Bell System Practices KS-15970 Assembly And Installation Manual

BELL SYSTEM PRACTICES
Plant Series
SECTION 402-433-200
Issue 1, December 1967
A7&TCo Standard
1.
2.
3.
4.
5.
MICROWAVE ANTENNAS
KS-1 5970 PARABOLIC ANTENNA
ASSEMBLY AND
CONTENTS
PAGE
GENERAL . . . . . . . . . . .1
TOOLS AND EQUIPMENT . . . . . . 2
UNPACKING AND HANDLING . . . . 3
ASSEMBLY . . . . . . . . . .3
FEED ASSEMBLY . . . . . . . . 3
RADOME . . . . . . . . . . .
AZIMUTH TURNBUCKLE ASSEMBLY . .
ELEVATION TURNBUCKLE ASSEMBLY . .
REFLECTOR POSITION ON MOUNTING
FRAME . . . . . . . . . . .
INSTALLATION . . . . . . . . .
GENERAL . . . . . . . . . . .
PRECAUTIONS . . . . . . . . .
INSTALLATION ON AT-7728 B GUYED
TOWER . . . . . . . . . . .
INSTALLATION ON AT-7729 B
SELF-SUPPORTING TOWER . . . . .
INSTALLATION ON AT-8013 C
SELF-SUPPORTING TOWER . . . . .
INSTALLATION OF ED-95 187-30 ANTENNA
SUPPORT STRUCTURE . . . . . . .
INSTALLATION ON ROOF PER ED-95 182-30
. . . . . . . . . . . . . .
INSTALLATION ON ROOF PER ED-95 189-30
. . . . . . . . . . . . . .
4
4
5
7
8
8
8
9
11
11
14
18
22
INSTALLATION
CONTENTS
PAGE
INSTALLATION ON ROOF PER ED-59804-30
. . . . . . . . . . . . .
. 22
6. ORIENTATION . . . . . . . . . 24
GENERAL . . . . . . . . . . .24
DIRECT RADIATOR APPLICATION . . . 24
PERISCOPIC APPLICATION . . . . . 26
1.
GENERAL
1.01 The KS-15970 parabolic antenna (Fig. 1) is
a dually polarized, 5-foot diameter, parabolic-
reflector antenna.
It consists principally of a
spun-aluminum dish and a simple primary feed
system. The feed system is protected by a
'laminated-glass-fabric dished radome, which is
attached to the frent of the reflector flange. The
antenna is arranged to mount with standoff brackets
and a T-frame.
The brackets and frame permit
independent azimuth and elevation orientation
adjustments when the antenna is used as a direct
radiator, or in a periscopic system.
1.02
The KS-15970 antenna is intended for use
in the TJ and TL Microwave Radio Relay
Systems to transmit and receive microwave signals
in the frequency range 10.7 to 11.7 GHz.
1.03
The antenna is covered by the following
specification and list numbers:
0 American Telephone and Telegraph Company, 1967
Printed in U.S.A.
Page 1
