Sealey TC006 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Wear eye
instruction
protection
manual
1. SAFETY
Familiarise yourself with the application and limitations of the bead seater.
9
Ensure the beed seater is in good order and condition before use. If in any doubt DO NOT use the unit and contact your service
9
agent.
WARNING! Bead seater must only be serviced by an authorised agent. DO NOT tamper with, or attempt to adjust, pressure switch or
‰
safety valve.
Maintain the bead seater in good condition and replace any damaged or worn parts. Use genuine parts only. Unauthorised parts may
9
be dangerous and will invalidate your warranty.
Use the bead seater in a well ventilated area.
9
Keep tools and other items away from the bead seater when it is in use, and keep area clean and clear of unnecessary items.
9
Keep children and unauthorised persons away from the working area.
9
DO NOT disassemble bead seater for any reason. The unit must be checked by qualified personnel only.
8
DO NOT operate within the vicinity of flammable liquids, gases or solids.
8
DO NOT use this product to perform a task for which it has not been designed
8
DO NOT deface the certification plate attached to the bead seater tank.
8
DO NOT cover the bead seater or restrict air flow around the unit whilst operating.
8
▲ DANGER! DO NOT direct the output jet of air towards people or animals.
DO NOT allow anyone to operate the bead seater unless they have received full instructions.
8
WARNING! The air tank is a pressure vessel and the following safety measures apply:
‰
DO NOT tamper with the safety valve, DO NOT modify or alter the tank in any way and DO NOT strap anything to the tank.
8
DO NOT subject the tank to impact, vibration or to heat and DO NOT allow contact with abrasives or corrosives.
8
Drain condensation from tank daily and inspect inside walls for corrosion every three months and have a detailed tank inspection carried
9
out annually. The tank shell must not fall below the certified thickness at any point.
WARNING! For this reason DO NOT tamper with, or adjust, the pre-set switch or safety valve.
‰
1.1. INSPECTION OF PRESSURE TANK BOTH INTERNAL AND EXTERNAL.
Under the PRESSURE SYSTEMS SAFETY REGULATIONS 2000 it is the responsibility of the owner of the bead seater to initiate a
system of inspection that both defines the frequency of the inspection and appoints a person who has specific responsibility for carrying
out the inspection.
DO NOT carry out any welding operations on any pressurised parts of the vessel.
8
When not in use, store the bead seater carefully in a safe, dry, childproof location.
9
Wear appropriate Personal Protective Equipment. A full range of Personal Protective Equipment is available from your Sealey stockist.
9
2. INTRODUCTION
The easy and instant way to seat tubeless tyre beads. Dumps air into the tyre void, forcing the bead to seat against the rim for
inflation. Air release is controlled by a trigger lever. Fully certified 6l steel tank with gauge and safety valve prevents over-pressurising.
Suitable for use on cars, commercials, agricultural and ATV tyres. Maximum air pressure 145psi (10bar) Working pressure 87-116psi
(6-8bar).
3. SPECIFICATION
Model No:
Maximum Pressure:
Nett Weight:
Operating Temperature:
Tank Capacity:
Tank thickness:
Conforms to EN 286-1 standard
© Jack Sealey Limited
STEEL TYRE BEAD SEATER 6L
MODEL NO:
Wear
Wear ear
protective
protection
gloves
TC006
145psi(10bar)
6.5kg
-20 to 70°
6L
2.5mm
Original Language Version
TC006
Wear
a mask
TC006 Issue:1 10/07/24
