Summary of Contents for SmartCow SmartCam T1023
- Page 1 誤! 尚未指定自動圖文集項目。 SmartCam T1023/T1025 User Manual November 2024 User Manual – SmartCam T1023/T1025...
-
Page 2: Copyright And Legal Statement
No part of this document may be reproduced, translated, modified, published, distributed, transmitted, or displayed in any form or by any means, without the prior written permission from SmartCow AI Technologies Ltd. SmartCow ® is a registered trademark of SmartCow AI Technologies Ltd. Otherwise, you will be responsible for any infringement of copyright law. -
Page 3: Acknowledgements
• Ubuntu is a registered trademark of Canonical. All other product names or trademarks are properties of their respective owners. No ownership is implied or assumed for products, names or trademarks not herein listed by the publisher of this document. User Manual – SmartCam T1023/T1025... -
Page 4: Declaration Of Conformity
SmartCow RoHS environmental policy SmartCow is a global citizen for building digital infrastructure. We are committed to providing green products and services, which are compliant with European Union RoHS (Restriction on Use of Hazardous Substance in Electronic Equipment) directive 2011/65/EU and 2015/863, to be your trusted green partner and to protect our environment. -
Page 5: Warranty And Rma
SmartCow warrants that products will be free from defects in material and workmanship for 2 years (24 months), beginning on the date of invoice by SmartCow. SmartCow will provide free of charge warranty coverage to all the products manufactured and sold in case the purchased product is proven defective in material or workmanship under normal use during the warranty period. -
Page 6: Safety Precautions
• All cables and adapters supplied by SmartCow are certified and in accordance with the material safety laws and regulations of the country of sale. Do not use any cables or adapters not supplied by SmartCow to prevent system malfunction or fires. - Page 7 • Do not leave batteries in extremely hot environments, as this can cause flammable liquids or gases to leak and ignite. Do not subject batteries to extremely low air pressures, as this may cause flammable liquids or gases to leak, resulting in an explosion. User Manual – SmartCam T1023/T1025...
-
Page 8: Table Of Contents
1.4 – M I/O C ..............................11 ECHANICAL AND ONNECTIONS 1.5 – R ................................11 ANEL ONNECTIONS 2 – SETTING UP SMARTCAM T1023/T1025 ............................12 2.1 – P ....................................12 REREQUISITES 2.2 – G T1023/T1025 ........................12 ENERAL TEPS TO MART 2.3 –... -
Page 9: About Smartcam T1023/T1025
Mechanical and I/O Connections 1.5 – Rear Panel Connections 1.1 – Features and Benefits The following are the key benefits of SmartCam T1023/T1025: Advanced camera system with 5MP CMOS Rolling • Shutter Sensor Powered by NVIDIA ® Jetson ™ TX2 NX/Orin™ Nano •... -
Page 10: Specification
SONY Max. Image Resolution 2560H x 1920V Image Sensor Max. Frame Rate 30fps(2560x1920) Day/Night Mode Day/Night/Auto Effective Focal Length Lens Field of View D140.7°×H107°×V77.8° Focus Control Fixed M12 Lens Aperture F2.0 Iris Control Fixed type User Manual – SmartCam T1023/T1025... -
Page 11: Packing List
誤! 尚未指定自動圖文集項目。 1.3 – Packing List The following table lists the contents of the SmartCam T1023/T1025 package, except for the camera, which is included but not listed in this table. Sl. No. Item Description Bracket Wall mount bracket Bracket Pole mount bracket... -
Page 12: Mechanical And I/O Connections
1.4 – Mechanical and I/O Connections 1.5 – Rear Panel Connections These figures illustrate the various ports and connectors located at the bottom side of the SmartCam T1023/T1025 device, helping you to identify the appropriate points for establishing power supply and network. -
Page 13: Setting Up Smartcam T1023/T1025
2.1 – Prerequisites Electrical requirements To power the SmartCam T1023/T1025, you can connect a DC 12V 5A power supply to the power input jack. 2.2 – General Steps to Use SmartCam T1023/T1025 The following table lists the general steps to use SmartCam T1023/T1025. -
