- Page 1 EV CHARGER USER MANUAL （E Version : . ）...
-
Page 2: Table Of Contents
CONTENT Content 1. Safety Tips …………………………………………………………………………………… 2. Important Information ……………………………………………………………………… 2.1 Specified Use …………………………………………………………………………… 2.2 About this Manual ……………………………………………………………………… 3. Use of Products ……………………………………………………………………………… Product Appearance Size ……………………………………………………………… 3.2 Product Appearance ……………………………………………………………………… Ground Mounted Appearance Size ……………………………………………………… Product Performance Description …………………………………………………… LED Indicator Instruction ……………………………………………………………... -
Page 3: Safety Tips
.SAFETY TIPS Warning a. Please confirm the power level you are ready to connect before installation; b. The whole installation process needs professional personnel with electrician qualification to operate; c. Please do not operate under any circumstances that may cause electric leakage; d. -
Page 4: Important Information
. I MPORTANT INFORMATION . Specified Use ● This type of product is a charging pile that can charge electric vehicles in indoor and outdoor areas (such as electric vehicles). ● When installing and connecting the charging pile, the relevant regulations of the local country or government shall be observed;... -
Page 5: Use Of Products
.USE OF PRODUCTS . Product Appearance Size 255mm 126.5mm . Product Appearance Introduction [B]Display Screen [A]Surface Cover [D]Gun Holder [C]Panel [F]Output Wire [E]Charging Gun [H]Bottom Shell [G]Input Wire [J]The Anti-theft Screw [I]Fixing Plate [L]Emergency Stop Switch [K]Junction Box Cover [M]Waterproof Joint USER MANUAL... -
Page 6: Ground Mounted Appearance Size
.USE OF PRODUCTS . Ground Mounted Appearance Size [A]Pedestal [B]Display Screen [C]Charging Cable [D]Vehicle Connector [E]Input Wire [F]Wire protector [G]Column [H]Expandable Rubber Stopper ● The appearance shall be subject to the real object. ● When the charging operation is not performed, the charging cable shall be rolled up and put back into the cable slot. -
Page 7: Product Performance Description
.USE OF PRODUCTS . Product Performance Description Product Characteristics Product Item ZB -E K Series ZB -E K Series ZB -E K Series Output Power Operating Current Operating Voltage L/N/PE; L /L /L /N/PE; ＜ . kg Product Weight ＜ . kg Operating Frequency Cable Length . -
Page 8: Led Indicator Instruction
.USE OF PRODUCTS Reliability MTBF Warranty Years ， EN/IEC ， Safety Standard ， IEC . LED Indicator Instruction Charger Status Indicator Color Indicator Status Standby Blue Always on Insert the Plug Green Always on Charging Green Flashes once every S C P Abnormal Always on Over voltage/Under voltage... -
Page 9: Operation Guide
. Operation Guide . Operation Steps If the green light Open the charging seat Hold the charging gun flashes, the charging gun and connect the electric and confirm that there is correctly connected vehicle is no foreign matter Charging Procedure Scheduled Plug and Charge Scan code to... -
Page 10: Steps For Adding App Device
. Operation Guide . Steps For Adding APP Device Download method For IOS: Search Smart Life in the Apple Store to download and install it. For Android: Search Smart Life in the Google Store to download and install it. Step : Step : Step : Step :... - Page 11 . Operation Guide . . Steps for APP Appointment Time . . Charging Instructions on APP Instructions : Instructions : Instructions : Swipe Right to Charge Charging Record Charging Completed Insert the charging plug Users’ charging After charging, click into the charging port, history can be viewed to turn off...
-
Page 12: Installation Method
. Installation Method . Wallbox Installation Method . . The distance between the center of the wall drilling is shown in the figure, and the wall hole template is placed at a suitable height (the top surface of the wall hole template is at least . - Page 13 5. Installation Method . . After locking the fixed plate and L-shaped fixing strip with self tapping screws, hang the charger connected with the line onto the fixed plate and L-shaped fixing strip, lock the charger and the fixing strip from the side of the charger with flat head anti-theft screw φ...
-
Page 14: Ground Mounted Installation Method
. Installation Method . Ground Mounted Installation Method . . . Ground Mounted general assembly drawing A- （Ground Mounted General Assembly Drawing） [A]Charger [B]Vehicle Connector [C]Cross pan head screwM * [D]Flat head anti-theft screwφ [E]L-shaped fixing strip [F]Output Wire [G]Pan head anti-theft screwφ [H]Fixing plate [I] Wire protector [J]Input Wire... -
Page 15: Installation Environment Requirements
. Installation Method . . The power supply in the cement foundation has been embedded in the cable at one end of the outlet, and the column is erected at a suitable position on the cement foundation. Mark the cement foundation through the four bolt holes in the column flange plate, drill holes with a diameter of mm with a hole depth of mm with an impact drill, and then drive four M expansion bolts into... -
Page 16: Troubleshooting
. Troubleshooting . Troubleshooting Table Failure Causes and Solutions ● Check the power supply and cables to make sure they are not damaged in any way and properly connected and that the power supply is working properly. Unable to turn on ●... - Page 17 . Troubleshooting . Troubleshooting Table Causes and Solutions Failure ● Indicates that the charger input voltage is below the limit Vac(min). ● Contact an electrician to confirm that the supply voltage is The screen displays normal. "Low voltage fault" ● Please check whether the power supply load capacity is sufficient.
-
Page 18: Maintenance
7. Maintenance . Maintenance ● The whole maintenance process needs professional personnel with qualification to operate; ● The following routine maintenance items are only for reference, please refer to relevant standards and operation instructions for operation; ● Sunshade and rainproof measures shall be taken for the charging pile, and it is recommended to install a canopy outdoors;... -
Page 19: Model Number Definition
7. Maintenance Three-phase electrical diagram . Model Number Definition E XXX A Product flow （ ） Cable length (As shown in . . ) Initiating Mode (As shown in . . ) Basic Motherboard version Product power (As shown in . . ） Country of use Product design flow Product brand... -
Page 20: Important Matters
7. Maintenance . . Code Table for Charging Cable of Vehicle Connector Length Cable length Code . . Code Table for Initiating Mode Initiating mode Plug and charge mode Non-direct mode Key mode Code (*)Swipe card /smart app charging are optional function, which doesn’ t mean the unit you get has all the three initiating mode.
