｎ ｍｅｔｈｏｄｓ， ａｎｄ ｐｒｅｃａｕｔｉｏｎｓ ｏｆ ｔｈｅ ｉｎｓｔａｌｌａｔｉｏｎ． Ｔｈｅｒｅ ｍａｙ ｂｅ ｄｉｆｆｅｒｅｎｃｅｓ ｉｎ ｔｈｅ ａｐｐｅａｒａｎｃｅ ａｎｄ ｃｏｎｆｉｇｕｒａｔｉｏｎ ｆｒｏｍ ｏｔｈｅｒ ｍｏｄｅｌｓ． Ａｌｌ ｐｒｏｄｕｃｔ ｉｍａｇｅｓ ｉｎ ｔｈｉｓ ｍａｎｕａｌ ａｒｅ ｆｏｒ ｉｌｌｕｓｔｒａｔｉｏｎ ｐｕｒｐｏｓｅｓ ｏｎｌｙ ａｎｄ ｍａｙ ｄｉｆｆｅｒ ｆｒｏｍ ｔｈｅ ａｃｔｕａｌ ｐｒｏｄｕｃｔ． Ｔｈｉｓ ｍａｎｕａｌ ｉｎｃｌｕｄｅｓ ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｃｈａｐｔｅｒｓ： １． Ｐｒｏｄｕｃｔ Ｉｎｔｒｏｄｕｃｔｉｏｎ． Ｉｎｃｌｕｄｉｎｇ ｔｈｅ ｂａｓｉｃ ｆｕｎｃｔｉｏｎｓ ａｎｄ ｓｐｅｃｉｆｉｃａｔｉｏｎ ｏｆ ＰＴ－ＰＯＳ８ＰＢ２ＳＭ-OT， ａｓ ｗｅｌｌ ａｓ ｔｈｅ ｐｒｏｄｕｃｔ ａｐｐｅａｒａｎｃｅ ａｎｄ applications ｉｎｔｒｏｄｕｃｔｉｏｎ． ２． Ｉｎｓｔａｌｌａｔｉｏｎ Ｉｎｔｒｏｄｕｃｔｉｏｎ． Ｉｎｔｒｏｄｕｃｉｎｇ ｔｈｅ ｐｒｅｐａｒａｔｉｏｎ ｗｏｒｋ ａｎｄ ｐｒｅｃａｕｔｉｏｎｓｂｅｆｏｒｅ ｉｎｓｔａｌｌｉｎｇ ｔｈｅ ｐｒｏｄｕｃｔ． ３． Ｐｒｏｄｕｃｔ Ｉｎｓｔａｌｌａｔｉｏｎ． Introducing how to install this product. 4. Spare Parts Information. Introducing the spare parts information for this product. Ｆｏｒ Ｗｈｏｍ Network Engineers Network Administrators Field Technicians Ｏｖｅｒｖｉｅｗ...
-
Page 4: Table Of Contents
Ｔａｂｌｅ ｏｆ Ｃｏｎｔｅｎｔｓ １． Ｉｎｔｒｏｄｕｃｔｉｏｎ １．１ Ｉｎｔｒｏｄｕｃｔｉｏｎ..............01 1.2 Ａｐｐｅａｒａｎｃｅ..............01 1.3 Ｓｐｅｃｉｆｉｃａｔｉｏｎ............. 03 1.4 Admin Interface............2. Ｉｎｓｔａｌｌａｔｉｏｎ Preparation 2.1 Ｐａｃｋａｇｅ Ｃｏｎｔｅｎｔｓ．．..........07 2.2 Ｉｎｓｐｅｃｔｉｏｎ..............07 ３． Ｉｎｓｔａｌｌａｔｉｏｎ 3.1 Ｐｏｌｅ Ｉｎｓｔａｌｌａｔｉｏｎ．............09 3.2 Ｇｒｏｕｎｄｉｎｇ..............11 3.3 Ｃｏｎｎｅｃｔｉｏｎ..............12 Ａｃｃｅｓｓｏｒｉｅｓ... -
Page 5: １． Ｉｎｔｒｏｄｕｃｔｉｏｎ
１． Ｉｎｔｒｏｄｕｃｔｉｏｎ １．１ Ｉｎｔｒｏｄｕｃｔｉｏｎ ＰＴ－ＰＯＳ８ＰＢ２ＳＭ-OT ｉｓ ａｎ ｏｕｔｄｏｏｒ－ｒａｔｅｄ ＰｏＥ ｓｗｉｔｃｈ． Ｅｎｃｌｏｓｅｄ ｉｎ ａｎ ＩＰ６７ Ｒｅｆｌｅｃｔｉｖｅ ｍｅｔａｌ ｃａｓｅ ｗｉｔｈ ａ ｓｅａｌｉｎｇ ｇａｓｋｅｔ ｔｈａｔ ｐａｓｓｅｓ ｔｅｎｓｉｏｎ， ｂｅａｒｉｎｇ， ｃｏｒｒｏｓｉｏｎ， ａｎｄ ａｇｉｎｇ ｔｅｓｔｓ ｆｏｒ ＩＰ６７ ａｐｐｌｉｃａｔｉｏｎｓ． Ｐａｓｓ ｔｈｅ ｓａｌｔ ｓｐｒａｙ ｒｅｓｉｓｔａｎｃｅ ｔｅｓｔ． Ｉｎｃｌｕｄｉｎｇ １ ＡＣ ｉｎｐｕｔ ｐｏｒｔ， ２ ＳＦＰ １Ｇ／２．