N150 Hardware Guide

The following guide is intended as an overview of your Aurender's hardware

interface. Detailed installation information is found in the included

Quick Start Guide

and a comprehensive Conductor App Overview and How-To guides are found in the

Aurender Knowledge Base

Box Contents

• Aurender N150

• AC Power Cord

• Quick Start Guide

Not included: An iOS (iPad or iPhone) or Android device is required to interface with

and control your Aurender. The Aurender must be connected to a Local Area

Network (LAN) via Ethernet (CAT5 or higher) in order to facilitate communication

between your remote device and the Aurender. Please review the "Connect to Local

Area Network (LAN)" section of the included

Quick Start Guide

for more information

on network connectivity.

Digital Transport

This model is a high performance digital audio transport. It features digital outputs

only - there are no analog outputs on board this model. Pair this model up with a

high performance Digital-to-Analog Converter (DAC) for a complete digital front end

solution.

DAC Compatibility

AES/EBU and SPDIF outputs & inputs are universally compatible. However, with USB,

compatibility between any two devices is not always guaranteed! Sometimes, special

drivers or software provisions must be made to establish compatibility over USB.

DACs that fully adhere to the USB Audio Class 2 (UAC2) protocol will be supported

without issue.

Need help?

Do you have a question about the N150 and is the answer not in the manual?

Page 1 Not included: An iOS (iPad or iPhone) or Android device is required to interface with and control your Aurender. The Aurender must be connected to a Local Area Network (LAN) via Ethernet (CAT5 or higher) in order to facilitate communication between your remote device and the Aurender.
Page 2 With the AC switch on the rear in the ON position, simply press and release the front panel On/Off button to turn the Aurender on or off. The surrounding LED light will pulse while the unit is starting up or shutting down, and it will stop pulsing when fully turned on or off.
Page 3 Rear Panel 1. User-installable SSD/HDD Slots The N150 is supplied 1 bays for user-installable storage. The unit does not include built-in storage. If it is your intent to import and store digital audio files on the N150, you will need to install the appropriate hard drive(s)/SSD(s) first. Please refer to the “...
Page 4 "off" position. More information on proper shut down procedure is found here: What is the proper way to shut down my Aurender? Because N150 has UPS circuitry inside, it will take some time for the unit to be drained of power after the power switch turned off.
Page 5 • Unplug power cord during severe lightning storms (after shutting down properly). • Please note that hard drives can break down. Do not consider your Aurender the "Master" copy of your precious music library! Rather, maintain a separate master copy and consider your Aurender as a secondary backup copy.
