Summary of Contents for Contender SLU001
- Page 1 ST EP UP TO TH E P L ATE SLUSH MACHINE USER MANUAL S L U 0 0 1 | S L U 0 0 2...
- Page 2 CONTENTS 1. INTRODUCTION ....................4 2. SAFETY INSTRUCTIONS ..................4 3. INSTALLATION PROCEDURES ................5 4. PRODUCT PREPARATION AND APPLICATION ............6 5. CLEANING, SANITISATION, AND MAINTENANCE ............. 6 6. DISASSEMBLING THE PARTS ................. 7 7. RE-ASSEMBLING THE PARTS ................8 8.
- Page 4 INTRODUCTION Dear customer, Thank you for choosing our product. IMPORTANT! Our company is not responsible for any negative results and damages that may occur in case the security measures mentioned in this manual are not implemented properly. The beverage you will prepare should have sugar ratio of between 12% and 17%. In snow mode you should only prepare slush though you can prepare sherbet, ayran and other beverages in sherbet mode.
- Page 5 OPERATIONAL 1. Do not run the dispenser without reading this manual. 2. Do not run the dispenser unless all panels are mounted and fixed. 3. Do not put objects or finger in panels, louvers and faucet outlet. 4. The dispenser is not suitable for outdoor use. Make sure the dispenser is not placed and does not operate under direct sunlight.
- Page 6 4 . PRODUCT PR EPA RATI ON AND A PP L ICATI O N Preparing your Product: 1. Product may be poured into the bowl only when the machine is off and unplugged. 2. Dilute and mix the concentrate with water in a suitable container, following the concentrate manufacturer’s directions.
- Page 7 6. DI SASSE M BLING THE PARTS IMPORTANT! Make sure the turn off the machine and empty the bowl through the tap. Removing the tap FIGURE 1 1. The tap should be cleaned regularly to prevent bacteria formation and to get rid of waste food accumulation. 2.
- Page 8 Drip Tray Cleaning: The drip tray should be cleaned properly. 2. When the red warning pin is all the way up, the tray needs to be emptied. 3. Wash the drip tray in warm water and dry before installing back in place. FIGURE 7 Periodic Condenser Cleaning: FIGURE 8...
- Page 9 Assembling the Helix Mixer: FIGURE 12 FIGURE 13 1. Lubricate the bowl gasket and the place where the gasket sits on the cooling cylinder. Then place the bowl gasket on to the cooling cylinder as shown in Figure 12. 2. Attach the gasket to the white helix mixer as shown in Figure 13. IMPORTANT! Make sure to lubricate the helix mixer gasket every time you assemble the mixer.
- Page 10 Assembling the Tap: FIGURE 18 1. Press the plunger of the tap into the tap channel in the bowl as shown in Figure 18 and press it down until it fits the shoulder. IMPORTANT! Make sure to lubricate tap piston and o-rings with Vaseline or food grade lubricant every time you assemble the tap. Assembling the Bowl COVER: IMPORTANT! Follow the instructions below carefully when you mount the bowl cover.
- Page 11 8 . sET T IN G T HE DE NSIT Y OF TH E BE V ER AGE 1. User can adjust the beverage’s softness or density by turning the screw as shown in Figure 21 and 22. 2. If you choose to drink icier beverage, turn the screw counter-clockwise and you will see the indicator goes downward to plus (+) side.
- Page 12 10. ELECTRICAL DIAGRAMS SLUSH SINGLE: MAIN SWITCH FIGURE 26 S2: MIXER SWITCH S3: 3-CONTACT SWITCH S4: DEFROST SWITCH THERMOSTAT TH: COMPRESSOR THERMIC RELAY COMPRESSOR Mf: FAN MOTOR Mk: MIXER MOTOR SEL: SOLENOID VALVE SLUSH TWIN: MAIN SWITCH FIGURE 27 S2: MIXER SWITCH S3: 3-CONTACT SWITCH S4: DEFROST SWITCH THERMOSTAT...
- Page 13 11. TECHNICAL SPECIFICATIONS S L U S H S I N G L E S L U S H T W I N S L U S H T R I P L E...
- Page 14 SLUSH SINGLE...
- Page 15 SPARE PART LIST RES. STOK KODU PARÇA ADI PART NAME CODE PARÇA ADI PART NAME YM-0011 SLUSH 12 L HAZNE KAPAĞI ŞEFFAF SLUSH 12 L BOWL COVER TRANSPARENT YM-0009 SLUSH 12 L HAZNE SLUSH 12 L BOWL YM-0389 SLUSH MUSLUK TAKIMI SLUSH TAP SET YM-0387 SLUSH MUSLUK KOLU...
- Page 16 SLUSH TWIN...
- Page 17 SPARE PART LIST STOK KODU PARÇA ADI PART NAME CODE PARÇA ADI PART NAME YM-0011 SLUSH 12 L HAZNE KAPAĞI ŞEFFAF SLUSH 12 L BOWL COVER TRANSPARENT YM-0009 SLUSH 12 L HAZNE SLUSH 12 L BOWL YM-0389 SLUSH MUSLUK TAKIMI SLUSH TAP SET YM-0387 SLUSH MUSLUK KOLU...
- Page 18 SLUSH TRIPLE...
- Page 19 SPARE PART LIST RES. STOK KODU PARÇA ADI PART NAME CODE PARÇA ADI PART NAME YM-0011 SLUSH 12 L HAZNE KAPAĞI ŞEFFAF SLUSH 12 L BOWL COVER TRANSPARENT YM-0009 SLUSH 12 L HAZNE SLUSH 12 L BOWL YM-0389 SLUSH MUSLUK TAKIMI SLUSH TAP SET YM-0387 SLUSH MUSLUK KOLU...
- Page 20 TROUBLESHOOTING PROBLEM CAUSE SOLUTION 4. Open the thermostats. 4. Thermostats may be closed. 6. There may be a power shortage. 2. The tap hose may be torn. The tap cons- The beverage some sugar. Do not use hot water. turn 3.
- Page 21 NOTES...
- Page 22 2 x 1 2 L T w i n S l u s h M a c h i n e • S K U : S L U 0 0 1 3 x 1 2 L T r i p l e S l u s h M a c h i n e • S K U : S L U 0 0 2 STEP UP TO TH E P LAT E Distribu te d by RG Distrib u to rs Ltd.
