- Page 1 LB5900 Series Power Sensor Option LAN Get Started Guide LadyBug Technologies, LLC 9290 W. Barnes Dr. Boise, ID 83709 707-546-1050 www.ladybug-tech.com LB5900-LAN QS Guide v2.0 Page 1...
- Page 2 Table of Contents Introduction & Notices ............................3 Notices ................................3 Additional Resources Available ........................3 What is covered in this manual ........................3 Overview ................................4 Usability ................................4 Power Source ..............................4 URL / Browser character information ......................4 IP Address: Self-Assign, Static, DHCP ......................
- Page 3 - Product Data Sheet What is covered in this manual This manual provides information to get the LAN based LB5900 series power sensor up and running. Please refer to the Programming guide, user manual and additional LAN documents for other application information.
- Page 4 Overview Usability LadyBug LAN interfaced power sensors can be used in a wide variety of applications and environments such as: Using a web browser and the sensor’s internal web power meter with Interactive IO Applications utilizing HiSLIP (High Speed LAN Instrument Protocol) ...
- Page 5 Once boot-up is complete and a connection is established, the connection method and static IP address can be changed through the System Settings menu using the sensor’s internal web page. Refer to the additional information in this document or the LAN programming guide for further details.
- Page 6 Get Started This section covers recommended steps to get your LB5900 series LAN sensor up and running quickly. Make Sure Power is Available LB5900 Series Power Sensors with Option LAN, are powered through the Ethernet cable using PoE (Power over Ethernet). Most computer Ethernet ports do not supply power, in which case a PoE injector or a router / switch with PoE should be utilized as shown in the images below.
- Page 7 Locate the IP Address The following assumes that LAN power sensor is set to its default settings. Upon power-up, the LED indicator will flash blue to indicate a DHCP search. If unsuccessful after 45 seconds, the sensor will default to its self-assigned static address. In either case, the sensor’s indicator will show green, indicating a successful self-test.
- Page 8 Figure 1 - Router Client List Screen Alternatively, to locate the IP address of a LadyBug power sensor on a Windows PC, you can use either of two methods: the Address Resolution Protocol (ARP) or the nslookup tool. Here's how to...
- Page 9 Figure 2 – Windows Power Shell showing ARP Table Figure 3 - Using the nslookup tool Note: After locating the IP address, note it for future use. LB5900-LAN QS Guide v2.0 Page 9...
- Page 10 Static IP Connection Summary (from factory default settings) When a LadyBug LAN power sensor is first attached to the Ethernet port, it is ready to accept a DHCP address, this will occur if a router is present, and a Static IP address will NOT be available.
- Page 11 Connect to the Sensor and Test Once the sensor's IP address has been identified, various software applications can interact with it. However, any device seeking to access the sensor must be within the same LAN (Local Area Network). While connections outside of the LAN are possible, the subject is beyond the scope of this Guide.
- Page 12 Figure 5 – Left Power Meter Web Page, Center Interactive IO, Right System Settings Change Sensor Connection Mode (DHCP, Static, Self-Assign) Once the power sensor is connected and the web power meter is functioning, changes can be made to the LAN connectivity options. This example details changing the sensor from its default DHCP setting, to a static address.
- Page 13 Using NI-VISA Interactive Control Note, the images and examples here were done using NI MAX Version 2023 Q4 Referring to Figure 7, 0pen NI Max, and from the main window, under My System at left, open the Devices and Interfaces dropdown and select Network Devices. Look for the sensor in the right window under the Add Network Device dropdown.
- Page 14 If a LAN Device name was added previously it will appear in the LAN Device Name box lower in the window. The entire resource can be renamed by completing the Name box at the top, enter LB5940L again, then select Save directly above the window. The sensor is now available for use in the NI MAX system.
- Page 15 General Specifications & Information Default static IP Address 169.254.22.22 Default Connection Setting DHCP (Attempts to connect by DHCP for 45 seconds; assigns the Default static IP address if it fails) PoE Specification IEEE 802.3af or higher LED Indicators details There are 3 indicators, 2 located on the Ethernet connector and 1 on the sensor itself.
- Page 16 Other Connection Examples Keysight Connection Expert Setup Keysight Interactive IO LB5900-LAN QS Guide v2.0 Page 16...
- Page 17 Windows Command Prompt Windows Power Shell Linux & Mac LB5900-LAN QS Guide v2.0 Page 17...
