Eclipse Combustion VeriFlame CE VF56 Instruction Manual

Burner monitoring system model vf56
Hide thumbs

Advertisement

Quick Links

Download this manual
Instruction Manual
No. 818-2 9/02
VeriFlame CE
Burner Monitoring System
Model VF56
Version 2.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the VeriFlame CE VF56 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eclipse Combustion VeriFlame CE VF56

  • Page 1 Instruction Manual No. 818-2 9/02 VeriFlame CE Burner Monitoring System Model VF56 Version 2.0...
  • Page 2 In this way we hope to improve our product documentation for the benefit of our customers. Please send your corrections and comments to our Marketing Communications Manager. It must be understood that Eclipse Combustion’s liability for IABILITY AND its product, whether due to breach of warranty, negligence, ARRANTY...
  • Page 3 If you do not understand any part of the information in this manual, do not continue. Contact your Eclipse sales office or Eclipse Combustion, Rockford, Illinois. If you need help, you can contact your local Eclipse Combustion sales office. You can also contact Eclipse...
  • Page 4 There are several special symbols in this document. You OCUMENT must know their meaning and importance. The explanation ONVENTIONS of these symbols follows. Please read it thoroughly. Danger: Indicates hazards or unsafe practices that WILL result in severe personal injury or even death. Only qualified and well-trained personnel are allowed to carry out these instructions or procedures.
  • Page 5 Table of contents Copyright......................2 Disclaimer Notice ..................2 Liability and Warranty ................... 2 Audience ......................3 Scope ......................3 How To Get Help.................... 3 Document Conventions ................4 Introduction................7 Product Description ..................7 Control Unit ....................7 Wiring Base....................7 Sensor......................
  • Page 6 Scanners..................... 29 Figure 5 –2 Scanner Sighting ..............29 Test Procedures..............30 Introduction ....................30 Flame Signal Strength ................30 Minimum Pilot Test ..................30 Pilot Flame Failure Test................31 Main Flame Failure Test ................31 Spark Sighting Test ..................31 Limits and Interlocks Test ................
  • Page 7 Introduction The Eclipse Combustion VeriFlame CE Single Burner Monitoring RODUCT System consists of a microprocessor based control unit, a wiring ESCRIPTION base, and a flame sensor. The control unit includes all the necessary digital logic and analog ONTROL measuring circuitry to control the sequence and monitor the flame of single gas, oil or combination gas/oil burners.
  • Page 8 This product is in conformity with the protection CE C ONFORMITY requirements of the following European Council Directives: 73/23/EEC, the Low Voltage Directive, and 89/336/EEC, the EMC Directive, and 90/396/EEC the Gas Appliance Directive based on examination to EN298 “Automatic gas burner control systems for gas burners and gas burning appliances with or without fans”.
  • Page 9 CE C ERTIFICATE Eclipse VeriFlame CE Instruction Manual 818-2, 09/02...
  • Page 10 Specifications 102-132 VAC, 50/60 Hz OWER UPPLY 204-264 VAC, 50/60 Hz 12 VA internal consumption, excludes externally connected loads Unit Model No. Temperature Range Weight VeriFlame VF56 -40° to +60°C -40° to 140°F 1.09 kg 90-degree UV Scanner 5600-90A -20° to +60°C -4°...
  • Page 11 IMENSIONS VeriFlame Control Unit, all models VeriFlame Bases, NO-PURGE and PURGE sequence models VeriFlame MODULATION sequence model, Base Model Number 5602-40 Eclipse VeriFlame CE Instruction Manual 818-2, 09/02...
  • Page 12 Remote Display Model Number 5602-DB p.n. 20317: 24VDC Power Supply for Remote Display 5602-DB Remote Display Model Number 5602-DBP Eclipse VeriFlame CE Instruction Manual 818-2, 09/02...
  • Page 13 Function Summary This section describes the features of the VeriFlame CE. It NTRODUCTION is presented in three categories: Standard Features, Optional Features, System Errors and Lockout Conditions, and the LED Indicator Lights. The following functions are standard features on the TANDARD EATURES VeriFlame models as noted.
  • Page 14 system will lockout and the alarm output and the air failure light will come on. However, if the unit has the recycle option and the main output has been operating for at least 35 seconds, the VeriFlame will shut-down and restart. Pre-Purge For PURGE sequence models: The VeriFlame delays the sequence after the air switch is proven by the specified...
