Sony STR-A17/D159 Service Manual

STR-A1//D199
SERVICE MANUAL
Canadian Model
AEP Model
UK Model
E Model
Australian Model
PX Model
STR-A17
STR-A17 and STR-DI159 are
the tuner and amplefier section J
in LBT-A17CDM and LBT-159CD/
D220CD respectively. :
Photo : STR- D159
SPECIFICATIONS
AUDIO POWER SPECIFICATIONS Amplifier
fnpat | deckypo | Senay | ipcance
For US Model :
POWER OUTPUT AND TOTAL HARMONIC
Sr
with 6 ohm loads both channel driven, from
40 - 20,000 Hz; rated 25 watts per channel
minimum RMS power, with no more than
0.5% total harmonic distortion from 250
milliwatts to rated output.
Output __| Jack type
SURROUND Accepts speakers of
SPEAKER 16 ohms
HEADPHONES | Stereo phone Accepts headphones of
8 ohms or more
Stereo FM-AM receiver
External antenna terminal
Intermediate frequency 4501kHz
STEREO FH-AM RECEIVER
SONY.
