- Page 1 BUILT-IN GAS COOKING HOBS INSTALLATION ADVICES - INSTRUCTIONS FOR THE USE • CHG6BF3WPX LPG • CHG938WPX LPG CANDY HOOVER GROUP S.R.L. • Via Comolli 16 • 20861 Brugherio (MB) Italy...
- Page 3 Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.
- Page 4 IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e.
- Page 5 • Do not attempt to modify the technical characteristics of the appliance as this may become dangerous to use. The manufacturer declines all responsibility for any inconvenience resulting from the inobservance of this condition. • CAUTION: this appIiance must only be installed in a permanently ventilated room in compliance with the applicable regulations.
- Page 6 • The manufacturer declines all liability for injury to persons or damage to property caused by incorrect or improper use of the appliance. • WARNING: During use the appliance and its accessible parts become hot; they remain hot for some time after use. Care should be taken to avoid touching heating elements on –...
- Page 7 • WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. • WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance.
- Page 8 ADVICE ADVICE for the for the INSTALLER INSTALLER...
- Page 9 IMPORTANT: • The appliance is designed and approved for domestic use only and should not be installed in a commercial, semi commercial or communal environment. Your product will not be guaranteed if installed in any of the above environments and could affect any third party or public liability insurances you may have. •...
- Page 10 INSTALLATION TECHNICAL INFORMATION FOR THE INSTALLER In order to install the cooker top into the kitchen fixture, a hole with the dimensions shown in fig. 1.1a has to be made, bearing in mind the following: ■ 60cm wide models: • A 40mm ventilation gap must be provided between the bottom of the appliance and any cabinetry, draw unit, thermal protection barrier or appliance.
- Page 11 Fig. 1.1a The thermal protection barrier must • removable with the use of a tool for installation and service; • heat-resistant; • made from thermal Cooktop conductivity material. installed Thermal Clearance protection barrier Door Space for Fig. 1.1b Fig. 1.1c connections Measures (mm) Description...
- Page 12 FASTENING THE COOKTOP Each cooktop is provided with an installation kit including brackets and screws for fastening the cooktop to benches from 30 to 40mm thick. 60cm wide models (fig. 1.2a): The kit includes two “F” type brackets (for the front of the cooktop), two “R”...
- Page 13 VENTILATION REQUIREMENTS The appliance must be installed in compliance with applicable local regulations concerning ventilation and the evacuation of exhaust gases. Intensive and prolonged use may require extra ventilation, e.g. opening a window, or more efficient ventilation increasing the mechanical suction power if this is fitted. CHOOSING SUITABLE SURROUNDINGS The room where the gas appliance is to be installed must have a natural flow of air so that the gas can burn (in compliance with applicable local regulations).
- Page 14 GAS SECTION GAS INSTALLATION REQUIREMENTS Important ! This appliance must be installed and serviced only by a suitably qualified, • registered installer. The installer shall refer to the local standards in force. • Failure to install the appliance correctly could invalidate any manufacturer’s warranty.
- Page 15 CONNECTING THE COOKTOP TO THE GAS SUPPLY The gas connection fitting (fig. 2.1) is made up of: • the floating nut; • the elbow; • the gaskets; The gas connection must be carried out by an authorised person according to the relevant local standards.
- Page 16 ADDITIONAL GAS CONNECTION REQUIREMENTS When connecting the cooktop to the gas supply with rigid pipes or a flexible hose, make sure that: • You use rigid pipes or a flexible hose compliant with applicable local regulations. The flexible hose shall be of the correct construction for the type of gas being used and of the correct size to maintain the heat output of the appliance.
- Page 17 Some models - for the gas category check the data label attached on the appliance TABLE FOR THE CHOICE OF THE INJECTORS Cat: II 2H 3+ G30/G31 (Countries IT-ES-PT-IE-GB-GR-CH) 28-30/37 mbar 20 mbar Cat: II 2E+3+ G30/G31 G20/G25 (Countries FR-BE) 28-30/37 mbar 20/25 mbar Nominal...
- Page 18 REPLACEMENT OF THE INJECTORS Auxiliary, If the injectors are not supplied they can semi-rapid be obtained from the “Service Centre”. and rapid burner Select the injectors to be replaced according to the “TABLE FOR THE CHOICE OF THE INJECTORS”. nozzle diameters, expressed hundredths of a millimeter, are marked on...
- Page 19 SETTING THE MINIMUM OF THE COOKTOP BURNERS In the minimum position the flame must have a length of about 4 mm and must remain lit even with a quick turn from the maximum position to that of minimum. The flame adjustment is done in the following way: •...