  • Page 15 Interrupted or An interrupted pilot shuts off at the time specified by the part Intermittent Pilot number after the main valve is energized. An intermittent pilot (specified as 00 time) continues during the entire main flame firing cycle. Spark, Pilot Flame & During the trial for ignition period (TFI), the pilot and ignition Main Flame outputs remain energized.
  • Page 16 The display incorporates the following functions: 1) Provides status messages for the Veri-Flame sequence, see Section 8 “Remote Display Messages” on page 38. 2) Indicates lockout conditions when they occur, as well as the amount of time into the sequence when the lockout occurred.
  • Page 17 8) Main flame fail – loss of flame during the main burner trial for ignition or run period (recycling not selected). The Flame Failure LED will be on for this condition. System Errors and The following result in lockout conditions after 30 seconds, Lockout Conditions the system error light blinks about 14 times and then (Continued)
  • Page 18 Auto For modulation models: this green LED illuminates during the automatic period which occurs 20 seconds after the main valve is energized. Test/Reset This push-button is used to activate the pilot test mode or to reset the Veri-Flame unit. Flame Signal This red LED is located behind the signal test port and illuminates when a flame signal is present.
  • Page 19 3 – 2 T PURGE M IGURE YPICAL EQUENCE FOR ODELS 3 – 3 T IGURE YPICAL EQUENCE FOR ODULATION ODELS Eclipse VeriFlame CE Instruction Manual 818-2, 09/02...
  • Page 20 System Installation In this section, the necessary procedures are detailed to integrate NTRODUCTION a VeriFlame into a burner system. Specific wiring directions are given for the various functions described in the previous section. Note: Shut off the power supply before the VeriFlame is removed or replaced from the base.
  • Page 21 sensing port. Power the valve from the blower output terminal 8. An alternate method if accepted by local codes: the air switch could be wired between the combustion blower output and the air switch input. Connecting the air switch in this manner will satisfy the open contact (air short) check during startup.
  • Page 22 High Purge Switch For modulation models: the system can be wired to check for Input high purge position for the high fire purge portion of the sequence. To use this feature, the red jumper in the base must be cut and the (Terminal D) high purge position switch must be connected from terminal 6 to D.
  • Page 23 4 –1 IGURE IRING FOR URGE ODELS 4 –2 IGURE IRING FOR URGE ODELS Eclipse VeriFlame CE Instruction Manual 818-2, 09/02...
  • Page 24 4 –3 IGURE IRING FOR IRECT PARK OF LAME &P URGE ODELS Unit must be intermittent pilot, not interrupted. 4 –4 IGURE IRING FOR ODULATION ODELS See the Function Summary Section for the sequence of these Internal Contacts. 4 –5 IGURE IRING FOR IRECT...
  • Page 25 4 –6 IGURE Scanner IRING FOR 5600-90, ODELS -91, -91N4 UV CANNERS 4 –7 IGURE IRING FOR LAME 4 –8 IGURE IRING FOR 5602-91 ODELS HECK CANNER 5602-91-7 cable 4-pin connector 4 –9 IGURE IRING FOR ODEL 5602DB, 24VDC EMOTE ISPLAY 4 –10 IGURE...
  • Page 26 4 –11 B NO-PURGE PURGE M IGURE AYOUT FOR ODELS 4 –12 B MODULATION M IGURE AYOUT FOR ODELS Eclipse VeriFlame CE Instruction Manual 818-2, 09/02...
  • Page 27 Sensor Installation This section describes the proper wiring, installation and NTRODUCTION sighting considerations for the sensors used with a VeriFlame. Warning: Incorrect sensor installation may cause the sensor to generate a false flame signal, possibly resulting in the collection of unburned fuel in the combustion chamber.
  • Page 28 Note: Unshielded sensor wiring must not be run in common with other wires; it must be run in separate conduit. Use 1mm (#14 to #18 AWG) wire suitable for 90°C (194°F) and 600 volt insulation. Multiple unshielded flame sensor wiring must not be run together in a common conduit or wire way.
  • Page 29 area between the flame rod and spark plug may eliminate the interference. CANNERS Warning: Use only Eclipse scanner models as listed for operation with the VeriFlame. When installing scanners, please consider the following: 1) Position the scanner within 450 mm (18") of the flame. Consult factory for longer distances.
