- Page 1 Quick Installation Guide Ceiling Mount AP WIS-EAP500 WIS-EAP510 WIS-EAP510E WIS-EAP520 WIS-EAP550 WIS-EAP560 WIS-EAP530 WIS-EAP530E www.wisnetworks.in...
- Page 2 1.Product introdction LED indicator definition Front Back One LED Indicator Designation Normal Status Explanation Green Light System boots up successfully SYSTEM/WIFI LED Blue light WIFI boots up successfully Designation Three LED Indicator Normal Status Explanation Bright System boots up successfully SYSTEM LED System reset default Flashing...
- Page 3 2.Device Installation...
- Page 4 3.Device connection Bypass mode topology Cloud Server INTERNET Router POE Switch Laptop Mobile phone Monitor AC Gateway mode topology Cloud Server INTERNET AC(AC gateway all in one) POE Switch Laptop Mobile phone Monitor Tips:AP is a standard 48V POE device, please use a standard IEEE802.3at POE switch or POE adapter12v---1mp. When deploy a large wireless network, there are many APs in this network, it is recommended to use a wireless AC controller in the network to centrallized-manage all APs in the network.
- Page 5 AP mode 1.Use Internet Explorer to visit http://192.168.2.2, pop up the login dialogue box shown in the following picture, input the default login password: admin, then press “Login” to enter the wireless AP’s management user interface page. Input password Login 2.By default it is in Fit AP mode, users need click the button at the right corner to change it to FAT AP mode if needed.
- Page 6 4.Setup Wizard page,choose AP mode as the current working mode. Current Mode Home Wizard Gateway Repeater Mode WISP Mode AP Mode WIFI In this mode the AP wireless interface and cable interfac are bridging together.Without NAT,firewall and all network Network related functions.
- Page 7 3. In FAT AP mode user interace home page is as shown below: Operation Mode AP Mode Fat AP Flow(2G Wifi)bps Home Wizard WIFI Uptime 01:05:39 Network Device Information Device Description LAN Information WIFI Information IP Mode Get IP From AC Status Lan IP 192.168.2.2...
- Page 8 5.Enter AP Mode setup page,choose “Get IP from AC” in connection type, click Next. AP Mode √ LAN Settings IP Mode Get IP From AC Static IP Get IP From AC Get IP From Gateway Next 6. Enter Wifi setup page,set up SSID, Channel, Encryption parameters as shown below: AP Mode √...
- Page 9 Internet connection and status view IP settings: After the configuration is completed, the wireless AP will restart and enter the Operation Mode you set. Then change the IP address of your computer to Obtain an IP address automatically, computer and other wireless devices can connect to the AP for Internet access.
- Page 10 Configure Reboot Modify Password Upgrade Time Home Configure Wizard Save the configuration file to your computer Backup WIFI Restore Select Network Restore the factory default settings ,please press this button Reset Default Manage Wireless testing 1.Use Laptop or mobile phone to test whether the wireless network can surf the Internet: click wireless network , select the wireless SSID, enter the password to connect the wireless AP, test whether you can surf the Internet.
- Page 11 Other mode Current Mode Gateway Repeater Mode WISP Mode AP Mode Gateway Mode Realize router function, WAN port connect with modem (ADSL or Fiber) , or WAN port connect internet by dynamic or static IP type. Repeater mode Realize wireless bridge and forwarding without compatibility matching with the upper device.
- Page 12 Use mobile phone to login Mobile phone login web page of AP (default password is admin)
- Page 13 When mobile phone connect to AP through wireless, need to configure static IP according to below steps How to set static IP for Android system mobile phone Open the phone click "settings", choose "WLAN" , find and long press the SSID of the AP, pop-up menu select "Static IP", set a static IP 192.168.2.X (X can not be 253 or 252) (the static IP should be same IP segment as AP) for mobile phone, then input the right Gateway IP, network mask and DNS.
- Page 14 X.X.X How to set static IP for IOS system mobile phone Click "settings", choose "Wi-Fi", click exclamation mark after connect wireless signal successfully, setup the static IP 192.168.2.2(X can not be 253 or 252), then input gateway IP, subnet mask and DNS, please note: the static IP should be in the same IP segment as AP.
- Page 15 FAQ and Solutions Q1: Forget login name and password ? A1: Reset to factory default settings: press the reset button for above 10 seconds and release it , the device will reboot and reset to factory default settings automatically. Q2: Can not Login wireless AP management WEB interface ? A2: 1.Check if PC with static IP and if this IP is in the same IP segment of AP, make sure it is not set to other IP range.
