Rack lock (bus) DoorLock-RA4 – MANUAL | 1
ORDER-CODES:
,
,
,
KXC-RA4-IP1-R
KXC-RA4-IP1-L
KXC-RA4-IP2-R
KXC-RA4-IP2-L
DATASHEET KXC-RA4
Overview
The DoorLock-RA4 is a wired locking solution for IT racks and distribution cabinets. The DoorLock
offers the possibility of two-factor authentication via a touch PIN keypad and an RFID reader. In
addition, the position of the lever on the DoorLock is sensed via an integrated magnetic contact.
The DoorLock requires a suitable remote station for operation. This remote station is formed by the
network-capable devices AccessManager (SmartRelay) or SmartPDU, which act as both bus gateway
and power supply.
For central management, an AccessManager, SiteManager or AlarmManager is required in the
MAIN-DEVICE operating mode. Teach-in and configuration are performed entirely via the KentixONE
© Kentix GmbH. This file was automatically generated on 2024-12-30 01:28:04. Please visit
docs.kentix.com
for the
latest documentation.
Advertisement
Summary of Contents for Kentix DoorLock-RA4
- Page 1 DATASHEET KXC-RA4 Overview The DoorLock-RA4 is a wired locking solution for IT racks and distribution cabinets. The DoorLock offers the possibility of two-factor authentication via a touch PIN keypad and an RFID reader. In addition, the position of the lever on the DoorLock is sensed via an integrated magnetic contact.
- Page 2 Kentix accepts no liability for damage to the equipment or components resulting from incorrect installation. No liability is accepted for incorrectly programmed units. Kentix shall not be liable in the event of malfunctions, damage to property or other damage. Use of the products, transport and storage Protect the device during transport, storage and operation from Protect moisture, dirt and damage.
- Page 3 Rack lock (bus) DoorLock-RA4 – MANUAL | 3 Status LED (RED, GREEN) RFID reader unit (Mifare®, Mifare®DESFire®) Touch PIN Keyboard © Kentix GmbH. This file was automatically generated on 2024-12-30 01:28:04. Please visit docs.kentix.com for the latest documentation.
- Page 4 The Teach In Code is required to teach in the DoorLock. The 10-digit code is located both on the side and on the back of the DoorLock. © Kentix GmbH. This file was automatically generated on 2024-12-30 01:28:04. Please visit docs.kentix.com for the latest documentation.
- Page 5 An illustration of the SmartAccess system topology can be found here. Connection variant 1: To AccessManager SmartRelay The DoorLock-RA4 is connected to an AccessManager SmartRelay. By using the Kentix distributor box KXC-RA4-DB-BUS, up to 16 DoorLocks can be taught in at one AccessManager. Two DoorLocks and two door contacts can be connected to one distribution box.
- Page 6 This is included in every DoorLock-RA4 basic package. Connection variant 2: To Kentix SmartPDU The Kentix DoorLock-RA4 is connected to the system port of the SmartPDU. With one distributor box, a maximum of 2 DoorLocks and two door contacts can be connected per SmartPDU.
- Page 7 Installation Install only when open! Hole pattern for mounting The following hole pattern is required for mounting the DoorLock-RA4. The bar lock of the cabinet © Kentix GmbH. This file was automatically generated on 2024-12-30 01:28:04. Please visit docs.kentix.com for the...
- Page 8 Rack lock (bus) DoorLock-RA4 – MANUAL | 8 door must have a receptacle for an 8 mm square mandrel. © Kentix GmbH. This file was automatically generated on 2024-12-30 01:28:04. Please visit docs.kentix.com for the latest documentation.
- Page 9 Phillips screws for lower attachment of the DoorLock to the cabinet door Ordering information The DoorLock-RA4 is available with two directions of rotation of the square mandrel. With the DoorLock with the order number KXC-RA4-IPx-L, the square mandrel rotates counterclockwise / left- handed (viewing direction from inside on the mandrel) and with the order number KXC-RA4-IPx-R, the mandrel rotates clockwise / right-handed.
- Page 10 LED flashes green Access granted short tone, LED flashes green Access denied 3 long tones, simultaneously LED flashes 3x red © Kentix GmbH. This file was automatically generated on 2024-12-30 01:28:04. Please visit docs.kentix.com for the latest documentation.
- Page 11 Emergency access No signaling Table signaling Emergency opening If the power supply is lost, the KXC-RA4-EMS emergency opening set can be used. © Kentix GmbH. This file was automatically generated on 2024-12-30 01:28:04. Please visit docs.kentix.com for the latest documentation.
