Summary of Contents for Sarmert DC21
- Page 1 Owner’s Manual DC21 DC21...
- Page 2 CONTENTS IMPORTANT SAFETY INFORMATION ......01 WARRANTY AND SUPPORT ........... 03 PACKING LIST ..............04 SPECIFICATION ............... 05 GETTING STARTED ............06 Camera Overview .............. 07 Installation ................09 Calibrate Date/Time ............11 Format Micro-SD Card ............14 GENERAL SETTING ............14 Photo Size ................
- Page 3 PLAYING AND MANAGING VIDEOS ........ 18 Managing videos in WiFi ............ 18 Managing videos by Micro-SD card reader ......19 VOICE PROMPTS ............. 21 FAQ ..................23 NOTICE ................24...
- Page 4 IMPORTANT SAFETY INFORMATION Thank you for purchasing this Sarmert dashcam. This instruction manual contains information on how to operate your dashcam. Before using your dashcam, we recommend that you read through this manual to ensure correct usage. To improve the performance of the product, the contents of this manual are subject to change without prior notice.
- Page 5 ● Do not install the product in an environment with high humidity, or combustible gases or liquids. Doing so may cause an explosion and/or fire. ● Do not leave the product near infants, children, or pets. There is a risk of them swallowing small components, and/or their saliva may get into the product, causing an explosion due to a short circuit.
- Page 6 WARRANTY AND SUPPORT The dash cam comes with a full 12 months warranty. If you have any questions regarding your product, please do not hesitate to contact us via Amazon or drop us an email at support@sarmertvip.com. Queries are typically answered within 24 working hours.
- Page 7 PACKING LIST Check the box for each of the following items before installing the dash cam. DC21 Cigarette Lighter Power Dash Cam Cable (3.5m/11.6ft) Cable Clips x 5 Micro SD Card x 1 Pry Tool x 1 Warm Prompt 1: Please paste the electrostctic film near the top of the front windscreen of the car...
- Page 8 SPECIFICATION Model DC21 Aperture F=1.8 Color Black Memory 64GB SD Card 4M/3M/2M (Depends on the Photo Resolution set video resolution) H.264 Video Code Photo Format Video Compression Mode -2560x1440P Video Resolution -2304x1296P -1920x1080P WiFi Built-in(2.4GHz) USB Port Charging Power Interface 2.5A...
- Page 9 GETTING STARTED Tips Please read and understand tips before operating. ● Setting Date & Time: Please calibrate the date/time based on your location under the Date/Time by going to APP system settings menu, please refer to page 11 ● Before first time use, you MUST format the memory card in the camera to prevent any errors and for smooth operation, please refer to page 14 ●...
- Page 10 ● Camera Overview DC21 Description Sticker Mount Lens Micro-SD Card Slot Micro USB Charging Port WiFi Key -During recording,shortly press 1 (one) time to lock the video -Press and hold 3(three) seconds to turn ON/OFF WiFi -Press and hold 8(eight) seconds to RESET...
- Page 11 Color Status WiFi ON WiFi WiFi OFF Blingking Recording Solid Connecting to Power Bliking Rapidly Updating Firmware - 08 -...
- Page 12 ● Installation Install the front camera behind the rear view mirror. Remove any foreign matter and clean and dry the windshield before installation. Turn off the engine, gently push the card into the slot until it locks into place. (We alreay finish the setting up with 64GB SD card) Find a suitable place on windshield where don’t obstruct the driver’s field of vision and remove any foreign matter...
- Page 13 USB charging cable Turn on the engine. The dashcam will power up and start recording. Video files are stored on the microSD card. Turn off the engine. The dashcam will automatically stop recording and power down. - 10 -...
- Page 14 ● Calibrate Date/Time DC21 is built in WiFi, need to set Timezone first in APP so that the video date/time stamp will be correct. Search for the Kacam app in the Google Play Store or Apple App Store and install it on your smartphone.
- Page 15 DC21_Dashcam_****** DC21 Go to your There will show dash smartphone's Settings to cam model DC21 when turn on WiFi, then sel connected successfully, ect WiFi default named Check Real-time Video. “DC21_Dashcam_******” (6 randomly digital number is setting by our system), password is 12345678.
- Page 16 11/ 09/ 2022 11:33:01 00:00:00 1920*1080 Snapshot Stop recording, and Select the "Date/Time". press the to enter into The dash camera will system setting menu. automatically syncthronize to your mobile phone when connected to the APP. - 13 -...
- Page 17 Note ● WiFi Direct lets you directly connect your smartphone to your dashcam via Wi-Fi. ● The App is available for devices running Android 7.0 and higher, or iOS 9.0 and higher. ● Format Micro-SD Card Please connect to Kacam APP, using the function menu named "Format"...
- Page 18 ● Audio Recording — On(Default)/Off Dash cam has built-in microphone to record audio with video. You can choose to record mute video by choosing OFF. ● G-Sensor — Off/High/Medium(Default)/Low G-Sensor is a 3-axis impact gravitational accelerometer which is designed to detect physical and gravitational forces on the camera.
- Page 19 ● Date/Time Format This feature allows you to select the date format. ● Volume — Low/Medium(Default)/High/Off This feature allows you to set the volume level for the boot sound volume, prompt volume through camera’s internal built-in speaker. ● Boot Sound This feature allows you to turn ON/OFF camera button’s beep sound.
- Page 20 ● WiFi Name and Password WiFi SSID: DC21_Dashcam_****** (******is randomly digital number) WiFi Password: 12345678 DC21 is built-in 2.4G WiFi module. Note: The WiFi name and password cannot be changed. ● Default Settings Here you can restore all the settings to factory default settings.
- Page 21 You also can select files to download into your smartphone, please find these downloaded files in APP original interface menu named "Local Video". You can playback the video or edit the video files. 11/ 09/ 2022 11:33:01 00:00:00 Snapshot 1920*1080 DC21 - 18 -...
- Page 22 20:30 Recorder album 2021-0621-203026-0000003A... Select DC21 2021/06/20 20:05:10 ● Managing Videos by Micro-SD Card Reader Please remove the micro SD card from camera and insert it directly in your laptop if you have a micro SD card slot (otherwise please using a micro SD card reader).
- Page 23 DC21 Movie 220915000001A 220915000001B File named ******A=Front dash cam video file - 20 -...
- Page 24 Voice Description WiFi is On Default ON, after powered on, say it Press and hold Wi-Fi button for 3s to WiFi is Off switch off, say it After powered on and boot ringtone Recording Started /operate via App, say it Recording Stopped Operate via App, say it During recording once G-Sensor...
- Page 25 Wrong/bad/fake memory card or Memory Card Error memory card error, say it Sound as “Click” Take picture(s) via App, say it Firmware is Updating, FW updating starts and in Please DO NOT Turn Off progress, say it the Camera The Locked Files are Full, When locked files reach a certain Please Format TF Card proportion, say it...
- Page 26 Q: I can’t get live video on Kacam APP, what should I do? If can’t get live-video on APP, please turn off cellular data of Kacam APP, take iPhone and Google phone(Android 12) for example. Technical Service: support@sarmertvip.com Kacam Kacam Kacam Kacam - 23 -...
- Page 27 NOTICE This product complies with the radio interface requirements of the european community. This symbol means the product must not be discarded as household waste, and should be delivered to an appropriate and recycling helps protect natural resources, human health and the environment. For more information on disposal and recycling of this product, contact your local municipality, disposal service, or the shop where you bought this product.
- Page 28 from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 29 Product: Car Dashcam Model: DC21 Product Warranty: One-year Limited Warranty Customer Support: support@sarmertvip.com...