  • Page 30 Test Procedures This section describes the test procedures that must be NTRODUCTION performed after installation to insure that the VeriFlame is operating properly; these procedures are mandatory. Insert the positive probe of a 0-15 VDC, digital voltmeter LAME IGNAL into the test point on the front cover of the VeriFlame; TRENGTH connect the negative probe to S2 or alternately to ground.
  • Page 31 pilot flame. Repeat steps 1 through 6 until the main burner lights off smoothly and reliably. 1) Manually shut off the fuel supply to the pilot and the ILOT LAME AILURE main burner. 2) Press the test/reset button in for the Pilot Test Mode, see page 14.
  • Page 32 Maintenance and Troubleshooting This section is divided into two parts. The first part NTRODUCTION describes the maintenance procedures. The second part describes troubleshooting procedures and includes identifying problems and interpreting the operating conditions by the lit LEDs on the front cover. Preventative maintenance is the key to a reliable, safe and AINTENANCE efficient system.
  • Page 33 1) Inspect flame-sensing devices for good condition and ONTHLY HECK cleanliness. Keep scanner lenses clean with a soft, damp cloth, since small amounts of dust will measurably reduce the flame signal strength. Wash the flame rod electrode and insulator with soap and water, then rinse and dry thoroughly.
  • Page 34 ROUBLESHOOTING PROBLEM POSSIBLE CAUSE REMEDY Cannot initiate start No power to control unit. Check for incoming power to sequence terminals 1-2. Unit is in lockout condition. Push the reset button twice, first in and then to out position. High or low gas pressure Measure gas pressure;...
  • Page 35 PROBLEM POSSIBLE CAUSE REMEDY Low fire, high fire, or main Check for improperly adjusted valve closed switches are or defective position switches not making. and loose wiring. Cannot initiate full Ignition circuit interference Separate and isolate high trial for ignition voltage spark wire.
  • Page 36 This section describes the status of operating conditions LED S TATUS based on the LED or combination of LEDs that are lit on the front cover of the VeriFlame. Some of the listed causes may apply only to a specific model sequence: No-Purge, Purge, or Modulation.
  • Page 37 7 – 1 IGURE URGE ODEL 7 – 2 P IGURE URGE ODEL 7 – 3 IGURE ODULATION ODEL Eclipse VeriFlame CE Instruction Manual 818-2, 09/02...
  • Page 38 Remote Display Messages This section covers how the optional remote display shows NTRODUCTION messages that relate to the sequences of the Veri-Flame. The remote display provides LCD messages which monitor the status of the VeriFlame’s functions as well as any lockout conditions, see “Remote Display”...
  • Page 39 8 – 1 S IGURE TARTUP Eclipse VeriFlame CE Instruction Manual 818-2, 09/02...
  • Page 40 8 – 2 P , TFI, IGURE URGE Eclipse VeriFlame CE Instruction Manual 818-2, 09/02...
  • Page 41 8 – 3 M IGURE IRING Eclipse VeriFlame CE Instruction Manual 818-2, 09/02...
  • Page 42 8 – 4 S IGURE HUTDOWN Eclipse VeriFlame CE Instruction Manual 818-2, 09/02...
  • Page 43 EMOTE ISPLAY XPLANATION ESSAGE ISTING AIR FAILURE The airflow switch input has opened for two or more seconds XX:XX:XX LOCKOUT after the initial proving period, resulting in a lockout. AIR FAILURE The airflow switch input has opened after running over 35 RECYCLING seconds in main flame.
  • Page 44 RECYCLING seconds, and will recycle back to the start-up sequence. MAIN ON The main output has energized and the flame proven. MAIN ON The pilot output has de-energized (interrupted) and the main PILOT OFF output is on. MAIN VALVE FAIL The main valve closed switch was open before start-up or XX:XX:XX LOCKOUT after shut-down.
  • Page 45 S-FAILURE-PURGE Internal component may have failed; remove power and XX:XX:XX LOCKOUT retry. If message repeats, then replace controller. TEST Control is in the Pilot Test Mode. TFI FLAME FAIL Flame was not detected by the end of the trial for ignition, XX:XX:XX LOCKOUT resulting in a lockout condition.
  • Page 46 Appendix Make one selection each from Tables I through VIII RODUCT ODEL UMBER UIDE Model VIII _ _ _ _ _ _ VF56 ABLE ESCRIPTION ELECTION 102-132VAC, 50/60Hz ABLE 204-264VAC, 50/60Hz OWER UPPLY No-Purge * ABLE Purge EQUENCE Modulation ** UV Scanner with 1 second FFRT ABLE Flame-rod with 1 second FFRT...
  • Page 47 LLUSTRATED ARTS ODEL ATEGORY ESCRIPTION UMBER UMBER Sensors Straight UV Scanner 5600-91 49600-91 90 Degree UV Scanner 5600-90A 49600-90 Self-Check UV Scanner 5602-91 49602-91 10-foot Cable for Self-Check UV 5602-91-7 49602-91-7 Scanner Sealed Straight UV Scanner 5600-91N4 20898 Scanner Support Lens Assembly, 5600-90A-SSH 20722 used with 5600-90A and 5600-91N4...
