Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual (or month and year of purchase if product has no number). Keep this manual and the
receipt in a safe and dry place for future reference.
DUST COLLECTOR
WITH 2-MICRON
CANISTER FILTER
email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1‑800‑444‑3353 as soon as possible.
©
Copyright
2023 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
Visit our website at: https://www.harborfreight.com
®
. All rights reserved.
tM
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
24l
24217E-B
70757
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Bauer 24217E-B
- Page 1 Write the product’s serial number in the back of the manual (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. 24217E-B DUST COLLECTOR WITH 2-MICRON CANISTER FILTER Visit our website at: https://www.harborfreight.com...
- Page 2 table of contents Safety ............2 Maintenance ..........9 Specifications ..........4 Parts List and Diagram ......10 Setup ............5 Warranty ............ 12 Operation ............ 8 WarninG SyMBOLS anD DeFinitiOnS This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
- Page 3 16. Do not use without dust bag 20. People with pacemakers should consult their and/or filters in place. physician(s) before use. Electromagnetic fields in close proximity to heart pacemaker could cause 17. FOR HOUSEHOLD USE ONLY. pacemaker interference or pacemaker failure. 18.
- Page 4 extension cords 1. Grounded tools require a three wire extension 6. Make sure the extension cord is properly wired cord. Double Insulated tools can use either and in good electrical condition. Always replace a two or three wire extension cord. a damaged extension cord or have it repaired by a qualified electrician before using it.
- Page 5 Setup - Before use: read the entire iMpOrtant SaFety inFOrMatiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product. tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn: turn the power Switch of the appliance off and unplug the appliance from its electrical outlet before performing any procedure in this section.
- Page 6 note: There are two Nuts welded to the Base Plate 8. Slide Hose Clamp (41) onto Hose (42). Slide for the Stand (36) nearest to the Motor. Hose onto the Outlet (49). Once Hose is in place, tighten screw on Hose Clamp until Hose 4.
- Page 7 11. Attach Handle to Filter with Nuts (57), Washers (58), Filter (38) Washer (59), and Cap Nut (60) as shown. cap nut (60) (57) Washer Washer Filter clamp (39) (59) Washer (58) collector (58) (40) (57) Screw Scraper (27) (53) Handle (56) retainer...
- Page 8 Operating instructions read the entire iMpOrtant SaFety inFOrMatiOn section at the beginning of this manual including all text under subheadings therein before set up or use of this product. Workpiece and Work area Setup tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn: turn the power Switch of the appliance off and unplug the appliance from its electrical outlet before performing any procedure in this section.
- Page 9 user-maintenance and Storage procedures not specifically explained in this manual must be performed only by a qualified technician. tO preVent SeriOuS inJury FrOM acciDentaL OperatiOn: turn the power Switch of the appliance off and unplug the appliance from its electrical outlet before performing any procedure in this section. tO preVent SeriOuS inJury FrOM appLiance FaiLure: Do not use damaged equipment.
- Page 10 parts List and Diagram part Description part Description Base Plate Bag Retainer Nut (I‑M10) Dust Removal Plate Washer (Ø10) Bolt (M8x20) Caster Dust Scraper Nut (I‑M8) Bolt (M6x12) Washer (Ø8) Stand Bolt (M6×20) Bolt (M8×18) Foot Filter Washer (Ø6) Filter Clamp Nut (I‑M6) Collector Caster with Brake...
- Page 11 assembly Diagram 70757 For technical questions, please call 1-800-444-3353. Page 11...
- Page 12 Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase.
