QU-KD2N-HF
QUIO TCP/IP OLED Display Reader
Operation Manual
Version 01.05
2021/09/24
Quick-Ohm Küpper & Co. GmbH
Cronenfelderstraße 75 | 42349 Wuppertal
Tel: +49 (0) 202 404329 | Fax: +49 (0) 202 404350
E-Mail:
mailto:kontakt@quio-rfid.de
Web:
www.quio-rfid.de
Advertisement
Summary of Contents for Quick-Ohm QUIO QU-KD2N-HF
- Page 1 QU-KD2N-HF QUIO TCP/IP OLED Display Reader Operation Manual Version 01.05 2021/09/24 Quick-Ohm Küpper & Co. GmbH Cronenfelderstraße 75 | 42349 Wuppertal Tel: +49 (0) 202 404329 | Fax: +49 (0) 202 404350 E-Mail: mailto:kontakt@quio-rfid.de Web: www.quio-rfid.de...
- Page 2 QU-KD2N TCP/IP OLED Display Reader Operation Manual I. Features & Specification Feature: Multi-mode access control Support ISO15693 / ISO14443A (Mifare) / ISO14443B / DESFire / NTAG203 2.42 inch OLED Display Multi communication interface Provide protocol to develop. Specification: Frequency 13.56MHz...
- Page 3 QU-KD2N TCP/IP OLED Display Reader Operation Manual II. Wiring Diagram...
- Page 4 QU-KD2N TCP/IP OLED Display Reader Operation Manual III. Network Parameter Setting Execute “NET_Discover_V0110.exe” and press to search QUIO series product. Factory default IP is “192.168.1.101”. User can check the MAC address from product sticker with IP to confirm the device.
- Page 5 QU-KD2N TCP/IP OLED Display Reader Operation Manual Double click IP (192.168.1.101) to open the web configure page(http://192.168.1.101) Default login ID / Password : admin / admin...
- Page 6 QU-KD2N TCP/IP OLED Display Reader Operation Manual Default Net Mode is the same as the following. User can modify Net Mode and other parameters. If device cannot communicate properly after setting, user can reset NET module via Micro USB. Communication Parameter Factory Default Serial Configure 230400,8,n,1...
- Page 7 QU-KD2N TCP/IP OLED Display Reader Operation Manual IV. Network Mode Switch QUIO device support 4 network modes: Default、ETH(Ethernet)、Wi-Fi(STA) Default Ethernet (DHCP) +Wi-Fi AP mode Ethernet only WIFI(STA) Wi-Fi client mode . ETH：Factory default is ETH-SERIAL. ( Standard TCP/IP Reader ) When user modify the IP and click on Apply button, device will reboot and apply the setting after 30 seconds.
- Page 8 QU-KD2N TCP/IP OLED Display Reader Operation Manual WIFI(STA)：QUIO can be set to communicate via Wireless AP without Ethernet. STA SSID: Enter the SSID from AP you will connect to network. Scan : User can scan AP in range of device and select one to connect. But user cannot scan the AP after changing default network mode (Ethernet only) to Wi-Fi (Client).
- Page 9 QU-KD2N TCP/IP OLED Display Reader Operation Manual . Default mode：Ethernet (DHCP) +Wi-Fi AP mode. It’s Dual-Mode ( Ethernet and Wi-Fi AP，but Ethernet only support DHCP.)
- Page 10 QU-KD2N TCP/IP OLED Display Reader Operation Manual AP SSID: Setup device’s SSID. AP Passwd: Device’s Wi-Fi password. (Default is 12345678)
- Page 11 QU-KD2N TCP/IP OLED Display Reader Operation Manual V. USB Connection Setup parameters via Micro USB. Micro USB 1. Install USB driver ”CDC_USB_Driver_VCP_V1.4.0_Setup.exe” 2. System will generate a virtual COM port. For example. Check port in device manager.(below picture is COM 3)
- Page 12 QU-KD2N TCP/IP OLED Display Reader Operation Manual User also can update driver manually. The driver is saved in the folder that is same as following. 3. Get device Model information and serial number by using V8 Tools with correct COM port or Ethernet connection.
- Page 13 QU-KD2N TCP/IP OLED Display Reader Operation Manual VI. V8 Tools Tool Parameter Setting Basic: Basic: Get device serial number、device ID and firmware version Warm Start: Reboot device Initial: Restore device to factory default (It is NOT including network setting). NET Initial (6 sec): Restore network parameter of device to Default mode.
- Page 14 QU-KD2N TCP/IP OLED Display Reader Operation Manual Reader Set Interface: Setup reader’s communication interface. Default is “RS485”. Set Message Mode: Card LED: Time for read card LED ON, default is 30 x 10ms Card Beep: Time for read card beep on, default is 30 x 10ms ISO14443A/B/ISO15693 : Same Card Delay: Setup time gap for reading the same card, default is 10 x100ms (1 second) Green Mode: Slow down the card read speed to power saving.
- Page 15 QU-KD2N TCP/IP OLED Display Reader Operation Manual Display : Set up display language and encode for different country. Test send message command with tools.
- Page 16 QU-KD2N TCP/IP OLED Display Reader Operation Manual Auto send reader mode Un- Select "Controller Mode" and then click "Set DI/DO Mode" to disable controller mode. Select "EN" (means enable), "S/N", "CLR", "CRC" and set heartbeat to 50 (means 5 sec) and then click "Auto Mode"...
