VC-HUB
Instruction Manua
GLOBAL
Cellular Remote Monitoring & Control System
12V-48V DC SKU: VC-HUB-G
Thank you for choosing our remote monitoring device.
Here is some useful information you need to know.
1a. Box Contents
1 x VC-HUB Unit
1 x Power Fuse Loom
6x Sensor Tails
1b. Contents
1.
Content
1a. Box Contents
1b. Contents
1c. Technical Specifications
2.
Installation Guide
2a. Regulatory/Certificate of
Conformity
2b. Installation Instructions
2c. Health & Safety
3.
Installation Guide
3a. Installing your Device
4. Wiring Diagram
4a. Wiring Diagram
VC-HUB Control
VC-HUB Data
1c. Technical Specifications
Technical Specifications
Materials & IP Rating:
Size & Mounting
Connectivity:
Input Channels:
Output Channel:
Operating Power & Fuse:
Configuration:
Power Draw @ 12VDC
l
1 x Instruction Manual
1 x Safety and User Guide
1 x GPS Antenna - 2m
1 x 4G / 2G Blade Antenna
5.
VC-HUB DATA
6.
VC-HUB DATA
Remotely configurable settings
7.
Remotely Configurable
Settings
8. Setup Disclaimer &
Support
8a. Setup Disclaimer & Support
8b. Installing the App
9.
VC-HUB DATA
9a. Logging into your Cloud
Account
9b. Adding Your Device
9c. Device Tariff and Billing
9d. Connecting to your device
9e. Accessing Remotely
PC/ABS, A2 stainless fittings, TPU rubber, IP64
110mm x 95mm x 35mm, 4x M4 bolt
2G, 4G CAT1 LTE GLOBAL bands
Battery supply voltage, 5 analogue 0 - 72 VDC, boot pin,
100A CT, 2 NTC Temperature
4 via digital interface - connected add on required
7 - 70 VDC, 1A
Remote configuration by Cloud Portal
15 minute updates = 5mAh, 5 minute updates = 7mAh at
12V and Live connection = 75mAh
For Use on:
Configurable Hardware Settings
10. Setting Date & Time
10a. Setting Date & Time
10b. Setting Data Transmission
and Control Interval
10c. Calibrate Accelerometer and
Threshold
10d. Boot Pin - White Wire
10e. Cloud Based configurations
11.
Troubleshooting
11a. Device Status Codes
11b. Troubleshooting
11c. Safety Considerations
*11d. Warranty*
12. Company Details
1
Advertisement
Summary of Contents for Metrix VC-HUB
- Page 1 VC-HUB Instruction Manua GLOBAL Cellular Remote Monitoring & Control System 12V-48V DC SKU: VC-HUB-G Thank you for choosing our remote monitoring device. Here is some useful information you need to know. 1a. Box Contents For Use on: 1 x Instruction Manual...
- Page 2 ++ CAUTION! Do not use welding equipment without first disconnecting AND COMPLETELY REMOVING the VC-HUB. Damage caused by electrical welding is not covered by warranty. ++ +++ A common ground is required to monitor and use the Green, Yellow, Brown, Blue, Orange and White input channels.
- Page 3 ● Remove positive battery terminals from all batteries within the installation. Ensure that the equipment cannot be started and/or moved. ● Please take care when working near a battery for shock and explosion through spark. ● Please connect 1 lead at a time, do not hold 2 terminals at the same time. ●...
- Page 4 4a. Wiring Diagram Recommended wiring layout Yellow/Green/Brown/Blue/Orange can be switches for run time or detection. 12-16 Require additional parts purchase. 1. VC-HUB 2. 4G Antenna 3. GPS Antenna 4. 4G Mount & Pigtail 5. Fused Power 6. Yellow Wire 1M Tail 7.
- Page 5 All wires serve the same function; the colours labelled above aid in differentiating them for the wire diagram. Control on the VC-HUB Device Output Relay Module - Relay Position Status Channel 1 (1/0) Channel 2 (1/0) Channel 3 (1/0) Channel 4 (1/0)
- Page 6 Temperature (°C) Temperature (°F) Average Temperature (°C) Average Temperature (°F) Max Temperature (°C) Max Temperature (°F) Min Temperature (°C) Min Temperature (°F) External Temperature 1 & 2 Temperature (°C) Temperature (°F) Average Temperature (°C) Average Temperature (°F) Max Temperature (°C) Max Temperature (°F) Min Temperature (°C) Min Temperature (°F)
- Page 7 The section below is technical and used primarily for those who like to understand how our system functions. In your settings interface in the cloud platform, a simple click and set dashboard is available for all settings below. Settings only change during a cycle unless the device is in LIVE mode.
- Page 8 If you think something is missing or not working correctly, please email us. The VC-HUB is a self install product, for assistance please contact support and we can put you in touch with a local installer.
- Page 9 10b. Setting Data Transmission and Control Interval The VC-HUB unit can be configured to send data collected between 1-300 minutes, this data is then stored in the cloud for 30 days. For all timings over 5 minutes the device will sleep...
- Page 10 High Cost Network Charges Disclaimer Whilst we at Vesscomm and Metrix endeavour to get the best network rates possible for your devices included, this can change without notice or in some cases there are networks...
- Page 11 fitment of a new SIM, a charge applies. Metrix Advanced Technologies Ltd will repair or replace faulty product during this period at its sole discretion subject to the failure not being a result or caused by any of the following conditions:...
- Page 12 Installation of the product supplied with this manual constitutes full acceptance of these terms. If you do not agree to them, return the product, unused to Metrix Advanced Technologies Ltd for a full refund.
