EXC -RL-Z05 Series Product Specifications

Led street light
Hide thumbs

Advertisement

Table of Contents

Product Specifications
Product Name：LED Street Light
Product Model：EXC-RL-Z05-XXX
Version Number：R001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXC-RL-Z05 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for EXC EXC-RL-Z05 Series

  • Page 1 Product Specifications Product Name：LED Street Light Product Model：EXC-RL-Z05-XXX Version Number：R001...

  • Page 2: Product Features

    Product Features：  SMD3030 & 5050 high brightness LED, efficiency ≥ 130LM/W & ≥ 150LM/W;  Inventronics / MOSO / PHILIPS / SOSEN isolated led driver optional;  New features "gradienter" design for auxiliary installation, more humanized;  A variety of light distribution options(Type II, Type III and Type IV) are available to meet the application of different road lighting;...

  • Page 3: Product Images

    Product Images： 80W - 100W 120W - 150W 180W - 250W 300W - 400W 80W - 150W 180W - 400W...
  • Page 4 Dimensions: Maximum Weight Dimensions（mm） Installation Part number Power(W) Windward Screw （Kg） Area(m2) EXC-RL-Z05-80 0.140 EXC-RL-Z05-100 0.140 EXC-RL-Z05-120 0.161 EXC-RL-Z05-150 0.161 EXC-RL-Z05-180 0.202 EXC-RL-Z05-200 0.202 EXC-RL-Z05-250 0.202 EXC-RL-Z05-300 0.247 10.1 EXC-RL-Z05-360 0.247 10.4 EXC-RL-Z05-400 0.247 10.4...

  • Page 5: Specifications

    Specifications： Product Model EXC-RL-Z05 Power(W) 100W 120W 150W 180W 200W 250W 300W 360W 400W LED Source SMD3030 / SMD5050 ≥130LM/W / ≥150LM/W Efficiency（LM/W） ≥70 2,700K - 6,500K Light Distribution Bat Wing LED Driver Inventronics / MOSO / PHILIPS / SOSEN...

  • Page 6: Optional Accessories

    Optional Accessories: A). 1-10V dimming, timer control, optical sensing, internet of things control, etc; B). 3-pin, 5-pin, 7-pin NEMA base; C). 10KV or 20KV surge protection; D). Lamp pole fixing: 60-40mm, 76-60mm. Light Distribution Curve: Packaging Diagram:...

  • Page 7: Installation Instructions

    Installation Instructions 1. When the lamp is installed horizontally, loosen the M8 screw, and adjust the lamp arm to the scale pointer points to the required angle. 2. When the lamp is installed vertically, adjust the lamp arm to the vertical direction, adjust the lamp arm so that the scale pointer points to the required angle, and tighten the lamp arm screws.
  • Page 8 3. Connect the street lamp input line with city wire (in the lamp pole), and connect the corresponding line according to the way shown in the figure to ensure that the color of each connecting line is the same (please refer to the detail drawing). After connection, corresponding waterproof and anti pulling treatment shall be done.
  • Page 9 5. Tighten the 2 pieces M8 screws on the lamp socket with 6 Allen wrench. 6. Loosen the hoop end screws with a slotted screwdriver, bind the hoop on the lamp pole, and then tighten the hoop screws with a slotted screwdriver. To avoid injury, disconnect the power supply of the lamp and allow the unit to cool down before maintenance.
  • Page 10 Attention： Before using this product, please read the following precautions carefully so that you can better and correctly apply this product 1. Warranty of this product: the warranty time of different versions is different. Please consult relevant personnel for details; 2.

This manual is also suitable for:

Exc-rl-z05-80Exc-rl-z05-100Exc-rl-z05-120Exc-rl-z05-150Exc-rl-z05-180Exc-rl-z05-200 ... Show all