５Ｇ ｆｉｂｅｒ ｓｌｏｔ， １ ｍｕｌｔｉ－ｆｕｎｃｔｉｏｎ ｉｎｔｅｒｆａｃｅ， ａｎｄ ８ ＰｏＥ ｏｕｔｐｕｔ ｐｏｒｔ ｗｉｔｈ ６ＫＶ （１０／７００ｕｓ） ｓｕｒｇｅ ｐｒｏｔｅｃｔｉｏｎ， ｐｒｏｖｉｄｅｓ ５５Ｖｄｃ， １．６４Ａ ｐｏｗｅｒ ｆｏｒ ｒｅｍｏｔｅ ＰＤｓ ｏｖｅｒ ４ ｐａｉｒｓ ａｔ １０／１００／１０００Ｍｂｐｓ． Ｔｈｅ ｔｏｔａｌ ｏｕｔｐｕｔ ｐｏｗｅｒ ｂｕｄｇｅｔ ｉｓ ３５０Ｗ． Ｉｔ ｗｏｒｋｓ ｗｉｔｈ ａ ｗｉｄｅ ｉｎｐｕｔ ｖｏｌｔａｇｅ ｏｆ １００－２４０Ｖａｃ ｗｉｔｈ ６ＫＶ ｓｕｒｇｅ ｐｒｏｔｅｃｔｉｏｎ ａｎｄ ｏｐｅｒａｔｅｓ ｆｒｏｍ －４０℃ ｔｏ ＋６５℃． Ｅｑｕｉｐｐｅｄ ｗｉｔｈ ａ ｄｅｔｅｃｔｉｎｇ ｃｈｉｐ ｉｎｓｉｄｅ ｗｈｉｃｈ ｍａｋｅｓ ｔｈｅ ＰｏＥ ｉｄｅｎｔｉｆｉｃａｔｉｏｎ ｈａｎｄｓｈａｋｅ ｗｉｔｈ ＩＥＥＥ８０２．３ａｆ／ａｔ／ｂｔ ＰＤｓ， ｃａｎ ｐｏｗｅｒ ＰＴＺ ｃａｍｅｒａｓ， ｗｉｒｅｌｅｓｓ ＡＰｓ， ｂａｓｅ ｓｔａｔｉｏｎｓ， ａｎｄ ｏｔｈｅｒ ＰｏＥ－ｐｏｗｅｒｅｄ ｄｅｖｉｃｅｓ． Ｐｒｏｔｅｃｔ ｎｏｎ－ＰｏＥ ｓｔａｎｄａｒｄ ｄｅｖｉｃｅｓ． Ｔｈｅ ｅｆｆｅｃｔｉｖｅ ｄｉｓｔａｎｃｅ ｉｓ １００ ｍｅｔｅｒｓ ｏｖｅｒ Ｃａｔ５ｅ／Ｃａｔ６ ｃａｂｌｅｓ． Ｅａｓｉｌｙ ｔｏ ｉｎｓｔａｌｌ ｗｉｔｈ ｉｎｓｔａｌｌａｔｉｏｎ ｋｉｔ （Ｓｏｌｄ ｓｅｐａｒａｔｅｌｙ）， ｎｏ ｎｅｅｄ ｔｏ ｏｐｅｎ ｔｈｅ ｅｑｕｉｐｍｅｎｔ． Ｔｈｅ ＰｏＥ ｓｗｉｔｃｈ ｃａｎ ｐｏｗｅｒ ｅｘｔｅｒｎａｌ ｄｅｖｉｃｅｓ ｗｉｔｈ ｓｅｌｅｃｔａｂｌｅ ２４Ｖ／１２Ｖ ｏｕｔｐｕｔ， ａｎｄ ｉｔｓ ４８５／２３２ ｉｎｔｅｒｆａｃｅ ｓｕｐｐｏｒｔｓ ｃｏｍｍｕｎｉｃａｔｉｏｎ ｗｉｔｈ ｅｘｔｅｒｎａｌ ｄｅｖｉｃｅｓ． odels with an “M” in the P/N include Ethernet and PoE management functionalities. It can be accessed and managed via a web browser, supporting configurations such as IP settings, port settings, VLAN settings, PoE settings, and factory reset. - Page 6 Ｓｉｄｅ Ｖｉｅｗ Ｐｒｏｔｅｃｔｉｖｅ Ｃｏｖｅｒ Ｉｎｔｅｒｆａｃｅ Product Ｌａｂｅｌ ２５．５±１ｍｍ Ｂｏｄｙ Ｈｅａｔ Ｓｉｎｋ Cable Glands ７４±１ｍｍ ２３５±１ｍｍ ３０９±１ｍｍ １－2 Side Ｖｉｅｗ Ｂｏｔｔｏｍ Ｖｉｅｗ ２３５±１ｍｍ ＡＣ Ｉｎｐｕｔ ３１．２±１ｍｍ Ｍｕｌｔｉ－ｆｕｎｃｔｉｏｎ Ｉｎｔｅｒｆａｃｅ Ｒｅｓｅｔ Button ３５ ９３±１ｍｍ ±１ｍｍ ２６．８±１ｍｍ ２２１．３±１ｍｍ ＳＦＰ Slot＊２ ＰｏＥ Ｏｕｔｐｕｔ ＊８ Ｐｏｗｅｒ LED Ｉｎｄｉｃａｔｏｒ １－3 Bottom Ｖｉｅｗ Ｉｎｔｒｏｄｕｃｔｉｏｎ ０２...
-
Page 7: Ｓｐｅｃｉｆｉｃａｔｉｏｎ