- Page 20 ELECTRICAL SECTION – connect the blue wire to the IMPORTANT: The appliance must be terminal marked with the letter “N” installed by a qualified technician or coloured black; according with the current local – connect the brown wire to the regulations and in compliance with terminal marked with the letter “L”...
- Page 21 SECTION OF THE SUPPLY CABLE TYPE “H05V2V2-F” resistant to temperatures of 90°C 220-240 V 50-60 Hz 3 x 0,75 mm (*) (**) 220V ac 18/3 (*) (**) Connection possible with plug and outlet (**) Connection with wall box connection. REPLACING THER POWER SUPPLY CABLE WARNING: If the power supply cable is damaged, it must be replaced only by an authorized service agent in order to avoid a hazard.
- Page 23 ADVICE ADVICE for the for the USERS USERS...
- Page 24 FEATURES AND TECHNICAL DATA Fig. 1.1 Fig. 1.2 11 9 8 7 10 9 8 7 Fig. 1.4 Fig. 1.3 12 7 8 9 10 10 9 12 8 7 Fig. 1.5 15 14 8 9 10 11 Caution! NOTE: Do not cover the hob with aluminium The knob and symbols may vary.
- Page 25 GAS BURNERS Auxiliary (A) 1,00 kW Semirapid (SR) 1,75 kW Semirapid (SR) 1,75 kW Rapid (R) 3,00 kW Double-ring compact (DRC) 3,50 kW Double-ring (DR) 3,80 kW Dual (DB) (*) 4,20 kW IMPORTANT: The Dual burner is controlled by two separate knobs; one knob for the inner crown only and one knob for the outer crown only.
- Page 26 HOW TO USE THE COOKTOP BRUCIATORI A GAS Gas flow to the burners is adjusted by turning the knobs (illustrated in fig. 2.1a or 2.1b) which control the safety valves. Turning the knob, so that the indicator line points to the symbols printed on the panel, achieves the following functions: –...
- Page 27 LIGHTING THE BURNERS DUAL BURNER - SOME MODELS ONLY ignite burner, following instructions are to be followed: The Dual Burner is a very flexible burner which allows different regulations and Press in the corresponding knob and optimal cooking. turn counter-clockwise (fig. 2.2a or It is composed by one inner and one outer 2.2b) to the full flame position marked crown: the inner and outer crown can be...
- Page 28 CHOICE OF THE BURNER On the control panel, near every knob there is a diagram that indicates which burner is controlled by that knob. The suitable burner must be chosen according to the diameter and the capacity used. The burners and pans must be used in accordance with the following instructions: DIAMETERS OF PANS WHICH MAY BE USED ON THE BURNERS BURNERS MINIMUM...
- Page 29 WOK STAND (OPTIONAL) (figs. 2.4a - 2.4b) This special grille for woks should be placed over the pan-rest for the double-ring compact, double ring or Dual burner (depending on models). Warning: • Using woks without this special grille may cause the burner to malfunction. •...
- Page 30 CLEANING AND MAINTENANCE GENERAL ADVICE Before you begin cleaning, you • COOKING HOBS WITH must ensure that the appliance is GLASS LID (optional) switched off and disconnected from the electrical power supply. • Important: The use of suitable protective clothing/gloves recommended when handling or cleaning of this appliance.
- Page 31 STAINLESS STEEL SURFACES Stainless steel parts must be rinsed with water and dried with a soft and clean cloth. For persistent dirt, use specific non-abrasive products available commercially or a little hot vinegar. PAINTED PARTS AND SILKSCREEN PRINTED SURFACES Clean using an appropriate product. Always dry thoroughly. IMPORTANT: these parts must be cleaned very carefully to avoid scratching and abrasion.
- Page 32 Fig. 3.1 Fig. 3.2 MODELS WITH DOUBLE-RING MODELS WITH COMPACT BURNER DOUBLE-RING BURNER Fig. 3.3 Fig. 3.4...
- Page 33 MODELS WITH DUAL BURNER Fig. 3.5 Fig. 3.6 Fig. 3.7...
- Page 34 PAN SUPPORTS These parts can be removed and cleaned with appropriate products. After cleaning, they must be well dried and correctly replaced. Warning! Not dishwasher safe. It is very important to check that the pan supports have been correctly positioned. Failure to do so can cause serious problems.
- Page 36 The manufacturer will not be responsible for any inaccuracy resulting from printing or transcript errors contained in this brochure. We reserve the right to carry out modifications to products as required, including the interests of consumption, without prejudice to the characteristics relating to safety or function.
