Summary of Contents for Contender RRG062
- Page 1 ST EP UP TO TH E P L ATE 2/3/4 DOOR COOLERS R RG 06 2 | R RG0 63 | R RG 10 0 | R RG1 0 1 | RRG 1 0 2 | RU G 047 | RU G 04 8 | RU G 04 9 | R U G0 50...
- Page 2 CONTENTS PART 1 . TECHNICAL FEATURES ................4 PART 2. INTRODUCTION ..................5 PART 3. SPECIFICATIONS ..................5 PART 4. ASSEMBLY ....................6 PART 5. OPERATION ....................6 PART 6. CLEANING, MAINTAINING AND TRANSPORTING ..........12 PART 7. TROUBLE SHOOTING .................13 PART 8. COMPLIANCE .....................13 PART 9. CAREL ECOBOX AND CAREL ENERGY SAVING CONTROLLED MODELS ..14...
- Page 4 1. TECHNICAL FEATURES 1 - Canopy 5 - InterIor lIghtIng 2 - Doors 6 - Power compartment 3 - Shelves 7 - ElectronIc thermostat (optIonal) 4 - PIlasters 8 - Adjustable feet N OT E: T he In fo rmatIon AND I M AGES gI v en ab ove a re o ptI On a l . Th ey may va ry du e to mode ls an d ve rs I on s.
- Page 5 Operating Internal Dimensions External DimensionS Max. Shelf CODE Temperature °C W x D x H (mm) W x D x H (mm) Load (Net) Kg RRG062 0 / +10 796x362x751 885x515x889 RRG063 0 / +10 796x362x751 885x515x889 RRG100 0 / +10...
- Page 6 CLIMATE CLASSES CLASS Temperature °C Relative Humidity % Dew PoInt °C 12.6 15.2 16.7 20.0 21.1 23.9 30.0 23.9 14.3 4. ASSEMBLY • Air circulation at the rear is required for the body to operate efficiently. • Move the cooler backwards to place it properly. •...
- Page 7 • Clean your cooler before operating it (See cleaning). • Since the location, ambient temperature and door-open time and frequency are the factors affecting the • interior temperature of the cooler, thermostat setting must be done accordingly. • Avoid blocking air circulation inside the cooler, when loading the cooler with food products. Otherwise undesired and extensive temperature variances may occur between the top and bottom compartments of the cooler.
- Page 8 Hol d- op en Mech an ism: (optIonal) Hold-open mechanism allows easy loading and unloading. When it requires holding the doors open, pull the RIGHT door leftmost. As it approaches the left side of the cooler, it will fit into the gap between the aluminium thread and stopper on the door track and stay motionless.
- Page 9 • Lean cabinet backwards from backside and remove pallet from underneath cabinet. Observe floor of cabinet and If Not smooth, put product on scales. For models without metal sheet connectors: Your cooler has been delIvered on a wooden pallet, FIxed to the body at four corners. Please carry out the followIng to detach the pallet before the body Is set In Its fInal operatIng locatIon: •...
- Page 10 Rep l acI ng t he f luo resc ent l Igh tI ng: (If APPICABLE) Before dismantling the lamp, always unplug your ooler. After dismantling the lamp cover inside the cooler, remove the lamp and always replace it with a lamp of the same features (length, power etc.) Unplug your COOLER.
- Page 11 : (Check the name plate) Glass doors of RRG062, RRG063, RRG100 models has been desIgned wIth resIstance to protect agaInst sweatIng. Copper termInals on the InterIor rIght and left SIDES correspondIng to the doors of cabInet should contact wIth copper plates on the sIdes of glass to prevent glasses gettIng hot and sweatING.
- Page 12 ONLY AVAILABLE FOR MODELS HAVING A VOLTAGE REGULATOR: Voltage regulator of your COOLER protects the unit against mains voltage fluctuations. When mains voltage fluctuates out of permissible range, THE voltage regulator turns off the power supply TO the unit. THIS ends when mains voltage Is back In the permissible range, the device will operate again.
- Page 13 7. TROUBLESHOOTING the COOLER does not function; - Check if the FRIDGE is properly plugged in the mains socket. - Check if there is electric current to the mains socket. - Check if the fuse has blown out. - Check if there is power failure. the COOLER RUNS more frequently - Check if the FRIDGE is properly plugged in the mains socket.
- Page 14 9. CAREL ECOBOX AND CAREL ENERGY SAVING CONTROLLED MODELS Control unit flashes for a few seconds In order to check If all connections are made correctly when the cooler Is plugged In. This Is normal, then the display will Indicate current temperature. Set temperature has been adjusted to keep your beverages at optimum temperature, please do not attempt to change the settings.
- Page 16 R RG 0 6 2 | R RG 063 | RRG 100 | RRG 10 1 | RRG10 2 | R UG047 | R U G04 8 | R U G04 9 | R U G050 STEP UP TO TH E P LAT E Distribu te d by RG Distrib u to rs Ltd.
