Sealey IWMH2003.V3 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear a face
instruction shield
manual
1. SAFETY
ELECTRICAL SAFETY
WARNING! It is the user's responsibility to check the following:
‰
Check all electrical equipment and appliances to ensure that they are safe before using.
Inspect power supply leads, plugs and all electrical connections for wear and damage.
Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
DO NOT use worn or damaged cables, plugs or connectors.
8
Ensure that any faulty item is repaired or is replaced immediately by a qualified electrician.
9
If the cable or plug is damaged during use, switch off the electricity supply and remove from use.
9
Ensure that repairs are carried out by a qualified electrician.
Sealey recommend that an RCD (Residual Current Device) is used with all electrical products.
9
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the
correct fuse.
DO NOT pull or carry the appliance by the power cable.
8
DO NOT pull the plug from the socket by the cable.
8
GENERAL SAFETY
Children from age 8 years and above, persons with reduced physical, sensory, or mental capabilities those with lack of experience
9
and knowledge can use the appliance, if they have been given supervision or instruction concerning use of the appliance in a safe way
to understand the hazards involved.
Children shall NOT play with the appliance.
9
Cleaning and user maintenance on the appliance shall not be made by children without supervision.
9
Children of less than 3 years should be kept away unless continuously supervised.
9
Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in
9
its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children aged from 3 years and less than 8 years shall not plug in, regulate, and clean the appliance or perform user maintenance.
9
The appliance shall be disconnected from its power source during service and when replacing parts
9
If the removal of the plug is foreseen, the removal of the plug has to be such that an operator can check from any of the points to
9
which he has access that the plug remains removed.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid
9
a hazard.
The heater must not be located immediately below a socket outlet.
9
WARNING!: Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and
‰
vulnerable people are present.
WARNING!: In order to avoid overheating, DO NOT cover the heater.
‰
WARNING!: Outdoor use only.
‰
WARNING!: The heater must be installed at least 1.8m above the floor
‰
2. INTRODUCTION
A totally dry heat, no condensation, no gas, no fumes and no smell. Reaches maximum heat output within seconds of being turned on. Highly
polished aluminium reflector for maximum heat efficiency. Adjusts horizontally through 45° while mounted. Three settings, controlled by pull cord,
allow unit to be on full, half or low power. Ideal for industrial or domestic applications. Suitable for outdoor use only (IP34 Rated).
3. SPECIFICATION
Model No.: ...................................................... IWMH2000.V3
Nett Weight: .................................................................. 1.8kg
Overall Dimensions (W x D x H):.............500 x 190 x 320mm
Plug Type: ......................................................................3 Pin
Power Supply Cable:......................................................... 2m
Power: ...........2000W (Three settings 650W, 1300W, 2000W)
Supply: ................................................................. 230V - 13A
© Jack Sealey Limited
WALL MOUNTING INFRARED QUARTZ HEATER
2000W
MODEL NO:
Wear protective Wear protective
clothing footwear
Original Language Version
IWMH2003.V3
Warning: Wear protective
Hot surfaces gloves
Do not cover Warning!
Electricity
IWMH2003.V3 Issue:1 21/10/24
Outdoor use
only
