Summary of Contents for AMS OSRAM AS7058 v1 demo
- Page 1 AS7058 watch Quick Start Guide Wireless wristband watch v1 and v4 demo Published by ams-OSRAM AG Tobelbader Strasse 30, 8141 Premstaetten, Austria Phone +43 3136 500-0 ams-osram.com © All rights reserved...
- Page 2 AS7058 watch Table of contents Table of contents Out of the box ............3 Button description ..............5 Optical stack arrangement ............8 Software installation ..........10 Connect hardware ..........10 Optical stack positioning ........11 Start the application ..........13 PPG measurement for HRM &...
- Page 3 AS7058 watch Out of the box Out of the box Referring documents: For a detailed description of hardware and software, please refer to AS7058 User Guide and Quick Start Guide: • UG001052 • QG001037 The AS7058 v1 & v4 wireless wristband demos come as shown in the figures below: Figure 1: AS7058 wireless wristband v1 demo Demo Kit Quick Start Guide •...
- Page 4 AS7058 watch Out of the box Figure 2: AS7058 wireless wristband v4 demo • The AS7058 wireless wristband v1 demo supports PPG (HRM, RRM & SpO2). • The AS7058 wireless wristband v4 demo supports PPG (HRM, RRM & SpO2), ECG, EDA &...
- Page 5 AS7058 watch Out of the box Button description 1.1.1 AS7058 wireless wristband v1 demo Figure 3: Status LED of AS7058 wireless wristband v1 demo Demo Kit Quick Start Guide • PUBLIC • Document Feedback QG001041 • v1-00 • 2024-Oct-30 / 20...
- Page 6 AS7058 watch Out of the box Figure 4: Button description of AS7058 wireless wristband v1 demo 1.1.2 AS7058 wireless wristband v4 demo Figure 5: Status LED of AS7058 wireless wristband v4 demo Demo Kit Quick Start Guide • PUBLIC • Document Feedback QG001041 •...
- Page 7 AS7058 watch Out of the box Figure 6: Part description of AS7058 wireless wristband v4 demo Information: Identification of electrodes for bioimpedance (BioZ) connections: E1 = BIOZ1; E2 = BIOZ3; E3 = BIOZ4, E4 = BIOZ2 Demo Kit Quick Start Guide • PUBLIC • Document Feedback QG001041 •...
- Page 8 AS7058 watch Out of the box Optical stack arrangement 1.2.1 AS7058 wireless wristband v1 demo optical stack arrangement Figure 7: AS7058 wireless wristband v1 demo optical stack components Component Function Pin assignment Photodiode SFH2706 Photodiode SFH2706 Photodiode SFH2705 Photodiode SFH2705 Red ->...
- Page 9 AS7058 watch Out of the box 1.2.2 AS7058 wireless wristband v4 demo optical stack arrangement Figure 8: AS7058 wireless wristband v4 demo optical stack components Component Function Pin assignment Photodiode SFH2705 Photodiode SFH2705 Photodiode SFH2705 Green: LED1 LED module SFH7018A Red: LED2 IR: LED3 Green: LED7...
- Page 10 AS7058 watch Software installation Software installation Please refer to the AS7058 Evaluation Kit Quick Start Guide (QG001037) for instructions on installing the AS7058 EVK GUI. Connect hardware Press the power button for 1 second to power on the wristband. Afterward, connect the v1 or v4 AS7058 wristband Demo via the correct COM port or BLE number to the evaluation software.
- Page 11 AS7058 watch Optical stack positioning Optical stack positioning During PPG, ECG, EDA, and BioZ measurements, specific buttons on the optical stack and electrodes of the AS7058 wireless wristband v1 & v4 demo should be pressed. Please refer to Figure 10 to Figure 12 for the correct positions, depending on the measurements taken. Figure 10: PPG measurement Figure 11: ECG/EDA measurement Demo Kit Quick Start Guide •...
- Page 12 AS7058 watch Optical stack positioning Figure 12: BioZ measurement Measurement conditions ✓ Ensure that your hands are warm and have good blood circulation. ✓ If your skin is too dry or greasy, wash and dry your fingers before a satisfying ECG signal can be achieved.
- Page 13 AS7058 watch Start the application Start the application For an overview of the AS7058 GUI please refer to the AS7058 user manual. PPG measurement for HRM & RRM of the v1 demo Press the power switch for 1 second to power on the sensor. Afterward, connect the AS7058 wireless wristband v1 demo via the correct COM port or BLE number.
- Page 14 AS7058 watch Start the application Figure 13: HRM & RRM measurement for the AS7058 wireless wristband v1 demo Demo Kit Quick Start Guide • PUBLIC • Document Feedback QG001041 • v1-00 • 2024-Oct-30 / 20...
- Page 15 AS7058 watch Start the application PPG measurement for HRM & RRM of the v4 demo Press the power switch for 1 second to power on the sensor. Afterward, connect the AS7058 wireless wristband v4 demo via the correct COM port or BLE number. The USB or BLE turns green after successfully connecting.
- Page 16 AS7058 watch Start the application PPG measurement for SpO2 of the v1 demo Press the power switch for 1 second to power on the sensor. Afterward, connect the AS7058 wireless wristband v1 demo via the correct COM port or BLE number. The USB or BLE icon turns green after successfully connecting.
- Page 17 AS7058 watch Start the application PPG measurement for SpO2 of the v4 demo Press the power switch for 1 second to power on the sensor. Afterward, connect the AS7058 wireless wristband v4 demo via the correct COM port or BLE number. The USB or BLE icon turns green after successfully connecting.
- Page 18 AS7058 watch Start the application PPG (HRM & RRM) & ECG raw data measurement Press the power switch for 1 second to power on the sensor. Afterward, connect the AS7058 wireless wristband v4 demo via the correct COM port or BLE number. The USB or BLE icon turns green after successfully connecting.
- Page 19 Draft / Preliminary: The draft / preliminary status of a document indicates that the content is still under internal review and subject to change without notice. ams-OSRAM AG does not give any warranties as to the accuracy or completeness of information included in a draft / preliminary version of a document and shall have no liability for the consequences of use of such information.
- Page 20 No obligation or liability to recipient or any third party shall arise or flow out of ams- OSRAM AG rendering of technical or other services.
