Serial Number _______________ Purchase Date _______________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 909-287-0730, 8 a.m. - 5 p.m. PST, Monday - Friday.
You may also contact us anytime at service@permasteel.life.
SS22046
EMERALD COVE
ATTACH YOUR RECEIPT HERE
1
ITEM #
80QT ROLLING
PATIO COOLER
MODEL # PS-220-BR
5203846
Advertisement
Summary of Contents for Allen + Roth EMERALD COVE PS-220-BR
- Page 1 ITEM # 5203846 EMERALD COVE ALLEN + ROTH and logo design are trademarks or 80QT ROLLING registered trademarks of LF, LLC. All rights reserved. PATIO COOLER MODEL # PS-220-BR ATTACH YOUR RECEIPT HERE Serial Number _______________ Purchase Date _______________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 909-287-0730, 8 a.m.
- Page 2 TABLE OF CONTENTS Package Contents………………………………………………………………………………………. Hardware Contents.…………………………………………………………………………………….. Safety Information..……………………………………………………………………………………… Preparation..…………………………………………………………………………………………...… Assembly or Installation Instructions………………………………………………………………….. Care and Maintenance.………………………………………………………………………………… Warranty……………………………………………………………………….………………………..PRODUCT SPECIFICATIONS SPECIFICATIONS 35.6in L x 19.6in D x 34.5in H Steel construction 80 QT capacity...
- Page 3 PACKAGE CONTENTS ITEM # DESCRIPTION PART # ITEM # DESCRIPTION PART # Body (Basin) PP220BR-A Bottle Opener PP220BR-G PP220BR-B Cap Catcher PP220BR-H Bottom Shelf PP220BR-C Handle PP220BR-I PP220BR-D Caster PP220BR-J Caster with Brake PP220BR-K Cross Member PP220BR-E Drainage Plug PP220BR-L Knob PP220BR-F...
- Page 4 HARDWARE CONTENTS M6 x 13 mm Bolt M6 x 15 mm M6 x 16 mm Shoulder Bolt Bolt Qty: 22 Qty: 2 M4 x 40 mm Qty: 4 Screw Qty: 2 (Note: Pre-attached to lid knobs) Tools included: Double open-end wrench Allen wrench...
- Page 5 SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. CAUTION • Hand tools only, use of power tools could damage product. • Remove all components, hardware and tools from box before assembly. Inventory and separate each of the hardware and components included.
- Page 6 ASSEMBLY INSTRUCTIONS Attach the legs (D) to the body (A) using eight M6 x 13 mm bolts. Note: Do not fully tighten the bolts. Legs should be loose so that it can be aligned with the holes on the cross members and bottom shelf. Hardware Used M6 x 13 mm Bolt Allen wrench...
- Page 7 ASSEMBLY INSTRUCTIONS Insert and thread casters (J) into two legs (D) on the same side with the provided double open-end wrench. Insert and thread casters with brake (K) into other two legs on the same side. Hardware Used Double open-end wrench Attach the body handle (I) to body (A) using four M6 x16 mm bolts, and tighten with the provided Allen wrench.
- Page 8 ASSEMBLY INSTRUCTIONS Attach the bottle opener (G) to body (A) using two M6 x 13 mm bolts, and tighten with the Allen wrench. Hardware Used M6 x 13 mm Bolt Allen wrench Attach the cap catcher (H) to body (A) using the two M6 x 15 mm shoulder bolts.
- Page 9 CARE AND MAINTENANCE • Cooler must be drained of water and completely dried in and out with a soft-clean cloth after every use. • When cooler is not in use for prolonged periods, it is recommended to store it in an enclosed dry place such as a storage shed or garage.
