Summary of Contents for Sandbox Smart R2
- Page 2 Thank you for purchasing this product! Enjoy the beautiful life brought by our smart coffee bean roaster. Download the Sandbox Smart app.
- Page 3 Product specifications Marca: Sandbox Smart Model: Smart R2 Roasting capacity: 200g-550g Heating Method: Electric Heating Approach Voltage: AC 100-120V (50/60Hz) AC 220-240V (50/60Hz)
- Page 4 Product Instructions A - Coffee bean tamping door F - The front door handle B - Bean outlet port G - Window with view of beans C - Button H - Bean outlet door lock D - Baked Bean Tray I - Chaff collection tray E - Oil collection tank J - Power switch...
- Page 5 Sandbox Smart Coffee Bean Roaster Instructions 1. Before roasting coffee beans, make sure you are familiar with the location and operation of the following parts. 1-1 Make sure A - Green Bean Inlet opens and closes the property. 1-2 Make sure the B-bean outlet door opens and closes properly. Turn the latch and make sure the door opens about 10 degrees so that the roasted beans fall out.
- Page 6 Parameter After the first crack After the second crack TIME No more than 180 seconds No more than 20 seconds STRENGTH No more than 50% No more than 30% SECONDS Not less than 60% Not less than 900% Following the above advice will electively increase the success rate and flavor of your bean roasting.
- Page 7 Steps to Roast Beans 1. Connect the power cord and turn 2. Open the Sandbox Smart App on the power switch on the back of and tap on “Pairing” the machine, the light will be on 3. Choose a profile in the App and 4.
- Page 8 5. When preheating is completed, 6. When you hear the first crack, open the bean door and pour in the tap "Press First Crack" in the app green beans. Tap "Confirm" on the (for dark roast, it will show *Press app to start roasting.
- Page 9 Cleaning the waste collector Please clean the coffee grounds straw after each use to prevent the residual straw from catching fire. 1. Put on gloves and take out the 2. Remove the waste queue tray tray of roasted beans. 3. Clean and make sure there is no 4.
- Page 10 Precautions before first use 1. Before using this product, be sure to remove the protective packaging materials and the power cord tie. 2. Use the screwdriver to open the front door and take out the heating pipe fixing piece, close the front door and tighten the screw afterwards. 3.
- Page 11 Button light description 1. When the button light is on, long press the button for 2 seconds to force the drum to roll for 10 seconds. Light signal display Description Machine initialization is complete, Constant light standby Waiting for the button to be pressed to start roasting the beans Warming up...
- Page 12 Abnormal condition Light signal display Description Machine initialization is complete, Constant light standby To switch off No lights are on The front door is open Cleaning and maintenance Step 1: Make sure the machine and drum are completely cooled down Step 2: Turn off the power Step 3: Remove the front cover screw on the right side of the door to open the front cover Step...
- Page 13 Watch the detailed video tutorial at https://youtube/bb9lBo5zVZo Guarantee Thank you for purchasing this Sandbox Smart Technology product. We provide a one-year worldwide warranty from the date of purchase. Within the warranty period, we provide a repair service if the machine is damaged due to non- human interference.
- Page 14 1.For repair service within the warranty period and related questions, please contact the distributor or purchasing channel. 2. If your machine is damaged due to the following circumstances during the warranty period, you may be subject to a repair fee: If the instructions in the manual are not followed Disassembly by unauthorized personnel or modification of the machine Failure to use required voltage causing machine malfunction...
- Page 15 2. Make sure the coffee bean inlet port is [A], the bean outlet door [B] and the bean tray (D) Roaster are tightly closed when roasting. 3. If any abnormality occurs during roasting, turn off the power immediately. Open the door once the outer casing of the machine has completely cooled. 4.
- Page 16 16. This appliance should not be used by or near children and should be stored out of their reach. 17. To protect against electrical shock, do not place or immerse cord, plugs or appliance in water or other liquid. 18. Make sure that the power supply used is the same as the rated voltage marked on the product.
- Page 17 ISED Declaration: This device contains licence-exempt transmitters that comply with Innovation, Science and Economic Development Canada's licence- exempt RS$(s). The operation is Subject to the following two conditions: (1) this device may not cause interference, (2) this device must accept any interference, including interference that may cause The licence-exempt transmitter contained in this device complies with the Innovation, Science and Economic Development Canada...
- Page 18 FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
- Page 19 If the power supply is damaged, in order to avoid danger, the manufacturer, its maintenance department or the professionals in the department must be more astute. It cannot be operated under an external timer or independent remote control system. If the power supply cord is damaged, it must be replaced by professionals from the manufacturer, its maintenance department or similar departments to avoid danger.
- Page 20 This appliance can be used by children aged 8 years and over and people with Reduced physical, sensory or mental capabilities or lack of experience and knowledge if they Have been given supervision or instruction concerning the safe use of the appliance and understand the hazards involved Children must not play with the appliance.
- Page 21 If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities Contact your local government for information on available collection systems.
- Page 22 - for very small equipment, i.e. with no external side greater than 25 cm, free delivery without obligation to purchase is provided for distributors with a sales area for electrical and electronic equipment greater than 400 m2. For distributors with smaller sizes, this mode is optional. For equipment with dimensions greater than 25 cm, delivery is provided to all distributors in cd.
