Original BTC Hector Medium Dome FW343N Instruction Manual

Safety & Installation Instructions
These instructions are provided for your safety in order to prevent the risk of Fire, Electric shock or Injury. It is vitally
important that they are read in their entirety before installing your fitting. Please retain for future reference.
1. If you are in any doubt concerning the installation of this fitting, consult a qualified electrician.
2. Ensure that the electrical supply is switched OFF. Disconnect the electrical supply at the fuse-board.
3. Before starting the installation, identify any concealed wiring or pipes in the mounting area to avoid damage.
4. Position the light where desired, ensuring that there is suitable support adjacent to where you will connect to the house
supply, and mark the positions of the fixing holes. Drill appropriate holes, as below:
5. a. Brick or masonry: Drill holes into which the wall plugs tightly fit, then insert wall plugs.
b. Wood: No hole necessary (unless small pilot hole required), screws can be screwed directly into the timber.
c. Plaster/Cavity: Special cavity wall fittings are required, rather than provided fixings. These are widely available from
good hardware or DIY store and should come with their own instructions that must be followed. It may be easier to
relocate the fitting so that you screw directly into a timber joist or beam.
6. Follow the instructions inside to complete the installation
7. Fit the correct type and wattage of lamp (or less). Be careful not to overtighten the lamp.
8. Switch on at the fuse-board. Your light fitting is now ready for use.
Other Important Information
Switch off at mains before changing lamp(s). Never fit a lamp of greater wattage than recommended. Ensure children do not
play with the light fitting. If the fitting is to be positioned in an area which can be accessed by young children, we recommend
installing the light with a suitable cable clip to prevent the flex from becoming a choking hazard. These are available at good
hardware stores. Dispose of old lamps carefully. Never leave a fitting without a lamp in position (or someone can accidentally
touch the contacts). Adjust fitting only when power to the fitting is off and has been left to cool. If the external flexible cable or
cord of this luminaire is damaged, it shall be exclusively replaced by the manufacturer or his service agent or a similar qualified
person in order to avoid a hazard. For use in a dry, indoor environment only. Ensure the fitting does not come into contact with
any liquids.
Cleaning and Maintenance
Metal finishes should only be cleaned with a soft, dry cloth. Do not use polishes or abrasives. Bone china can be cleaned by
hand, using a soft damp cloth with a diluted mild detergent (nonabrasive) if necessary. Switch off power to the fitting before
cleaning. Spare parts are available for this product, please contact us on the details below.
Established in 1990, Original BTC manufactures relaxed, familiar lighting for traditional and contemporary homes.
All products are hand-assembled in Oxfordshire from high quality components, produced in the UK.
ORIGINALBTC.COM
+44 (0)1993 882 251
UNIT 21 / 22 AVENUE ONE, STATION LANE, WITNEY, OX28 4XZ, ENGLAND
Hector
Medium Wall Light PSC
v2.1-09.24
Instruction Manual
Medium Dome /
Hector 30
FW343N
MADE IN BRITAIN
Medium Pleat Circle Line Bibendum
FW508N FW343CL FW504W
