TRASSIR TR-D8151CL3 Quick Start Manual

Specification
Model
TR-D8151CL3
Image sensor
1/2.8" CMOS 5МP
Resolution
5MP(2592x1920) 4MP(2560x1440)
3MP(2304x1280) 2MP(1920x1080)
Frame rate
50Hz: 5MP@25fps
60Hz: 5MP@30fps
Electronic shutter speed
1/2 ~ 1/1 000 s
Day/Night mode
Sensitivity
0.0015Lux (F1.0) / 0Lux (LED on)
LED range
up to 30 m
(neutral white)
Stroboscope
Lens (mm)
Field of view (horiz./vert.)
2.8 mm: 94.5˚ / 68˚
4.0 mm: 77.1˚ / 55.6˚
Axes setting
Pan: 0˚-355˚
Tilt: 0˚-105˚
Rotation: 0˚-360˚
WDR
Real WDR (120dB)
Digital noise reduction
Video compression
Н.265+ / Н.265 / H.264
Bitrate
up to 8Mbps
Local storage
MicroSD up to 256GB
Audio
Built-in microphone
1 in / 1 out
Corridor mode
IVS
Power supply
PoE (802.3af) / 12V DC
PoE Class
Power consumption
DC: 4.6W
PoE: 5.75W
Case material
Dimensions (mm)
Ø93 x 92.2
Weight Net/Gross (g)
400 / 490
Protection
IP66, IK10
Power surge
TVS 4000V
suppressor
Working temperature
-40°C ... +60°C
Technical support
www: helpdesk.trassir.com
mail: helpdesk@trassir.com
FTC
Yes
2.8 / 4.0
3D DNR
Yes
Yes
0
Metal
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
TR-D8151CL3
Outdoor Full Time Color Camera
Full Time
Color
IK10
Note: read user manual before using
Website: www.trassir.com
For any inquiry: info@trassir.com