ＰｏＥ Ｌｅｄ Iｎｄｉｃａｔｅ Description Items Status The equipment is powered Solid Green Light Power Indicator Light Off The device is powered off/not plugged in/no powe Solid Yellow Light Data available, but no transfer / no activity PoE Data Flashing Yellow Data is being transferred Indicator Data not available or failed connection Light Off... - Page 8 Item Description Backplane Bandwidt 26Gbps MAC address capacit Support 4096 VLAN IDs VLAN Support 802.1Q VLAN Supports port-based VLANs across any combination of multiple ips. Packet Forw arding Rate 19.344Mpps ＰｏＥ Ｐｏｗｅｒ Ｐｉｎｓ 4,5(+)/7,8(-) 3,6(+)/1,2(-) Output 55Vdc 1.64A 90W Max per port, total power budget 350W Max IEEE 802.1d Standard Media Access Control Supports MAC address automatic learning and aging.
-
Page 9: Admin Interface
１．４ Ｍａｎａｇｅｍｅｎｔ Ｉｎｔｅｒｆａｃｅ After connecting to the device, enter the IP address of the login device in the browser address bar (e.g.: 192.168.31.192), the display page is as shown below, enter the account: admin; password: 123456; enter the device page. Note: The login computer IP needs to be in the same network segment as the login dev ice (e.g.: 192.168.1.*). - Page 10 Simple VLAN division can meet different needs and achieve directional communication. Display PoE power supply status; control PoE power supply: click the normal button to indicate normal PoE power supply, click the force button to indicate PoE forced power supply, click the close button to indicate PoE is forced to shut down and no power supply, etc.
