VELTRON HEATERS
▶Thank you for purchasing the VELTRON Heater.
Please read this user manual carefully before you operate this heater.
▶It is recommended that you put this manual where the user can easily find
it. It is obligatory that the user read "Notice for Safety" carefully before
using, and they should be aware of this notice whenever using this heater.
▶This heater is designed for your country only. If you use it in another
country, you have to check the electricity first, and if the electricity
condition is the same, you can use it.
▶A warranty card is enveloped in this manual.
▶The contents (features and specifications) in this manual are subject to
change without notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VHOE-120/N and is the answer not in the manual?

Questions and answers

Related Manuals for Veltron VHOE-120/N

Summary of Contents for Veltron VHOE-120/N

  • Page 1 VELTRON HEATERS ▶Thank you for purchasing the VELTRON Heater. Please read this user manual carefully before you operate this heater. ▶It is recommended that you put this manual where the user can easily find it. It is obligatory that the user read "Notice for Safety" carefully before using, and they should be aware of this notice whenever using this heater.
  • Page 2 • NOTICE FOR SAFETY • STRUCTURE & DESCRIPTION - STRUCTURE & DESCRIPTION - REMOTE CONTROLLER - CONTROL PANEL • HOW TO USE 9~15 - OPERATION & STOP OPERATING MODE SETTINGS 10~11 - WIFI MANUAL 12~15 - ITEMS TO CHECK BEFORE INFORMING •...
  • Page 3 This is for protecting the user's safety and preventing any property damage. Please read carefully and follow the instructions in this manual.It is classified as "Warning" and "Caution" by the contents. In cases of misuse, it may cause serious wounds or death. In cases of misuse, it may cause a slight injury or property damage.
  • Page 4 It is dangerous to use this heater for a long You must ventilate well while you are using the time in a closed room, especially if there heater, and do not use it in a stuffy area where are children, the elderly, or the weak. ventilation is not possible.
  • Page 5 Do not put this heater on an unstable surface of When storing this heater, be sure that you store the ground, such as an inclined or bumpy it in a dry place indoors instead of in a hot and surface. humid environment.
  • Page 6 *Ensure the safety of the planned location for the diesel heater. *The base surface should be flat, strong, and non-flammable. *Sufficient clear space is required around the heater - the left and right sides of the At least heater should be at least 15 cm away from the wall, the distance from the ceiling 30 cm from sealing should be at least 1 m, and there should be a minimum of 1 m of free space in front of...
  • Page 7 ※ This design may be changed for improved efficiency. When the heater turns ON or OFF, you can press this button. Every time you press this button, the heater repeats set-up and cancels. To select the time control mode To select the temperature control mode. To set or change the temperature or time Connect the power cord of the heater to the outlet.
  • Page 8 FUNCTION 1. ON / OFF Can be switched between power stand-by state and operational state using the ON/OFF button on the front panel. 2. TEM P / TI ME You can change the operation method by pressing the button and switch between time mode and temp mode.
  • Page 9 1. Connect the power plug (you can see the current temperature), 2. Operation mode can be changed by pressing the ‘Time/ then press the on/off button. (Check "SET time/time," the number Temp’ button. on the right side.) But if this heater operates in case it is first used from purchase, turn the air screw left around three times and then start by pressing the "ON/OFF"...
  • Page 10 This mode enables the user to set the desired temperature in the room, and once it is set, this heater works automatically, running and stopping repeatedly to hold this temperature. (If power is on and the heater starts operation, the temperature control mode will be operated by default.) 2.

