Replacement Plasma Torches
Hand Torches
SL60™
4/15/04
SL100™
Machine Torches
SL100™
Torch and Adapter installations
on most Manufacturers' Units
• Esab
• L-Tec
• Lincoln
• Miller
• Hypertherm
• Hobart
• Smith
• Harris
...and more!
Literature No. 0-2935