-
Page 11: Ｉｎｓｔａｌｌａｔｉｏｎ Preparation
２． Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ ２．１ Ｐａｃｋａｇｅ Ｃｏｎｔｅｎｔｓ Ｏｐｅｎ ｔｈｅ ｂｏｘ ｏｆ ｔｈｅ ＰＴ－ＰＯＳ８ＰＢ２ＳM-OT ａｎｄ ｃａｒｅｆｕｌｌｙ ｕｎｐａｃｋ ｉｔ， ｔｈｅ ｂｏｘ ｓｈｏｕｌｄ ｃｏｎｔａｉｎ ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｉｔｅｍｓ： PT-POS8PB2SM-OT Operating Manual Protetive Cover ２．２ Ｉｎｓｐｅｃｔｉｏｎ Before installing the device, please feed it with an AC power source to check proper function first. Connect the SFP port to the data source/uplink for network access. - Page 12 AC Pow itch AC Input 24/12V 2A Output 232/485 Port PT-POS8P2SM-OT Grounding 100m ≤ PD X8 PoE Power&Data SFP Input Output ２－１ Ｄｅｖｉｃｅ Ｃｏｎｎｅｃｔｉｏｎ Ｃａｕｔｉｏｎｓ： １． Ｐｌｅａｓｅ ｒｅａｄ ｔｈｅ ｉｎｓｔｒｕｃｔｉｏｎｓ ｃａｒｅｆｕｌｌｙ ａｎｄ ｆｏｌｌｏｗ ｔｈｅ ｓｔａｎｄａａｒｄ ｏｐｅｒａｔｉｎｇ ｐｒｏｃｅｄｕｒｅｓ ｂｅｆｏｒｅ ｕｓｉｎｇ． ２． Ｔｈｅ ｄｅｖｉｃｅ ｒｅｑｕｉｒｅｓ ｇｒｏｕｎｄｉｎｇ． ３． Ｆｏｒ ｏｕｔｄｏｏｒ ｕｓｅ， ｐｌｅａｓｅ ｕｓｅ ＩＰ６７ ｎｅｔｗｏｒｋ ｃａｂｌｅｓ ｔｏ ｐｒｅｖｅｎｔ ｔｈｅ ｏｕｔｄｏｏｒ ｅｎｖｉｒｏｎｍｅｎｔ ｆｒｏｍ ａｆｆｅｃｔｉｎｇ ｔｈｅ ｎｅｔｗｏｒｋ ｑｕａｌｉｔｙ． ４． Ｐｌｅａｓｅ ｄｏ ｎｏｔ ｐｌａｃｅ ｔｈｉｓ ｄｅｖｉｃｅ ｏｎ ａｎ ｕｎｓｔａｂｌｅ ｂｏｘ ｏｒ ｔａｂｌｅ， ａｓ ｉｔ ｗｉｌｌ ｃａｕｓｅ ｓｅｒｉｏｕｓ ｄａｍａｇｅ ｉｆ ｉｔ ｆａｌｌｓ； Ｗｈｅｎ ｃｈｏｏｓｉｎｇ ｗａｌｌ ｍｏｕｎｔｉｎｇ， ｉｔ ｓｈｏｕｌｄ ｂｅ ｓｅｃｕｒｅｄ． ５． Ｓｕｆｆｉｃｉｅｎｔ ｓｐａｃｅ （ｇｒｅａｔｅｒ ｔｈａｎ ５ ｃｍ） ｓｈｏｕｌｄ ｂｅ ｒｅｓｅｒｖｅｄ ａｒｏｕｎｄ ｔｈｉｓ ｄｅｖｉｃｅ ｔｏ ａｌｌｏｗ ｆｏｒ ｐｒｏｐｅｒ ｈｅａｔ ｄｉｓｓｉｐａｔｉｏｎ． ６． Ｐｌｅａｓｅ ｄｏ ｎｏｔ ｐｌａｃｅ ｈｅａｖｙ ｏｂｊｅｃｔｓ ｏｎ ｔｈｉｓ ｄｅｖｉｃｅ． ０８ Ｉｎｓｔａｌｌａｔｉｏｎ Ｐｒｅｐａｒａｔｉｏｎ ...
