Vixen Horns VXO8350BDP/8124XB Installation Manual

BEFORE BEGINNING YOUR INSTALLATION
Read through the instruction guide before getting started with the installation. Professional installation is recommended for
this product.
CONTENTS
 Octo Trumpet Train Air Horn (Chrome Color)
 200 PSI Air Compressor (Chrome Color) x 2
 5 Gallon Air Tank
 12V Electric Air Valve (Solenoid)
 240 PSI Air Pressure Gauge
 170-200 PSI Pressure Switch
 250 PSI Safety Valve
 1/4" NPT Wing Style Drain Valve
 1/4" NPT Compression Fitting for 1/4" OD Air Line
 1/4" NPT Compression Fitting for 3/8" OD Air Line
 1/4" NPT Hex Head Male Plug
 1/2" NPT Hex Head Male Plug x 2
 3/8" OD Nylon Plastic Hose (25 Feet)
 12mm Thread Sealant Tape (16 Feet)
 5-PIN 12V/40A Relay with Pre-wired Plug x 2
 30A In-line Fuse with Waterproof Holder x 2
 60A In-line Fuse with Waterproof Holder
 Remote Mount Air Filter x 2
 Horn Button
 Mounting Hardware
The specific voltage requirement for this horn system is 12 volt DC, therefore installation must be done to a DC
power source of 12 volts.
PAGE 1 of 6
VXO8350BDP/8124XB
INSTALLATION GUIDE
U.S. Design Patent No. D937,344 S