  • Page 11: Time Control

    This mode enables the user to set the desired time for the heater working continiously, and once it is TIME CONTROL fixed, this heater works automatically, running and stopping repeatedly by the time what has been set. (If power is on and the heater starts operation, the temperature control mode will be operated by default.) 2.
  • Page 12 WiFi MANUAL 1. Install “Smart Life” app 2. Add and connect devices 3. HIPERS panel function control 4. Heater firmware online upgrade (OTA) 1. Install the "Smart Life" app to use the home control function of your Hipers heater. 1) Search for the Smart Life app in Google Play on your Android phone or iPhone app store. Once you find the application, click the “Install”...
  • Page 13 WiFi MANUAL 3. Monitor and control your heater using the device panel in the Smart Life app (HIPERS panel function control) - Click ‘HIPERS-Smart Heater’ on the My Home screen of the Smart Life app to launch the of the Smart Life app to launch the heater control panel. A description of each screen component is as follows Current temperature: Displays current temperature around heater.
  • Page 14 WiFi MANUAL Heater set value setting Heater operation settings: If the heater is in temperature setting mode, you can set the target temperature value, and if the heater is in time repeat mode, you can set the heating time. Command buttons and menus for other settings - Power : Press the ON/OFF button to turn the heater on or off - Mode : You can change the operation mode...
  • Page 15 • Once firmware writing is complete, it will restart with the new version (same as when the initial power is turned on). • At this time, various setting values and operating status are applied as previously set values. ※VELTRON Smart Heater upgrades firmware online. Manufacturers may upgrade firmware to modify features or improve performance .
  • Page 16 ITEMS TO CHECK BEFORE INFORMING OF TROUBLE If the following error or trouble signs are displayed on the operation panel Displayed Description Items to check and required actions messages of troubles - The lack of fuel E1. No ignition The burner is misfiring - There is air in the fuel tube (▶air discharge).
  • Page 17 To pull out the front grille, please raise it a little and pull it out. (Assembly is the opposite way.) In case you keep the heater for a long time and you want to maintain its clean status, please power off and cool down the heater, pull out the plug as shown in the above picture, and clean according to the following instructions.
  • Page 18 CLEAN OF FLAME SENSOR (Photocell, CDS) - If the detection part of the photocell is contaminated by soot or other dirt, the performance can be lowered, which may cause a problem. - Please take out the photocell carefully, which is placed in the lower part of the burner. - Please clean the detection part of the photocell with soft clothes.

  • Page 19: Daily Check Points & Adjustment

    DAILY CHECK POINTS & ADJUSTMENT ADJUSTMENT ▶IN CASE OF SUDDEN STOP DURING OPERATION - Please check if now is operating in the time control operation? If so, the heater can be rest for 5min. - Please check if now the setting temp, is less than the current temp. - Please check if the heater is stop by pressing On/Off switch by remote controller or front controller.
  • Page 20 Please check the points below before you think trouble has occurred. Check if the power supply is proper. No power supply? (ex. 220/230Vac, 50Hz) Check that the power Plug the power plug into the outlet. OPERATION plug is disconnected. Replace the fuse with a new one. Is the fuse short? (250Vac, 3.15A) Fill it up with kerosene or diesel.
  • Page 21 "Lack of Fuel" light ON? Running out of fuel Fill up the fuel. Check what kind It may cause less Drain the existing fuel and fill of fuel is inside the performance & trouble with Diesel or kerosene only. tank Water or any other It may cause less IMMEDIATE...

  • Page 22: Specification

    SPECIFICATION Model VHOE-90 VHOE-120/N VHOE-150/N VHOE-210/N VHOE-250F/N VHOE-350F/N VHEO-500F Fuel Diesel Diesel Diesel Diesel Diesel Diesel Diesel Heating Output (kcal/h) 9,000 13,000 15,000 21,000 25,000 35,000 49,800 Fuel Consumption (L/h) Heating Area (㎡) 36~53 55~88 66~133 135~237 166~280 231~330 330~500...

  • Page 23: Warranty

    WARRANTY - To activate your 2+1 year warranty, please scan the QR code below, which will take you to a page where you need to fill in your details. - 23 -...
  • Page 24 Official distributor and importer in European Union: Veltron International OÜ , Reg. No: 14338106 Phone: +372 5693 7082 E-mail: info@hipersheaters.com; Address: Pärnu mnt 139e/11, 11317 Tallinn ESTONIA...