-
Page 13: ３． Ｉｎｓｔａｌｌａｔｉｏｎ
３． Ｉｎｓｔａｌｌａｔｉｏｎ Ｔｈｉｓ ｐｒｏｄｕｃｔ ｉｓ ｓａｆｅ ｔｏ ｕｓｅ ｆｏｒ ｐｏｌｅ ｉｎｓｔａｌｌａｔｉｏｎ ３．１ Ｐｏｌｅ Ｉｎｓｔａｌｌａｔｉｏｎ Ｔｈｅ ｅｑｕｉｐｍｅｎｔ ｉｓ ｍａｉｎｌｙ ｉｎｓｔａｌｌｅｄ ｂｙ ｔｈｅ ｂｏｌｌａｒｄ ｔｏ ａｃｈｉｅｖｅ ｗａｔｅｒｐｒｏｏｆ ａｎｄ ｓｔａｂｌｅ ｗｏｒｋ， ｉｆ ｉｔ ｉｓ ｉｎ ａ ｈａｒｓｈ ｏｕｔｄｏｏｒ ｅｎｖｉｒｏｎｍｅｎｔ， ｐｌｅａｓｅ ｉｎｓｔａｌｌ ｔｈｅ ｐｒｏｔｅｃｔｉｖｅ ｃｏｖｅｒ ｐｒｏｐｅｒｌｙ． ３．１．１ Ｆｉｘ ｔｈｅ ｔｗｏ ｌａｒｇｅ ｂｒａｃｋｅｔｓ ｏｎ ｔｈｅ ｂａｃｋ ｏｆ ｔｈｅ ｓｗｉｔｃｈ ｗｉｔｈ ｔｈｅ ｆｏｕｒ Ｍ５×２５ ｂｏｌｔｓ ａｎｄ Ｍ５ ｎｕｔｓ ｔｈｒｏｕｇｈ ｔｈｅ ｃｉｒｃｕｌａｒ ｈｏｌｅｓ． Ａｓ ｓｈｏｗｅｄ ｉｎ ３－１． Circular hol ３－１ Ｐｏｌｅ Ｉｎｓｔａｌｌａｔｉｏｎ 3.1.2 Ｔｏ ｓｅｃｕｒｅ ｔｈｅ ｐｒｏｄｕｃｔ ｏｎｔｏ ａ ｓｕｉｔａｂｌｅ ｐｏｌｅ， ｕｓｅ ｆｏｕｒ Ｍ６×１５０ ｂｏｌｔｓ ａｎｄ Ｍ６ ｎｕｔｓ ｔｈｒｏｕｇｈ ｔｈｅ ｒｅｃｔａｎｇｕｌａｒ ｈｏｌｅｓ．Ａｓ ｓｈｏｗｅｄ ｉｎ ３－２． Ｉｎｓｔａｌｌａｔｉｏｎ ０９... - Page 14 Body Mounting Hole Fastening Hole ３－2 Ｐｏｌｅ Ｉｎｓｔａｌｌａｔｉｏｎ ３．１．３ Ｔｉｇｈｔｅｎ ｔｈｅ ｓｃｒｅｗｓ ｔｏ ｃｏｍｐｌｅｔｅ ｔｈｅ ｉｎｓｔａｌｌａｔｉｏｎ． Ｃａｕｔｉｏｎ: Ｔｏ ｅｎｓｕｒｅ ａ ｂｅｔｔｅｒ ｐｒｏｔｅｃｔｉｏｎ ｆｏｒ ｏｕｔｄｏｏｒ ＰＤ， ｉｔ ｉｓ ｒｅｃｏｍｍｅｎｄｅｄ ｔｏ ｉｎｓｔａｌｌ ｔｈｅ ｐｒｏｔｅｃｔｉｖｅ ｃｏｖｅｒ． １０ Ｉｎｓｔａｌｌａｔｉｏｎ ...