Page 14: Connecting 4G Antennas
3. Ensure all connection are tight and there is no gap between the connector and the port. Tip: Ensure that both antennas are pointing in the correct orientation for optimal signal reception. User Manual – SmartCam T1023/T1025... -
Page 15: Installing Camera Mounting
Fasten the camera to the mount bracket using the provided hex screws, washers, and nuts. Align and fasten the pole mount bracket to wall mount bracket with carriage screws, spring washers and nuts. Tip: Tighten the screws gradually and evenly to maintain stability. User Manual – SmartCam T1023/T1025... -
Page 16: Running The Smartcam Discovery Tool
Double-click the shortcut icon pointing to the executable file that is available at the default installation folder. C:\Program Files\SmartCow Discovery Tool You can view the camera’s name and IP address as shown in the following figure. User Manual – SmartCam T1023/T1025... -
Page 17: Accessing The Camera Remotely Via Ssh
For more information, see Running the SmartCam Discovery Tool on page 14. To remotely access your T1023 camera, use the discovered IP address and then run the following command to initiate the SSH session. ssh nvidia@192.168.xxx.xxx default password: nvidia User Manual – SmartCam T1023/T1025... -
Page 18: Camera Sensors Configuration
• Model: IMX335 SONY • Shutter mode: Rolling shutter • Lens type: Fixed • Resolution: 5 MP • Video device: /dev/video0 Procedure Mode Width Height Framerate 2560 1920 2560 1440 1920 1440 25/30 1920 1080 1280 1280 User Manual – SmartCam T1023/T1025... -
Page 19: Camera Sensor Capabilities
Adjust the position of y-axis of the min=1, max=100, step=1, image when digital zooming default=50 ae_lock Lock the current auto exposure gain 0: Disable (default) and shutter 1: Enable ae_max_shutter 0: 1/2s Choose the maximum auto User Manual – SmartCam T1023/T1025... - Page 20 Set the manual gain min= 10000, max=1280000, step=1000, default=1000 awb_lock Lock the current white balance 0: Disable (default) color temperature 1: Enable awb_mode Choose the while balance mode 0: AUTO (default) 1: MANUAL_GAIN 2: MANUAL_COLOR_TEMP 3: SUNNY User Manual – SmartCam T1023/T1025...
- Page 21 Enable infrared LED on night mode 0= Disable 1= Enable ir_led_level Adjust the level of infrared LED min=1, max=10, step=1, default=5 Valid when ir_led_enable is enabled als_level Get light sensor data read-only The unit of the value is 0.1lux User Manual – SmartCam T1023/T1025...
- Page 22 誤! 尚未指定自動圖文集項目。 ldc_level min=0, max=100, step=1, default=0 Adjust the lens distortion correction level User Manual – SmartCam T1023/T1025...
-
Page 23: A - Troubleshooting Faqs And Managing Cellular Network Connections
Topic: Troubleshooting Mobile Data Connectivity • Troubleshooting Network Connection • This section provides describes answers to frequently asked questions about SmartCam T1023/T1025, alongside detailed guidance on managing and troubleshooting mobile network connections. Troubleshooting and FAQs Problem Solution I am unable to discover any cameras after running Check that firewall access is enabled and that the the discovery tool. -
Page 24: Troubleshooting Network Connection
Depending on the connection mode, you can obtain the connection quality information from the following values: • Received Signal Strength Indicator (RSSI) • Reference Signals Received Power (RSRP) • Reference Signal Received Quality (RSRQ) • Signal-to-Interference-plus-Noise Ratio (SINR) User Manual – SmartCam T1023/T1025... - Page 25 SINR values. If only one of these values is satisfactory and the others are subpar, the connection may be unreliable. It is important to ensure that all of these parameters remain stable over time, as fluctuations can have an impact on connection reliability. User Manual – SmartCam T1023/T1025...
- Page 26 誤! 尚未指定自動圖文集項目。 Smartcow AI Technologies Ltd. www.smartcow.ai sales@smartcow.ai User Manual – SmartCam T1023/T1025...