-
Page 15: Ｇｒｏｕｎｄｉｎｇ
３．２ Ｇｒｏｕｎｄｉｎｇ ＰＲＯＣＥＴ ＰｏＥ Ｓｗｉｔｃｈ ＰＴ－ＰＯＳ８ＰＢ２ＳＭ - O T ｈａｓ ｔｈｅ ｆｏｌｌｏｗｉｎｇ ｇｒｏｕｎｄｉｎｇ ｓｏｌｕｔｉｏｎｓ ｆｏｒ ｒｅｆｅｒｅｎｃｅ ｄｕｒｉｎｇ ｃｏｎｓｔｒｕｃｔｉｏｎ： Ｉｆ ｔｈｅ ｉｎｓｔａｌｌａｔｉｏｎ ｉｓ ｉｎ ｔｈｅ ｃｏｍｐｕｔｅｒ ｒｏｏｍ， ｉｔ ｃａｎ ｂｅ ｃｏｎｎｅｃｔｅｄ ｔｏ ｔｈｅ ｄｅｄｉｃａｔｅｄ ｇｒｏｕｎｄｉｎｇ ｂｕｓｂａｒ ｉｎ ｔｈｅ ｒｏｏｍ． Ｔｈｅ ｇｒｏｕｎｄｉｎｇ ｂｕｓｂａｒ ｉｓ ａ ｃｏｎｎｅｃｔｉｎｇ ｃｏｎｄｕｃｔｏｒ ｂｅｔｗｅｅｎ ｔｈｅ ｇｒｏｕｎｄｉｎｇ ｂｏｄｉｅｓ ｏｆ ｔｈｅ ｂｕｉｌｄｉｎｇ， ｓｕｃｈ ａｓ ｆｌａｔ ｉｒｏｎ， ｆｌａｔ ｓｔｅｅｌ， ｎａｎｏｍａｔｅｒｉａｌ ｃｏｎｄｕｃｔｏｒｓ， ｃｏｐｐｅｒ－ｃｌａｄ ｓｔｅｅｌ， ｅｔｃ． Ｐｌｓ ｒｅｆｅｒ ｔｏ ｔｈｅ ｆｉｇｕｒｅ ３－６． GND Termi M4 screw Grou nding busbar ３－６ Ｇｒｏｕｎｄｉｎｇ For the safety of personnel and equipment in an environment without dedicated grounding equipment, a simple grounding device can be ｌｓ ｒｅｆｅｒ ｔｏ ｔｈｅ ｆｉｇｕｒｅ ３－7．... -
Page 16: Ｃｏｎｎｅｃｔｉｏｎ
GND Terminal M4 screw Ground Soil 2200 ３－７ Ｓｉｍｐｌｅ ｇｒｏｕｎｄｉｎｇ ３．３ Ｃｏｎｎｅｃｔｉｏｎ ＲＪ４５ Ｐｏｒｔ（ａｓ ｓｈｏｗ ｉｎ ３－８） 3.3.1 Remove the metal seals from the product. There are a total of five seals to be removed; here, one RJ45 port is used as an example. ３．３．２ Slide the metal seal components onto the Ethernet cable in the following order (the waterproof rubber stopper is not cut diagonally by default), and then crimp the RJ45 connector. - Page 17 RJ45 Joint bod Connector Clamping cla Cat5e/ Cat6 Ｃａｂｌｅ Sealing nut Flat Washers Rubber seal PoE Output*8 Removed metal seals ３－８ ＲＪ４５ Ｐｏｒｔ Ｃｏｎｎｅｃｔｉｏｎ ＡＣ Ｐｏｒｔ（ａｓ ｓｈｏｗ ｉｎ ３－９） 3.3.3 The AC input port uses screw terminals for connection. The AC input port has indicator markings to define the three pins, labeled as Ground (G), Neutral (N), and Line (L).
- Page 18 ＳＦＰ Ｐｏｒｔ（ａｓ ｓｈｏｗ ｉｎ ３－１０） 3.3.7 Thread the waterproof components onto the fiber optic cable in order.. 3.3.8 Insert the SFP optical module (not included) into the SFP slot. 3.3.9 Finally, tighten the waterproof components onto the product's SFP interface. SFP Port SFP optica l module Correct Slot...
-
Page 19: Ａｃｃｅｓｓｏｒｉｅｓ
Cable outer diameter range : 5-12mm Tightening Torsion:：19-25kgf.cm 153.5mm 153.5mm Breaking Torq ue：50kgf.cm 1-Inch Pole 4-Inch Pole Min Diameter：25mm Max Diameter：101.6mm ４－２ Ｄｉａｍｅｔｅｒ ｒａｎｇｅ ｏｆ ｔｈｅ ｉｎｓｔａｌｌａｔｉｏｎ ｋｉｔ Ｆｒｏｎｔ Ｖｉｅｗ 234.8±1mm 153.5mm 80mm 60mm Ｂｏｔｔｏｍ Ｖｉｅｗ 71mm 45mm 77.1±1mm 234.8±1mm ４－３ Ｄｉｍｅｎｓｉｏｎｓ ｏｆ ｔｈｅ ｉｎｓｔａｌｌａｔｉｏｎ ｋｉｔ １５ Ａｃｃｅｓｓｏｒｉｅｓ... - Page 20 Qualification Card PASS Creative Lianjie Network Technology Co.Ltd ｗｗｗ．ｐｒｏｃｅｔpoe．ｃｏｍ...
